Advances in Microfluidics and Lab on a Chip Technology

Journal Name	Impact Factor	CiteScore	Launched Year	First Decision (median)	APC
Applied Sciences applsci	2.5	5.3	2011	18.4 Days	CHF 2400
Biosensors biosensors	4.9	6.6	2011	18.9 Days	CHF 2200
Micromachines micromachines	3.0	5.2	2010	16.2 Days	CHF 2100
Molecules molecules	4.2	7.4	1996	15.1 Days	CHF 2700
Sensors sensors	3.4	7.3	2001	18.6 Days	CHF 2600

10 pages, 5795 KiB

Open AccessArticle

A PDMS–Agar Hybrid Microfluidic Device for the Investigation of Chemical–Mechanical Associative Learning Behavior of C. elegans

by Jinchi Zhu, Yu Wang, Shuting Tang, Huiying Su, Xixian Wang, Wei Du, Yun Wang and Bi-Feng Liu

Micromachines 2023, 14(8), 1576; https://doi.org/10.3390/mi14081576 - 10 Aug 2023

Cited by 1 | Viewed by 1957

Abstract

Associative learning is a critical survival trait that promotes behavioral plasticity in response to changing environments. Chemosensation and mechanosensation are important sensory modalities that enable animals to gather information about their internal state and external environment. However, there is a limited amount of [...] Read more.

Associative learning is a critical survival trait that promotes behavioral plasticity in response to changing environments. Chemosensation and mechanosensation are important sensory modalities that enable animals to gather information about their internal state and external environment. However, there is a limited amount of research on these two modalities. In this paper, a novel PDMS–agar hybrid microfluidic device is proposed for training and analyzing chemical–mechanical associative learning behavior in the nematode Caenorhabditis elegans. The microfluidic device consisted of a bottom agar gel layer and an upper PDMS layer. A chemical concentration gradient was generated on the agar gel layer, and the PDMS layer served to mimic mechanical stimuli. Based on this platform, C. elegans can perform chemical–mechanical associative learning behavior after training. Our findings indicated that the aversive component of training is the primary driver of the observed associative learning behavior. In addition, the results indicated that the neurotransmitter octopamine is involved in regulating this associative learning behavior via the SER-6 receptor. Thus, the microfluidic device provides a highly efficient platform for studying the associative learning behavior of C. elegans, and it may be applied in mutant screening and drug testing. Full article

(This article belongs to the Topic Advances in Microfluidics and Lab on a Chip Technology)

► Show Figures

Figure 1

37 pages, 7033 KiB

Open AccessArticle

Developing an Active Microfluidic Pump and Mixer Driven by AC Field-Effect-Mediated Induced-Charge Electro-Osmosis of Metal–Dielectric Janus Micropillars: Physical Perspective and Simulation Analysis

by Weiyu Liu, Ye Tao, Yaoyao Chen, Zhenyou Ge, Junshuo Chen and Yanbo Li

Appl. Sci. 2023, 13(14), 8253; https://doi.org/10.3390/app13148253 - 16 Jul 2023

Cited by 3 | Viewed by 1787

Abstract

We propose herein a novel microfluidic approach for the simultaneous active pumping and mixing of analytes in a straight microchannel via the AC field-effect control of induced-charge electro-osmosis (ICEO) around metal–dielectric solid Janus cylinders of inherent inhomogeneous electrical polarizability immersed in an electrolyte [...] Read more.

We propose herein a novel microfluidic approach for the simultaneous active pumping and mixing of analytes in a straight microchannel via the AC field-effect control of induced-charge electro-osmosis (ICEO) around metal–dielectric solid Janus cylinders of inherent inhomogeneous electrical polarizability immersed in an electrolyte solution. We coin the term “Janus AC flow field-effect transistor (Janus AC-FFET)” to describe this interesting physical phenomenon. The proposed technique utilizes a simple device geometry, in which one or a series of Janus microcylinders are arranged in parallel along the centerline of the channel’s bottom surface, embedding a pair of 3D sidewall driving electrodes. By combining symmetry breaking in both surface polarizability and the AC powering scheme, it is possible, on demand, to adjust the degree of asymmetry of the ICEO flow profile in two orthogonal directions, which includes the horizontal pump and transversal rotating motion. A comprehensive mathematical model was developed under the Debye–Hückel limit to elucidate the physical mechanism underlying the field-effect-reconfigurable diffuse-charge dynamics on both the dielectric and the metal-phase surfaces of the Janus micropillar. For innovation in applied science, an advanced microdevice design integrating an array of discrete Janus cylinders subjected to two oppositely polarized gate terminals is recommended for constructing an active microfluidic pump and mixer, even without external moving parts. Supported by a simulation analysis, our physical demonstration of Janus AC-FFET provides a brand-new approach to muti-directional electro-convective manipulation in modern microfluidic systems. Full article

(This article belongs to the Topic Advances in Microfluidics and Lab on a Chip Technology)

► Show Figures

Figure 1

18 pages, 5270 KiB

Open AccessArticle

Hemagglutination Assay via Optical Density Characterization in 3D Microtrap Chips

by Sung-Wook Nam, Dong-Gyu Jeon, Young-Ran Yoon, Gang Ho Lee, Yongmin Chang and Dong Il Won

Biosensors 2023, 13(7), 733; https://doi.org/10.3390/bios13070733 - 14 Jul 2023

Cited by 4 | Viewed by 3037

Abstract

Hemagglutination assay has been used for blood typing and detecting viruses, thus applicable for the diagnosis of infectious diseases, including COVID-19. Therefore, the development of microfluidic devices for fast detection of hemagglutination is on-demand for point-of-care diagnosis. Here, we present a way to [...] Read more.

Hemagglutination assay has been used for blood typing and detecting viruses, thus applicable for the diagnosis of infectious diseases, including COVID-19. Therefore, the development of microfluidic devices for fast detection of hemagglutination is on-demand for point-of-care diagnosis. Here, we present a way to detect hemagglutination in 3D microfluidic devices via optical absorbance (optical density, OD) characterization. 3D printing is a powerful way to build microfluidic structures for diagnostic devices. However, mixing liquid in microfluidic chips is difficult due to laminar flow, which hampers practical applications such as antigen-antibody mixing. To overcome the issue, we fabricated 3D microfluidic chips with embedded microchannel and microwell structures to induce hemagglutination between red blood cells (RBCs) and antibodies. We named it a 3D microtrap chip. We also established an automated measurement system which is an integral part of diagnostic devices. To do this, we developed a novel way to identify RBC agglutination and non-agglutination via the OD difference. By adapting a 3D-printed aperture to the microtrap chip, we obtained a pure absorbance signal from the microchannels by eliminating the background brightness of the microtrap chip. By investigating the underlying optical physics, we provide a 3D device platform for detecting hemagglutination. Full article

(This article belongs to the Topic Advances in Microfluidics and Lab on a Chip Technology)

► Show Figures

Figure 1

20 pages, 3508 KiB

Open AccessArticle

Difference in Intestine Content of Caenorhabditis elegans When Fed on Non-Pathogenic or Pathogenic Bacteria

by Farzad Rezaeianaran and Martin A. M. Gijs

Micromachines 2023, 14(7), 1386; https://doi.org/10.3390/mi14071386 - 7 Jul 2023

Viewed by 1923

Abstract

We investigated the bacterial food digestion and accumulation in wild-type adult Caenorhabditis elegans (C. elegans) worms that have fed on either non-pathogenic RFP-expressing Escherichia coli (E. coli) OP50 or pathogenic-RFP-expressing Pseudomonas aeruginosa (P. aeruginosa) PAO1 during the [...] Read more.

We investigated the bacterial food digestion and accumulation in wild-type adult Caenorhabditis elegans (C. elegans) worms that have fed on either non-pathogenic RFP-expressing Escherichia coli (E. coli) OP50 or pathogenic-RFP-expressing Pseudomonas aeruginosa (P. aeruginosa) PAO1 during the first 4 days of adulthood. Once the worms had completed their planned feeding cycles, they were loaded on microfluidic chips, where they were fixed to allow high-resolution z-stack fluorescence imaging of their intestines utilizing a Spinning Disk Confocal Microscope (SDCM) equipped with a high-resolution oil-immersion objective (60×). IMARIS software was used to visualize and analyze the obtained images, resulting in the production of three-dimensional constructs of the intestinal bacterial load. We discovered two distinct patterns for the bacteria-derived fluorescence signal in the intestine: (i) individual fluorescent spots, originating from intact bacteria, were present in the fluorescent E. coli-OP50-fed worms, and (ii) individual fluorescent spots (originating from intact bacteria) were dispersed in large regions of diffuse fluorescence (RDF), originating from disrupted bacteria, in fluorescent P. aeruginosa-PAO1-fed worms. We performed a semi-automated single-worm-resolution quantitative analysis of the intestinal bacterial load, which showed that the intestinal bacterial load generally increases with age of the worms, but more rapidly for the fluorescent P. aeruginosa-PAO1-fed worms. Full article

(This article belongs to the Topic Advances in Microfluidics and Lab on a Chip Technology)

► Show Figures

Figure 1

13 pages, 7148 KiB

Open AccessArticle

Microdroplet PCR in Microfluidic Chip Based on Constant Pressure Regulation

by Luyang Duanmu, Yuanhua Yu and Xiangkai Meng

Micromachines 2023, 14(6), 1257; https://doi.org/10.3390/mi14061257 - 15 Jun 2023

Cited by 5 | Viewed by 2787

Abstract

A device and method for the constant pressure regulation of microdroplet PCR in microfluidic chips are developed to optimize for the microdroplet movement, fragmentation, and bubble generation in microfluidic chips. In the developed device, an air source device is adopted to regulate the [...] Read more.

A device and method for the constant pressure regulation of microdroplet PCR in microfluidic chips are developed to optimize for the microdroplet movement, fragmentation, and bubble generation in microfluidic chips. In the developed device, an air source device is adopted to regulate the pressure in the chip, such that microdroplet generation and PCR amplification without bubbles can be achieved. In 3 min, the sample in 20 μL will be distributed into nearly 50,000 water-in-oil droplets exhibiting a diameter of about 87 μm, and the microdroplet will be subjected to a close arrangement in the chip without air bubbles. The device and chip are adopted to quantitatively detect human genes. As indicated by the experimental results, a good linear relationship exists between the detection signal and DNA concentration ranging from 10¹ to 10⁵ copies/μL (R² = 0.999). The microdroplet PCR devices based on constant pressure regulation chips exhibit a wide variety of advantages (e.g., achieving high pollution resistance, microdroplet fragmentation and integration avoidance, reducing human interference, and standardizing results). Thus, microdroplet PCR devices based on constant pressure regulation chips have promising applications for nucleic acid quantification. Full article

(This article belongs to the Topic Advances in Microfluidics and Lab on a Chip Technology)

► Show Figures

Figure 1

14 pages, 2235 KiB

Open AccessArticle

Label-Free Cyanobacteria Quantification Using a Microflow Cytometry Platform for Early Warning Detection and Characterization of Hazardous Cyanobacteria Blooms

by Yushan Zhang, Andres Escobar, Tianyi Guo and Chang-Qing Xu

Micromachines 2023, 14(5), 965; https://doi.org/10.3390/mi14050965 - 28 Apr 2023

Cited by 1 | Viewed by 1756

Abstract

The eutrophication of aquatic ecosystems caused by rapid human urbanization has led to an increased production of potentially hazardous bacterial populations, known as blooms. One of the most notorious forms of these aquatic blooms are cyanobacteria, which in sufficiently large quantities can pose [...] Read more.

The eutrophication of aquatic ecosystems caused by rapid human urbanization has led to an increased production of potentially hazardous bacterial populations, known as blooms. One of the most notorious forms of these aquatic blooms are cyanobacteria, which in sufficiently large quantities can pose a hazard to human health through ingestion or prolonged exposure. Currently, one of the greatest difficulties in regulating and monitoring these potential hazards is the early detection of cyanobacterial blooms, in real time. Therefore, this paper presents an integrated microflow cytometry platform for label-free phycocyanin fluorescence detection, which can be used for the rapid quantification of low-level cyanobacteria and provide early warning alerts for potential harmful cyanobacterial blooms. An automated cyanobacterial concentration and recovery system (ACCRS) was developed and optimized to reduce the assay volume, from 1000 mL to 1 mL, to act as a pre-concentrator and subsequently enhance the detection limit. The microflow cytometry platform utilizes an on-chip laser-facilitated detection to measure the in vivo fluorescence emitted from each individual cyanobacterial cell, as opposed to measuring overall fluorescence of the whole sample, potentially decreasing the detection limit. By applying transit time and amplitude thresholds, the proposed cyanobacteria detection method was verified by the traditional cell counting technique using a hemocytometer with an R² value of 0.993. It was shown that the limit of quantification of this microflow cytometry platform can be as low as 5 cells/mL for Microcystis aeruginosa, 400-fold lower than the Alert Level 1 (2000 cells/mL) set by the World Health Organization (WHO). Furthermore, the decreased detection limit may facilitate the future characterization of cyanobacterial bloom formation to better provide authorities with ample time to take the appropriate actions to mitigate human risk from these potentially hazardous blooms. Full article

(This article belongs to the Topic Advances in Microfluidics and Lab on a Chip Technology)

► Show Figures

Figure 1

21 pages, 3823 KiB

Open AccessReview

Manipulation, Sampling and Inactivation of the SARS-CoV-2 Virus Using Nonuniform Electric Fields on Micro-Fabricated Platforms: A Review

by Devashish Mantri, Luutzen Wymenga, Jan van Turnhout, Henk van Zeijl and Guoqi Zhang

Micromachines 2023, 14(2), 345; https://doi.org/10.3390/mi14020345 - 29 Jan 2023

Cited by 5 | Viewed by 2162

Abstract

Micro-devices that use electric fields to trap, analyze and inactivate micro-organisms vary in concept, design and application. The application of electric fields to manipulate and inactivate bacteria and single-celled organisms has been described extensively in the literature. By contrast, the effect of such [...] Read more.

Micro-devices that use electric fields to trap, analyze and inactivate micro-organisms vary in concept, design and application. The application of electric fields to manipulate and inactivate bacteria and single-celled organisms has been described extensively in the literature. By contrast, the effect of such fields on viruses is not well understood. This review explores the possibility of using existing methods for manipulating and inactivating larger viruses and bacteria, for smaller viruses, such as SARS-CoV-2. It also provides an overview of the theoretical background. The findings may be used to implement new ideas and frame experimental parameters that optimize the manipulation, sampling and inactivation of SARS-CoV-2 electrically. Full article

(This article belongs to the Topic Advances in Microfluidics and Lab on a Chip Technology)

► Show Figures

Figure 1

8 pages, 1183 KiB

Open AccessTechnical Note

A Solution to the Clearance Problem of Sacrificial Material in 3D Printing of Microfluidic Devices

by Terak Hornik, James Kempa, Jeffrey Catterlin and Emil Kartalov

Micromachines 2023, 14(1), 16; https://doi.org/10.3390/mi14010016 - 21 Dec 2022

Cited by 6 | Viewed by 2077

Abstract

3D-printing is poised to enable remarkable advances in a variety of fields, such as artificial muscles, prosthetics, biomedical diagnostics, biofuel cells, flexible electronics, and military logistics. The advantages of automated monolithic fabrication are particularly attractive for complex embedded microfluidics in a wide range [...] Read more.

3D-printing is poised to enable remarkable advances in a variety of fields, such as artificial muscles, prosthetics, biomedical diagnostics, biofuel cells, flexible electronics, and military logistics. The advantages of automated monolithic fabrication are particularly attractive for complex embedded microfluidics in a wide range of applications. However, before this promise can be fulfilled, the basic problem of removal of sacrificial material from embedded microchannels must be solved. The presented work is an experimental proof of principle of a novel technique for clearance of sacrificial material from embedded microchannels in 3D-printed microfluidics. The technique demonstrates consistent performance (~40–75% clearance) in microchannels with printed width of ~200 µm and above. The presented technique is thus an important enabling tool in achieving the promise of 3D printing in microfluidics and its wide range of applications. Full article

(This article belongs to the Topic Advances in Microfluidics and Lab on a Chip Technology)

► Show Figures

Figure 1

11 pages, 3886 KiB

Open AccessFeature PaperEditor’s ChoiceArticle

A Nitrocellulose Paper-Based Multi-Well Plate for Point-of-Care ELISA

by Zhen Qin, Zongjie Huang, Peng Pan, Yueyue Pan, Runze Zuo, Yu Sun and Xinyu Liu

Micromachines 2022, 13(12), 2232; https://doi.org/10.3390/mi13122232 - 16 Dec 2022

Cited by 12 | Viewed by 4619

Abstract

Low-cost diagnostic tools for point-of-care immunoassays, such as the paper-based enzyme-linked immunoassay (ELISA), have become increasingly important, especially so in the recent COVID-19 pandemic. ELISA is the gold-standard antibody/antigen sensing method. This paper reports an easy-to-fabricate nitrocellulose (NC) paper plate, coupled with a [...] Read more.

Low-cost diagnostic tools for point-of-care immunoassays, such as the paper-based enzyme-linked immunoassay (ELISA), have become increasingly important, especially so in the recent COVID-19 pandemic. ELISA is the gold-standard antibody/antigen sensing method. This paper reports an easy-to-fabricate nitrocellulose (NC) paper plate, coupled with a desktop scanner for ELISA, which provides a higher protein immobilization efficiency than the conventional cellulose paper-based ELISA platforms. The experiments were performed using spiked samples for the direct ELISA of rabbit IgG with a limit of detection (LOD) of 1.016 μg/mL, in a measurement range of 10 ng/mL to 1 mg/mL, and for the sandwich ELISA of sperm protein (SP-10) with an LOD of 88.8 ng/mL, in a measurement range of 1 ng/mL to 100 μg/mL. The described fabrication method, based on laser-cutting, is a highly flexible one-step laser micromachining process, which enables the rapid production of low-cost NC paper-based multi-well plates with different sizes for the ELISA measurements. Full article

(This article belongs to the Topic Advances in Microfluidics and Lab on a Chip Technology)

► Show Figures

Figure 1

10 pages, 3056 KiB

Open AccessArticle

Microfluidic Device to Manipulate 3D Human Epithelial Cell-Derived Intestinal Organoids

by Miki Matsumoto, Yuya Morimoto, Toshiro Sato and Shoji Takeuchi

Micromachines 2022, 13(12), 2082; https://doi.org/10.3390/mi13122082 - 26 Nov 2022

Cited by 4 | Viewed by 2881

Abstract

In this study, we propose a microfluidic organoid-trapping device used to immobilize human intestinal organoids and apply fluidic stimuli to them. The proposed device has a microchannel with a trapping region with wall gaps between the channel walls and the bottom surface, and [...] Read more.

In this study, we propose a microfluidic organoid-trapping device used to immobilize human intestinal organoids and apply fluidic stimuli to them. The proposed device has a microchannel with a trapping region with wall gaps between the channel walls and the bottom surface, and a constriction to clog the organoids in the channel. Since the introduced culture medium escapes from the gap, organoids can be cultured without excessive deformation by hydrostatic pressure. Owing to the characteristics of the organoid-trapping device, we succeeded in trapping human intestinal organoids in the channel. Furthermore, to demonstrate the applicability of the device for culturing intestinal organoids, we induced organoid fusion to form large organoids by aligning the organoids in the channel and applying fluidic shear stress to the organoids to regulate their surface structures. Therefore, we believe that organoid-trapping devices will be useful for investigating organoids aligned or loaded with fluidic stimulation. Full article

(This article belongs to the Topic Advances in Microfluidics and Lab on a Chip Technology)

► Show Figures

Figure 1

12 pages, 2288 KiB

Open AccessCommunication

A Bench-Top Approach for Isolation of Single Antibody Producing Chinese Hamster Ovary (CHO) Cells Using a Microwell-Based Microfluidic Device

by Salma Fuadiyah, Kittipat Chotchindakun, Rungrueang Phatthanakun, Panwong Kuntanawat and Montarop Yamabhai

Micromachines 2022, 13(11), 1939; https://doi.org/10.3390/mi13111939 - 10 Nov 2022

Cited by 2 | Viewed by 2444

Abstract

Genetically-modified monoclonal cell lines are currently used for monoclonal antibody (mAbs) production and drug development. The isolation of single transformed cells is the main hindrance in the generation of monoclonal lines. Although the conventional limiting dilution method is time-consuming, laborious, and skill-intensive, high-end [...] Read more.

Genetically-modified monoclonal cell lines are currently used for monoclonal antibody (mAbs) production and drug development. The isolation of single transformed cells is the main hindrance in the generation of monoclonal lines. Although the conventional limiting dilution method is time-consuming, laborious, and skill-intensive, high-end approaches such as fluorescence-activated cell sorting (FACS) are less accessible to general laboratories. Here, we report a bench-top approach for isolating single Chinese hamster ovary (CHO) cells using an adapted version of a simple microwell-based microfluidic (MBM) device previously reported by our group. After loading the cell suspension to the device, the electrostatically trapped cells can be viewed under a microscope and transferred using a micropipette for further clone establishment. Compared to the conventional method, the invented approach provided a 4.7-fold increase in the number of single cells isolated per round of cell loading and demonstrated a 1.9-fold decrease in total performing time. Additionally, the percentage of correct single-cell identifications was significantly improved, especially in novice testers, suggesting a reduced skill barrier in performing the task. This novel approach could serve as a simple, affordable, efficient, and less skill-intensive alternative to the conventional single-cell isolation for monoclonal cell line establishment. Full article

(This article belongs to the Topic Advances in Microfluidics and Lab on a Chip Technology)

► Show Figures

Figure 1

8 pages, 2057 KiB

Open AccessArticle

Real-Time Tunable Optofluidic Splitter via Two Laminar Flow Streams in a Microchannel

by Sha Xiong, Wenshuo Mai and Xiaofang Huang

Micromachines 2022, 13(10), 1758; https://doi.org/10.3390/mi13101758 - 17 Oct 2022

Viewed by 1645

Abstract

This paper reports a tunable optofluidic splitter in which the incident light is split via refraction and reflection at the interface between two laminar flows in a microchannel but with different refractive indices. A Y-junction microchannel is used to demonstrate the continuous tuning [...] Read more.

This paper reports a tunable optofluidic splitter in which the incident light is split via refraction and reflection at the interface between two laminar flows in a microchannel but with different refractive indices. A Y-junction microchannel is used to demonstrate the continuous tuning of the splitting ratio of optical power by smooth adjustment of the ratio of two flow rates. In addition, it has achieved the tuning of split angle from 5° to 19° by the control of the refractive index contrast. The dynamic response gives a fastest switching frequency of 1.67 Hz between the “wave-guiding” and “splitting” status. Full article

(This article belongs to the Topic Advances in Microfluidics and Lab on a Chip Technology)

► Show Figures

Figure 1

13 pages, 3765 KiB

Open AccessArticle

A Glass–Ultra-Thin PDMS Film–Glass Microfluidic Device for Digital PCR Application Based on Flexible Mold Peel-Off Process

by Yanming Xia, Xianglong Chu, Caiming Zhao, Nanxin Wang, Juan Yu, Yufeng Jin, Lijun Sun and Shenglin Ma

Micromachines 2022, 13(10), 1667; https://doi.org/10.3390/mi13101667 - 4 Oct 2022

Cited by 4 | Viewed by 3823

Abstract

The microfluidic device (MFD) with a glass–PDMS–glass (G-P-G) structure is of interest for a wide range of applications. However, G-P-G MFD fabrication with an ultra-thin PDMS film (especially thickness less than 200 μm) is still a big challenge because the ultra-thin PDMS film [...] Read more.

The microfluidic device (MFD) with a glass–PDMS–glass (G-P-G) structure is of interest for a wide range of applications. However, G-P-G MFD fabrication with an ultra-thin PDMS film (especially thickness less than 200 μm) is still a big challenge because the ultra-thin PDMS film is easily deformed, curled, and damaged during demolding and transferring. This study aimed to report a thickness-controllable and low-cost fabrication process of the G-P-G MFD with an ultra-thin PDMS film based on a flexible mold peel-off process. A patterned photoresist layer was deposited on a polyethylene terephthalate (PET) film to fabricate a flexible mold that could be demolded softly to achieve a rigid structure of the glass–PDMS film. The thickness of ultra-thin patterned PDMS could reach less than 50 μm without damage to the PDMS film. The MFD showcased the excellent property of water evaporation inhibition (water loss < 10%) during PCR thermal cycling because of the ultra-thin PDMS film. Its low-cost fabrication process and excellent water evaporation inhibition present extremely high prospects for digital PCR application. Full article

(This article belongs to the Topic Advances in Microfluidics and Lab on a Chip Technology)

► Show Figures

Figure 1

15 pages, 5020 KiB

Open AccessArticle

Computational Fluid Dynamics Study of the Effects of Temperature and Geometry Parameters on a Virtual Impactor

by Ruofei Wang, Heng Zhao, Jiaqi Li and Xingbo Wang

Micromachines 2022, 13(9), 1477; https://doi.org/10.3390/mi13091477 - 5 Sep 2022

Cited by 8 | Viewed by 2276

Abstract

The virtual impactor, as an atmospheric particle classification chip, provides scientific guidance for identifying the characteristics of particle composition. Most of the studies related to virtual impactors focus on their size structure design, and the effect of temperature in relation to the dynamic [...] Read more.

The virtual impactor, as an atmospheric particle classification chip, provides scientific guidance for identifying the characteristics of particle composition. Most of the studies related to virtual impactors focus on their size structure design, and the effect of temperature in relation to the dynamic viscosity on the cut−off diameter is rarely considered. In this paper, a new method that can reduce the cut−off particle size without increasing the pressure drop is proposed. Based on COMSOL numerical simulations, a new ultra−low temperature virtual impactor with a cut−off diameter of 2.5 μm was designed. A theoretical analysis and numerical simulation of the relationship between temperature and the performance of the virtual impactor were carried out based on the relationship between temperature and dynamic viscosity. The effects of inlet flow rate (Q), major flow channel width (S), minor flow channel width (L) and split ratio (r) on the performance of the virtual impactor were analyzed. The collection efficiency curves were plotted based on the separation effect of the new virtual impactor on different particle sizes. It was found that the new ultra−low temperature approach reduced the PM2.5 cut−off diameter by 19% compared to the conventional virtual impactor, slightly better than the effect of passing in sheath gas. Meanwhile, the low temperature weakens Brownian motion of the particles, thus reducing the wall loss. In the future, this approach can be applied to nanoparticle virtual impactors to solve the problem of their large pressure drop. Full article

(This article belongs to the Topic Advances in Microfluidics and Lab on a Chip Technology)

► Show Figures

Figure 1

14 pages, 2938 KiB

Open AccessArticle

Low Cost, Ease-of-Access Fabrication of Microfluidic Devices Using Wet Paper Molds

by Raviraj Thakur and Gene Y. Fridman

Micromachines 2022, 13(9), 1408; https://doi.org/10.3390/mi13091408 - 27 Aug 2022

Cited by 5 | Viewed by 2513

Abstract

Rapid prototyping methods enable the widespread adoption of microfluidic technologies by empowering end-users from non-engineering disciplines to make devices using processes that are rapid, simple and inexpensive. In this work, we developed a liquid molding technique to create silicone/PDMS microfluidic devices by replica [...] Read more.

Rapid prototyping methods enable the widespread adoption of microfluidic technologies by empowering end-users from non-engineering disciplines to make devices using processes that are rapid, simple and inexpensive. In this work, we developed a liquid molding technique to create silicone/PDMS microfluidic devices by replica molding. To construct a liquid mold, we use inexpensive adhesive-backed paper, an acetate backing sheet, and an off-the-shelf digital cutter to create paper molds, which we then wet with predetermined amounts of water. Due to the immiscibility of water and PDMS, mold patterns can be effectively transferred onto PDMS similarly to solid molds. We demonstrate the feasibility of these wet paper molds for the fabrication of PDMS microfluidic devices and assess the influence of various process parameters on device yield and quality. This method possesses some distinct benefits compared to conventional techniques such as photolithography and 3D printing. First, we demonstrate that the shape of a channel’s cross-section may be altered from rectangular to semicircular by merely modifying the wetting parameters. Second, we illustrate how electrical impedance can be utilized as a marker for inspecting mold quality and identifying defects in a non-invasive manner without using visual tools such as microscopes or cameras. As a proof-of-concept device, we created a microfluidic T-junction droplet generator to produce water droplets in mineral oil ranging in size from 1.2 µL to 75 µL. We feel that this technology is an excellent addition to the microfluidic rapid prototyping toolbox and will find several applications in biological research. Full article

(This article belongs to the Topic Advances in Microfluidics and Lab on a Chip Technology)

► Show Figures

Figure 1

12 pages, 2452 KiB

Open AccessArticle

Fabrication of Microfluidic Tesla Valve Employing Femtosecond Bursts

by Deividas Andriukaitis, Rokas Vargalis, Lukas Šerpytis, Tomas Drevinskas, Olga Kornyšova, Mantas Stankevičius, Kristina Bimbiraitė-Survilienė, Vilma Kaškonienė, Audrius Sigitas Maruškas and Linas Jonušauskas

Micromachines 2022, 13(8), 1180; https://doi.org/10.3390/mi13081180 - 26 Jul 2022

Cited by 14 | Viewed by 3738

Abstract

Expansion of the microfluidics field dictates the necessity to constantly improve technologies used to produce such systems. One of the approaches which are used more and more is femtosecond (fs) direct laser writing (DLW). The subtractive model of DLW allows for directly producing [...] Read more.

Expansion of the microfluidics field dictates the necessity to constantly improve technologies used to produce such systems. One of the approaches which are used more and more is femtosecond (fs) direct laser writing (DLW). The subtractive model of DLW allows for directly producing microfluidic channels via ablation in an extremely simple and cost-effective manner. However, channel surface roughens are always a concern when direct fs ablation is used, as it normally yields an RMS value in the range of a few µm. One solution to improve it is the usage of fs bursts. Thus, in this work, we show how fs burst mode ablation can be optimized to achieve sub-µm surface roughness in glass channel fabrication. It is done without compromising on manufacturing throughput. Furthermore, we show that a simple and cost-effective channel sealing methodology of thermal bonding can be employed. Together, it allows for production functional Tesla valves, which are tested. Demonstrated capabilities are discussed. Full article

(This article belongs to the Topic Advances in Microfluidics and Lab on a Chip Technology)

► Show Figures

Figure 1

11 pages, 1926 KiB

Open AccessArticle

A Comparative Study on Optofluidic Fenton Microreactors Integrated with Fe-Based Materials for Water Treatment

by Lijun Liu, Ning Wang, Liang Wan, Chao Zhao, Kunpeng Niu, Dajuan Lyu, Zhaolong Liao and Biao Shui

Micromachines 2022, 13(7), 1125; https://doi.org/10.3390/mi13071125 - 16 Jul 2022

Cited by 1 | Viewed by 1874

Abstract

The catalysts employed in catalytic reactors greatly affect the reaction efficiency of the reaction system and the reactor’s performance. This work presents a rapid comparative study on three kinds of Fe-based materials integrated into an optofluidic Fenton reactor for water treatment. The Fe-based [...] Read more.

The catalysts employed in catalytic reactors greatly affect the reaction efficiency of the reaction system and the reactor’s performance. This work presents a rapid comparative study on three kinds of Fe-based materials integrated into an optofluidic Fenton reactor for water treatment. The Fe-based sheets (FeSiB, FeNbCuSiB, and FeNi) were respectively implanted into the reaction chamber to degrade the organic dyes with the assistance of H₂O₂. In the experiment, by adjusting the hydrogen peroxide concentration, flow rate, and light irradiation, the applicable conditions of the Fe-based materials for the dye degradation could be evaluated quickly to explore the optimal design of the Fenton reaction system. The results indicated that FeNi (1j85) exhibits excellent degradability in the microreactor, the reaction rate can reach 23.4%/s at the flow rate of 330 μL/min, but its weak corrosion resistance was definitely demonstrated. Although the initial degradability of the microreactor by using FeNbCuSiB (1k107) was not as good as that of 1j85, it increased after being reused several times instead, and the degradation efficiency reached >98% after being reused five times. However, the FeSiB (1k101) material shows the worst degradability and recycling. Therefore, in contrast, 1k107 has the greatest potential to be used in Fenton reactors for practical water treatment. Full article

(This article belongs to the Topic Advances in Microfluidics and Lab on a Chip Technology)

► Show Figures

Figure 1

12 pages, 4791 KiB

Open AccessArticle

Research on Intelligent Distribution of Liquid Flow Rate in Embedded Channels for Cooling 3D Multi-Core Chips

by Jian Zhang, Zhihui Xie, Zhuoqun Lu, Penglei Li and Kun Xi

Micromachines 2022, 13(6), 918; https://doi.org/10.3390/mi13060918 - 9 Jun 2022

Cited by 12 | Viewed by 2557

Abstract

A numerical simulation model of embedded liquid microchannels for cooling 3D multi-core chips is established. For the thermal management problem when the operating power of a chip changes dynamically, an intelligent method combining BP neural network and genetic algorithm is used for distribution [...] Read more.

A numerical simulation model of embedded liquid microchannels for cooling 3D multi-core chips is established. For the thermal management problem when the operating power of a chip changes dynamically, an intelligent method combining BP neural network and genetic algorithm is used for distribution optimization of coolant flow under the condition with a fixed total mass flow rate. Firstly, a sample point dataset containing temperature field information is obtained by numerical calculation of convective heat transfer, and the constructed BP neural network is trained using these data. The “working condition–flow distribution–temperature” mapping relationship is predicted by the BP neural network. The genetic algorithm is further used to optimize the optimal flow distribution strategy to adapt to the dynamic change of power. Compared with the commonly used uniform flow distribution method, the intelligently optimized nonuniform flow distribution method can further reduce the temperature of the chip and improve the temperature uniformity of the chip. Full article

(This article belongs to the Topic Advances in Microfluidics and Lab on a Chip Technology)

► Show Figures

Figure 1
