In recent years, interest in lithium-ion batteries has grown significantly due to their dominance in electric mobility, driven by their high energy density. However, their performance and longevity are strongly influenced by the effectiveness of heat dissipation and thermal management. The literature indicates that battery temperature should be maintained within the optimal range of 20–40 °C, while also ensuring minimal temperature gradients within the battery pack. In this study, a thermal management system for electric vehicle batteries which combines two different cooling approaches (i.e., direct immersion cooling and pulsating heat pipes) is presented. In particular, the battery pack is placed inside a PVC case and completely submerged by a low-boiling dielectric fluid (T_bp = 33.4 °C at 1 atm) to take advantage of the excellent thermal properties of the liquid and of the latent heat during phase change. The evaporator section of the pulsating heat pipe is positioned in the vapor phase region of the dielectric fluid, while the condenser section is located outside the PVC box and cooled by an airflow in natural convection. This setup is a completely passive system. To evaluate the cooling performance of the dual two-phase cooling system, tests were conducted on the battery pack at three different discharge C-rates 0.5C, 1C, and 2C that reproduce the working conditions of a real-world battery. To evaluate the effectiveness of the new setup, its performance was compared with cooling based on natural convection and direct immersion cooling alone. These approaches were assessed under two controlled ambient temperatures—5 °C and 20 °C—to compare their performance in varying conditions. The results show that the hybrid system performs particularly well, especially because it can operate passively without requiring external power or active control mechanisms. Full article

The numerical solution of flow and temperature fields in and around a hot metal component being immersed into a cooling fluid offers powerful insights into investigating industrial quenching processes. The calculation requires a simultaneous solution of the Navier Stokes and the according energy equation. Difficulties arise at the boundaries where high heat transfer rates are forced from the solid surface to the fluid due to high metal temperatures. Heat transfer rates are determined based on the similarity theory, but reliable heat transfer equations valid for the high temperature typical of quenching processes are rare. This paper presents a two-fluid VOF (volume-of-fluid method) approach, giving an insight into the transient heat transfer and its oscillations. Unlike our previous publications, this paper uses the lumped heat conduction model to obtain the heat transfer coefficient in the film boiling heat transfer mode. Its application leads to an estimation of an average heat transfer coefficient. Furthermore, the unsteady distribution of the heat transfer coefficient values, shown in our previous paper, is now supplemented with the corresponding flow behavior obtained using the numerical simulation. In our approach, the vapor bubble formation during the film boiling phase is tracked directly (DNS of interface motion, not turbulence), and the unsteady heat transfer coefficient distribution is obeyed. Full article

Deionized water is replacing fluorinated liquids as the preferred choice for two-phase immersion cooling in data centers. Yet, insufficient bubble removal capability at low saturated pressure is a key challenge hindering the widespread application. To solve this issue, this study employs non-ionic surfactant (Tween 20) and asymmetric structures (expanding microchannel) to enhance the boiling performances of deionized water under sub-atmospheric pressure. The research examines the effects of pressure (8.8~38.5 kPa), surfactant concentration (0.1~0.5 mL/L), and heat flux density (10~180 W/cm²) on the boiling heat transfer characteristics and analyzes the mechanism of unusual temperature oscillations induced by surfactants. It was found that the trade-off between the sub-atmospheric pressure, surface tension coefficient, and reduced static contact angle results in pronounced intermittent boiling on the heated surface. Even with the addition of surfactants, the improvement in heat transfer requires demanding conditions. Boiling enhancement throughout all heat flux conditions was achieved when the surfactant concentration was higher than 0.2 mL/L for the expanding microchanneled surface. The heat transfer coefficient reached 6.89 W·cm⁻²·K⁻¹ under 8.8 kPa, which was 45% higher than without the surfactant. Under the same heat flux and sub-atmospheric pressure, as the concentration increased from 0.1 to 0.5 mL/L, the amplitudes of temperature fluctuation of the plane surface and expanding microchanneled surface decreased from 10 K to 2 K and 18 K to 1 K, respectively. The onset of nucleate boiling and wall superheat of the expanding microchanneled surface gradually decreased with the increase in surfactant concentration, where the onset of nucleate boiling decreased by 10.54 K. When the heat flux is 160 W/cm², the wall superheat is reduced by 12.8 K. Full article

An accurate simulation and computational analysis of temperature distribution in large power transformers used in power plants is crucial during both the design and operational phases. This study introduces a thermal modeling analysis encompassing two- and three-dimensional (2D and 3D) approaches for power transformers. The mathematical model for heat diffusion follows the Finite Element Method (FEM) approach. Validation of the computed results involves comparing them against measurements from Hyundai’s test report for both 2D and 3D models, aiming to identify the most effective solution. Additionally, the thermal dynamics of power transformers under diverse operational conditions, specifically oil-immersed ones, are examined. The efficacy of this model is confirmed through testing on a step-up transformer at Kureimat station in Egypt, with specifications including three-phase, 50 Hz, 16.5/240 KV, nine taps, and cooling type (ONAN/ONAF1/ONAF2). Full article

The effects of the anisotropic properties (wettability and roughness) of microgrooved surfaces on heat transfer were experimentally investigated during pool boiling using Novec-7100 as a working fluid. The idea for introducing the concept of anisotropic wettability in boiling experiments draws inspiration from biphilic surfaces. The investigation is also motivated by two-phase immersion cooling, which involves phase-change heat transfer, using a dielectric liquid as a working fluid. Very few studies have focused on the effects of surfaces with anisotropic properties on boiling performance. Thus, this study aims to examine the pool-boiling heat transfer performance on surfaces with microgroove-induced anisotropic properties under the saturation condition. A femtosecond-laser texturing method was employed to create microgrooved surfaces with different groove spacings. The results indicated that anisotropic properties affected the heat transfer coefficient and critical heat flux. Relative to the plain surface, microgrooved surfaces enhanced the heat transfer performance due to the increased number of bubble nucleation sites and higher bubble detachment frequency. An analysis of bubble dynamics under different surface conditions was conducted with the assistance of high-speed images. The microgrooved surface with a groove spacing of 100 μm maximally increased the BHTC by 37% compared with that of the plain surface. Finally, the CHF results derived from experiments were compared with related empirical correlations. Good agreement was achieved between the results and the prediction correlation. Full article

Lithium-ion batteries, crucial in powering Battery Electric Vehicles (BEVs), face critical challenges in maintaining safety and efficiency. The quest for an effective Battery Thermal Management System (BTMS) arises from critical concerns over the safety and efficiency of lithium-ion batteries, particularly in Battery Electric Vehicles (BEVs). This study introduces a pioneering BTMS solution merging a two-phase immersion cooling system with heat pipes. Notably, the integration of NovecTM 649 as the dielectric fluid substantially mitigates thermal runaway-induced fire risks without requiring an additional power source. Comprehensive 1-D modeling, validated against AMESim (Advanced Modeling Environment for Simulation of Engineering Systems) simulations and experiments, investigates diverse design variable impacts on thermal resistance and evaporator temperature. At 10 W, 15 W, and 20 W heat inputs, the BTMS consistently maintained lithium-ion battery temperatures within the optimal range (approximately 27–34 °C). Optimized porosity (60%) and filling ratios (30–40%) minimized thermal resistance to 0.3848–0.4549 °C/W. This innovative system not only enhances safety but also improves energy efficiency by reducing weight, affirming its potential to revolutionize lithium-ion battery performance and address critical challenges in the field. Full article

Immersion cooling is widely used for thermal management of servers. The two-phase immersion cooling, which transfers heat by boiling, possesses efficient temperature control ability under intensive heat generation. In the process of temperature control through boiling, the generation and transportation of bubbles play a crucial role in calculating the heat-transfer capacity. Therefore, it holds immense significance to obtain a profound understanding of the mechanisms underlying bubble formation and detachment. Currently, numerous mechanistic explanations and empirical correlations have been proposed to elucidate the various parameters of bubbles during the boiling process. These findings were considered to be valuable references when selecting appropriate boiling media and designing efficient heating surfaces. To comprehensively present the progress of bubble formation and heat transfer in the boiling system, the forces exerted on the bubbles are highlighted in this article. A meticulous review of bubble-force analysis and correlation formulae pertaining to various relevant parameters (e.g., nucleation sites density, bubble growth rate, bubble growth period, and detachment frequency) was conducted. This review article was also expected to provide a novel foundation for further exploration of enhanced boiling heat transfer. Full article

As the carriers of massive data, data centers are constantly needed to process and calculate all kinds of information from various fields and have become an important infrastructure for the convenience of human life. Data centers are booming around the world, accompanied by the problems of high power consumption and poor heat dissipation. One of the most effective solutions to these problems is to adapt a two-phase liquid immersion cooling technology, which is a more energy-saving and efficient method than the traditional cooling methods; the reason for this is mainly that in two-phase liquid immersion cooling technology, the heat transfer caused by the phase change of liquid coolants (electronic fluoride liquids) helps to cool and improve the temperature uniformity of electronic components. However, the requirements for the electronic fluoride liquids used in two-phase liquid immersion cooling systems are strict. The thermophysical properties (saturated vapor pressure, density, surface tension, viscosity, thermal conductivity and latent heat of vaporization, etc.) of the liquid coolants play a very key role in the heat dissipation capacity of two-phase liquid immersion cooling systems. However, it is not always easy to obtain new electronic fluoride liquids under many actual conditions and reasonable prediction models of their thermophysical properties could contribute to the preliminary screening of the coolants. Thus, the prediction models of their key thermophysical properties (saturated vapor pressure, saturation density, surface tension, viscosity and thermal conductivity) are reviewed, and the accuracy and practicality of these prediction models in predicting the thermophysical properties of electronic fluoride liquids (FC-72, HFE-7100 and Novec 649) are evaluated. This work will provide a valuable reference for actual engineering applications. Full article

Cooling systems can effectively enable information and communication technology (ICT) equipment to utilize power more efficiently in data centers (DCs). Two-phase cooling provides a potential method to cool CPUs and other electronics and involves submerging them in a thermal conductive dielectric liquid or coolant. In this study, an innovative cooling structure and a two-phase immersion cooling system procedure are presented. The CPU is directly submerged in an engineered fluid, and an experimental test is conducted to obtain the boiling heat transfer and energy consumption data. A prediction equation for saturated boiling HTC in the pool, based on the influence of the characteristics of the heat transfer surface of the CPU and the physical parameters, is proposed. The average partial power usage effectiveness (pPUE) value of the proposed system is 1.036, indicating a significantly improved energy conservation effect compared to conventional air cooling systems. Studies have shown that direct-touch heat dissipation is suitable for supercomputer server CPU heat dissipation with low heat flux density, while for high-density CPU heat dissipation, it is easy to reach the maximum temperature limit of the CPU, thereby reducing the CPU frequency. Full article

In this study, three-dimensional thermal simulations for a 54 V Lithium-ion battery pack composed of 18 LiFePO₄ pouch battery cells connected in series were conducted using a multi-scale electrochemical-thermal-fluid model. An equivalent circuit model (ECM) is used as a subscale electrochemical model at each cell node of the battery, which is then combined with the macro-scale thermal and fluid equations to construct a model of the battery and battery pack. With the model, the cooling effects of indirect cooling and direct cooling battery thermal management systems (BTMS) on the battery pack under rapid discharging conditions are explored. It is found that when the battery pack is discharged at 2C, indirect cooling of the bottom plate can effectively dissipate heat and control the temperature of the battery pack. Under the 10C discharging condition, the maximum temperature of the battery pack will exceed 100 °C, and the temperature uniformity will be very poor when using indirect cooling of the bottom plate for the battery pack. Direct air cooling is also unable to meet the cooling requirements of the battery pack at a 10C discharging rate. The possible reason is that the convective heat transfer coefficient of direct air cooling is small, which makes it difficult to meet the heat dissipation requirements at the 10C condition. When single-phase direct cooling with fluorinated liquid is used, the maximum temperature of the battery pack under the 10C discharging condition can be controlled at about 65 °C. Compared with air direct cooling, the pressure drop of fluorinated liquid single-phase direct cooling is smaller, and the obtained battery pack temperature uniformity is better. From the detailed study of fluorinated liquid single-phase direct cooling, it is concluded that increasing the coolant flow rate and reducing the cell spacing in the battery pack can achieve a better cooling effect. Finally, a new cooling method, two-phase immersion cooling, is investigated for cooling the battery pack. The maximum temperature of the battery pack discharged at a 10C rate can be controlled below 35 °C, and good temperature uniformity of the battery pack is also achieved at the same time. This study focuses on fluorinated liquid immersion cooling using numerical simulations, showing that it is a promising cooling method for lithium-ion battery packs and deserves further study. This paper will provide a reference for the design and selection of BTMS for electric vehicles. Full article

This paper reviews the major researchers of liquid, immersion, and two-phase cooling. Currently, liquids are used instead of air to cool the growing data centers. Immersion cooling shows a higher heat transfer coefficient than conventional cooling (<37 W/cm²). Because the use of liquids with high global warming potentials is prohibited, the number of liquids that can be used is limited. This paper discusses the existing, relevant literature from researchers who have studied the issue at least thrice. The authors were divided into those who focused on the surface and those who formed a structure on the surface. In summary, the authors suggested the following research directions: The experimental conditions of porous foam are not diverse, and there is a concern about the separation of foam and coating into the tub. The experimental conditions of the immersion tub should also be varied according to the heat and pressure over time. Structure-level research shows higher performance than surface-level research, but an economic feasibility study is required. Full article

In this work, three-dimensional thermal simulations of single 18650 lithium-ion battery cell and 75 V lithium-ion battery pack composed of 21 18650 battery cells are performed based on a multi-scale multi-domain (MSMD) battery modeling approach. Different cooling approaches’ effects on 18650 lithium-ion battery and battery pack thermal management under fast discharging and external shorting conditions are investigated and compared. It is found that for the natural convection, forced air cooling, and/or mini-channel liquid cooling approaches, the temperature of battery cell easily exceeds 40 °C under 3C rate discharging condition. While under external shorting condition, the temperature of cell rises sharply and reaches the 80 °C in a short period of time, which can trigger thermal runaway and may even lead to catastrophic battery fire. On the other hand, when the cooling method is single-phase direct cooling with FC-72 as coolant or two-phase immersed cooling by HFE-7000, the cell temperature is effectively limited to a tolerable level under both high C rate discharging and external shorting conditions. In addition, two-phase immersed cooling scheme is found to lead to better temperature uniformity according to the 75 V battery pack simulations. Full article

In this paper, the vibration frequency of the stator of 3.6 MW fully immersed evaporative cooling permanent magnet semi-direct drive generators (ECPMSDDGs) was analyzed based on the fluid-structure coupling theory and solved by finite element analysis (FEA) simulation. The resonance noise reduction research under the typical working condition induced by two-phase flow and electromagnetic force was studied based on the method of structural optimization. In this paper, a structural optimal design method for the stator of the 3.6 MW ECPMSDDGs was presented. First of all, the frequency and characteristics of electromagnetic force of 3.6 MW ECPMSDDGs under the rated power were analyzed. Secondly, the frequency and characteristics of two-phase flow boiling vibration were analyzed based on the bubble oscillation theory of the two-phase flow and the experiment. Thirdly, the wet modal natural frequency of the stator core cooling structure was analyzed based on the fluid-structure coupling theory and FEA. Finally, the natural wet mode vibration frequency of the stator cooling structure of the 3.6 MW ECPMSDDGs was improved based on the structure optimization. This optimization method could reduce the resonance noise of evaporative cooling motor induced by electromagnetic and two-phase flow. The optimization results showed that the natural wet mode frequency of the stator could be improved by optimizing the radial flow groove and supporting beam under the condition that the effective length of the stator core remained unchanged during the optimization. The noise simulation result showed that the resonance noise of 3.6 MW ECPMSDDGs induced by electromagnetic and two-phase flow could be reduced after the structural optimization. Full article

An efficient cooling system for data centers can boost the working efficiency of servers and promote energy savings. In this study, a laboratory experiment and computational fluid dynamics (CFD) simulation were performed to explore the performance of a two-phase cooling system. The coefficient of performance (COP) and partial power usage effectiveness (pPUE) of the proposed system was evaluated under various IT (Information Technology) loads. The relationship between the interval of the two submerged servers and their surface temperatures was evaluated by CFD analysis, and the minimum intervals that could maintain the temperature of the server surfaces below 85 °C were obtained. Experimental results show that as server power increases, COP increases pPUE decreases. In one experiment, the COP increased from 19.0 to 26.7, whereas pPUE decreased from 1.053 to 1.037. The exergy efficiency of this system ranges from 12.65% to 18.96%, and the tank side accounts for most of the exergy destruction. The minimum intervals between servers are 15 mm under 1000 W of power, 20 mm under 1500 W, and more than 30 mm under 2000 W and above. The observations and conclusions in this study can be valuable references for the study of cooling systems in data centers. Full article

Nickel-based alloys have had extensive immersion in the manufacturing world in recent decades, especially in high added value sectors such as the aeronautical sector. Inconel 718 is the most widespread in terms of implantation. Therefore, the interest in adapting the manufacture of this material to additive manufacturing technologies is a significant objective within the scientific community. Among these technologies for the manufacture of parts by material deposition, plasma arc welding (PAW) has advantages derived from its simplicity for automation and integration on the work floor with high deposition ratios. These characteristics make it very economically appetizing. However, given the tendency of this material to form precipitates in its microstructure, its manufacturing by additive methods is very challenging. In this article, three deposition conditions are analyzed in which the energy and deposition ratio used are varied, and two cooling strategies are studied. The interpass cooling strategy (ICS) in which a fixed time is expected between passes and controlled overlay strategy (COS) in which the temperature at which the next welding pass starts is controlled. This COS strategy turns out to be advantageous from the point of view of the manufacturing time, but the deposition conditions must be correctly defined to avoid the formation of Laves phases and hot cracking in the final workpiece. Full article
