Search Results (45)

This paper presents a new power delivery architecture to bring AC distribution voltages to core levels for computing loads using only two conversion stages with new converter topologies to potentially replace the traditional four-stage structure in the development of new data centers. This paper also includes new converters as solutions to the proposed two stages. A new switched capacitor (SC)-based AC-DC converter is proposed for the first stage and demonstrated for an intermediate bus with 90 V–110 VAC to 48–60 VDC conversion and power factor correction. The second stage also includes an SC-based hybrid converter with multi-phase operation suitable for power delivery for core voltages of up to ~1 V with a high current density. This work also reports a new phase sequence for the second stage for an extended output voltage range. Individually, the first stage was measured at 96.1% peak efficiency for output currents ranging from 0 to 4.5 A, while the second stage achieved 90.7% peak efficiency with a load range of 0–220 A at 1V. The measured peak power densities were 73 W/in³ for the first stage and 2020 W/in³ for the second stage. In combination, the direct conversion from ~110 VAC to 1 VDC led to a peak efficiency of 84.1% at 50 A, and this setup has been tested with output currents of up to 160 A, where the efficiency was 73.5%. Full article

The aim of the article is to determine the control range of a multiphase squirrel cage induction generator with more than three stator phases, operating in a wide range of driving speeds. The generator produces an output DC voltage using a multiphase converter operating as a PWM rectifier. The entire speed range is divided into intervals in which the sequence of stator phase voltages and, in effect, the number of pole pairs, is changed. In each interval, the output voltage is regulated by the frequency and amplitude of the stator voltages causing the highest possible power efficiency of the generator. The system can be scalar controlled or regulated using field orientation. Generator characteristics are calculated based on the set of steady-state equations derived from differential equations describing the multiphase induction machine. The calculation results are compared with simulations and with the steady-state measurement of the vector-controlled nine-phase generator. Recognizing the reliability of the obtained results, calculations are performed for a twelve-phase generator, obtaining satisfactory efficiency from 70% to 85% in the generator speed range from 0.2 to 1.0 of the assumed reference speed of 314 rad/s. The generator producing DC voltage can charge an electrical energy storage system or can be used directly to provide electrical power. This solution is not patented. Full article

To deal with the interphase circulating-current problem of modular multilevel converters (MMCs) in multiphase wind power systems, a cooperative circulating-current suppression strategy based on a second-order generalized integrator (SOGI) and passivity-based control–integral sliding mode control (PBC-ISMC) is proposed in this paper. Firstly, a multiphase permanent magnet direct-drive wind power system topology without a step-up transformer is established. On this basis, SOGI is utilized to construct a circulating current extractor, which is utilized to accurately extract the double-frequency component in the circulating current, and, at the same time, effectively filter out the DC components and high-frequency noise. Secondly, passivity-based control (PBC), with its fast energy dissipation, and integral sliding mode control (ISMC), with its strong robustness, are combined to construct the PBC-ISMC circulating-current suppressor, which realizes the nonlinear decoupling and dynamic immunity of the circulating-current model. Finally, simulation results demonstrate that the proposed strategy significantly reduces the harmonic content of the circulating current, optimizes both the bridge-arm current and output current, and achieves superior suppression performance and dynamic response compared to traditional methods, thereby effectively enhancing system power quality and operational reliability. Full article

This paper introduces a high-conversion ratio multiphase nonisolated converter built from generic LC cells. The unique architecture that hinges on a generic capacitor inductor switching module enables the high modularity of the topology, providing a quick extension of the converter design in an interleaved configuration for lower ripple and higher current output. The generic module comprises the basic power components of a nonisolated DC–DC converter, where the unique interaction between the capacitor and the inductor results in a soft charging operation, which curbs the losses of the converter, and contributes to a higher efficiency. Additional features of the new converter include a significantly extended effective duty ratio, and a lower voltage stress on the switches, a very high output current, and architecture-inherent output current sharing that balances the loading between the phases. In addition, a power extension using a paralleling and interleaving approach is presented to provide higher output current capabilities. Simulation and experimental results of a modular interleaved three-phase prototype demonstrate an excellent proof of concept and agree well with the theoretical analyzes developed in this study. Full article

While DC/DC converters for water electrolysis systems have been widely investigated, they inherently face a critical compromise between wide voltage regulation capabilities and dynamic response characteristics. This study is based on a two-stage hybrid topology (TSIB-TPLLC) that synergistically combines a two-phase interleaved buck converter with a three-phase LLC resonant converter to resolve this challenge. The first-stage interleaved buck converter enables wide-range voltage regulation while reducing input current ripple and minimizing intermediate bus capacitance through phase-interleaved operation. The subsequent three-phase LLC stage operates at a fixed resonant frequency, achieving inherent output current ripple suppression through multi-phase cancellation while maintaining high conversion efficiency. A dual-loop control architecture incorporating linear active disturbance rejection control (LADRC) with PI compensation is developed to improve transient response compared to conventional PI-based methods. Finally, a 1.2 kW experimental prototype with an input voltage of 250 V and an output voltage of 24 V demonstrates the converter’s operational feasibility and enhanced steady-state/transient performance, confirming its suitability for hydrogen production applications. Full article

Multiphase DC/DC power converter architectures have recently been investigated for powering the superconducting electromagnets in the High-Luminosity (HL) upgrade of the Large Hadron Collider (LHC) at CERN, targeting high-performance figures and reliability. In terms of control, a master–slave voltage/current regulation configuration was previously proposed by the authors as an alternative to other well-known cascaded options. In this work, fault-tolerant features (i.e., diagnosis and reconfiguration under open-circuit switch faults) are incorporated into the aforementioned proposal. These features are highly desirable, as physics experiments—which can last for several hours—should not be interrupted in the event of a recoverable fault in the powering system. Simulation and experimental results are provided, demonstrating the correctness of the proposed fault-tolerant scheme. Full article

A matrix converter (MC) converts an AC source voltage into a variable-voltage variable-frequency AC output voltage (direct AC-AC) without an intermediate DC-link capacitance. By eliminating the traditional DC-link capacitor, MCs can achieve higher power densities and reliability when compared to conventional AC-DC-AC converters. MCs also offer the following characteristics: total semiconductor solution, sinusoidal input and output currents, bidirectional power flow and controllable input power factor. This paper reviews the history, recent developments and commercialization of MCs and discusses several technical requirements and challenges, including bidirectional switches, wide bandgap (WBG) opportunities using GaN and SiC, overvoltage protection, electromagnetic interference (EMI) and ride-through in motor drive applications. MC design solutions and operation are discussed, including a comparison of control and modulation techniques as well as the detailed development of space vector modulation (SVM) to provide a deep insight into the control implementation and results. The paper concludes with compelling motor drive innovation opportunities made possible by advanced MCs including fully integrated and multiphase systems. For conventional MCs, size reductions of 30% are reported, as well as efficiencies of 98% and low input current total harmonic distortion of 3–5%. Full article

In this study, a current-equalization technology utilizing a variable-capacitance technique for a multiphase inductor–inductor–capacitor (LLC) converter is studied. Accordingly, the proposed method involves adjusting the resonant capacitance of the LLC resonant converter to balance the currents between phases. This is achieved primarily by biasing ferroelectric multilayer ceramic capacitors (MLCCs) through a step-down circuit and a common-mode bias structure. These ferroelectric MLCCs serve as the resonant elements, allowing for variable capacitance by leveraging capacitance sensitivity to their trans voltages. This approach provides additional control flexibility to the resonant circuit. Furthermore, since each phase operates independently, the circuit can be scaled to accommodate any number of phases. Moreover, all switches in the circuit have zero-voltage switching (ZVS) turn-on, minimizing switching losses. This study initially analyzes and evaluates the proposed common-mode bias variable capacitance technique and the corresponding operational principles. Subsequently, a two-phase LLC experimental circuit based on a field-programmable gate array (FPGA) digital controller is utilized to assess current equalization and efficiency. That is to say, this experimentation aims to validate the effectiveness of the current-equalization variable-capacitance technique in an LLC resonant converter. Full article

This work introduces a generalized version of the pulse width modulation (PWM) switch model applied in the small-signal modeling of converters based on the multistate switching cell (MSSC) operating in discontinuous conduction mode (DCM). It consists of extending the concept formerly introduced by Vorperian for the representation of multiphase converters in DCM, yielding a circuit-based approach that does not rely on matrix manipulations unlike state-space averaging (SSA). The derived dc and ac models are valid for any number of switching states and any operating region defined in terms of the duty cycle, thus allowing for determining the voltage gain and distinct transfer functions. A thorough discussion of results is presented to demonstrate the applicability of the derived models to represent distinct configurations of the MSSC. Full article

This research explores an improved operation of a recently studied converter, the so-called two-phase sixth-order boost converter (2P6OBC). The converter consists of a symmetric design of power stations followed by an LC filter; its improved operation incorporates an asymmetric pulse width modulation (PWM) scheme for transistor switching, sometimes known as an interleaved PWM approach. The new operation leads to improved performance for the 2P6OBC. Along with studying the 2P6OBC, one of the contributions of this research is providing design equations for the converter and comparing it versus the interleaved (or multiphase) boost converter, known for its competitiveness and advantages; the single-phase boost topology was also included in the comparison. The comparison consisted of a design scenario where all converters must achieve the same power conversion with an established maximum switching ripple, and then the stored energy in passive components is compared. Although the 2P6OBC requires a greater number of components, the total amount of stored energy is smaller. It is known that the stored energy is related to the size of the passive components. Still, the article includes a discussion of this topic. The new operation of the converter offers more streamlined, cost-effective, and efficient alternatives for a range of applications within power electronics. The final design of the 2P6OBC required only 68% of the stored energy in inductors compared to the multiphase boost converter, and 60% of the stored energy in capacitors. This result is outstanding, considering that the multiphase boost converter is a very competitive topology. Experimental results are provided to validate the proposed concept. Full article

This paper presents a voltage control system for multiphase squirrel-cage induction generators operating at a high variability of speed and variable load. Field-oriented vector control was used with a change in the sequence of the stator phase currents what changes the number of poles of the magnetic field produced by nine-phase stator winding. At low speeds, the current sequence is changed so that the number of poles increases allowing for the desired voltage to be obtained with greater efficiency. The task of the automatic control system was to control the DC voltage to a desired value at the output of the multiphase PWM converter. This is an alternative control method to the scalar control of voltage and frequency presented in a previous work. The control method and parameters of the automatic control system result from the mathematical model of the multiphase induction machine. The results of the laboratory tests were compared with the effects of the operation of the same nine-phase scalar controlled generator. Full article

The main objective of this article is to propose a rational methodology for designing multi-phase step-down DC-DC converters, which can find applications both in engineering practice and in power electronics education. This study discusses the main types of losses in the multi-phase synchronous buck converter circuit (transistors’ conduction losses, high-side MOSFET’s switching losses, reverse recovery losses in the body diode, dead time losses, output capacitance losses in the MOSFETs, gate charge losses in MOSFETs, conduction losses in the inductor, and losses in the input and output capacitors) and provides analytical dependencies for their calculation. Based on the control examples for applications characterized by low voltage and high output current, the multi-phase buck converter’s output and input current ripples are analyzed and compared analytically and graphically (3D plots). Furthermore, graphical results of the converter efficiency at different numbers of phases (N = 2, 4, 6, 8, and 12) are presented. An analysis of the impact of various parameters on power losses is conducted. Thus, a discussion on assessing the factors influencing the selection of the number of phases in the multi-phase synchronous buck converter is presented. The proposed systematized approach, which offers a fast and accurate method for calculating power losses and overall converter efficiency, reduces the need for extensive preliminary computational procedures and achieves optimized solutions. Simulation results for investigating power losses in 8-phase multi-phase synchronous buck converters are also presented. The relative error between analytical and simulation results does not exceed 4%. Full article

Raising the electrification ratio to 100% is still a formidable challenge in Indonesia, especially in the remote areas of the eastern part of the archipelago. A DC microgrid system is one of the most viable solutions to increase the electricity supply in remote areas, taking advantage of various renewable energy sources that are located near the rural load centers. A DC–DC power converter for a rural DC microgrid system needs to have a high voltage gain to facilitate the power conversion from low-voltage PV output to a high-voltage DC microgrid bus, a very low input ripple current to help maintain the PV or battery lifetime, and be highly modular for ease of transport and assembly. Many topologies have been proposed to obtain high voltage gain, very low ripple current, and modularity. However, they usually use either bulky and lossy magnetic components, are sensitive to component parameter variance and need special voltage-balancing techniques, or have different component ratings for their multilevel configuration which weakens the modularity aspect. This paper proposes a new modular multilevel DC–DC converter that is very suitable for rural DC microgrid applications based on a modified buck–boost topology. The proposed converter is easily stackable to achieve high voltage gain and does not require any voltage balancing techniques, thus enhancing the modularity characteristics and simplifying its control method. Moreover, the ripple current can be reduced by employing a multiphase configuration. This converter can also facilitate bidirectional power flow to serve as a battery charger/discharger. A comprehensive analysis of voltage gain and ripple current are presented to explain the inner workings of this converter. Finally, the performance of this converter is verified through simulation and experiment, showing the converter’s modularity, bidirectional power capability, and potential to achieve voltage gain and ripple-current requirements of the DC microgrid system. Full article

Multiphase drives have received a lot of interest because of their several features over traditional three-phase systems for high-power applications. Pulse-width modulation (PWM) approaches are necessary to regulate the supply for multiphase ac drives. As a result, it is vital to continually improve the modulation and control approaches used to upgrade output power converters’ quality. This paper offers a comparative analysis of the 2L + 2M and 6L space vector pulse-width modulation (SVPWM) techniques applied to a five-phase two-level voltage source inverter (VSI) fed an inductive (R-L) load. The comparative evaluation is based on measuring the inverter switching losses, the total harmonic distortion (THD) values, and the common mode voltage (CMV) under different operation scenarios. A system model is carried out by MATLAB/Simulink. An experimental prototype is constructed in the lab to validate the theoretical analysis. Simulation results for the system based on the two SVPWM techniques are obtained at different modulation indices and different output frequencies and are confirmed by the experimental results. It has been found that the peak-to-peak CMV of the 6L method is 80% lower than that of the 2L + 2M method. Moreover, 6L SVPWM offers better DC-link utilization compared to 2L + 2M SVPWM. Full article

Over the past few years, there have been significant advancements in Microgrid (MG) systems, particularly in the field of power electronics. These advancements aim to address the needs of the grid and loads, while integrating low-voltage, non-linear, and highly sensitive power sources, such as solar PV modules, batteries, and supercapacitors. It is crucial to select the appropriate converter configuration and power converters in MG systems, as they greatly impact their optimal performance. To achieve the best results, numerous architectures and converter configurations have been suggested for integrating different energy sources. As a result, a considerable number of research articles have been published, necessitating a thorough review. This article continues studies of Part I and presents a comprehensive overview of various architectures based on the arrangement of different sources and provides a detailed analysis and discussion of these architectures. This article covers thirty-three different categories of DC-DC converters, both isolated and non-isolated. These converters are divided into subcategories, such as conventional type, switched-capacitor type, soft-switching type, multi-phase type, and multilevel type. The article also evaluates the suitability of these topologies based on factors such as high conversion gain, power decoupling, efficiency, isolation, power handling capabilities, and compact design. The critical examination and comparative study presented in this work can be valuable for industry professionals and academics in selecting the most suitable architectural and power converter topologies for optimal performance. Full article
