The purpose of this paper is to study the shear performance of reinforced concrete corbels under a synergistic change in the main stirrup inclination angle to explore the synergistic mechanism of the main reinforcement and the stirrup inclination angle, and to evaluate the applicability of existing design specifications. The shear performance test was carried out by designing RC corbel specimens with an inclination angle of the main reinforcement and stirrup. The test results show that a 15° inclination scheme significantly improves the shear performance: the yield load is increased by 28.3%, the ultimate load is increased by 23.6%, the strain of the main reinforcement of the 15° specimen is reduced by 51.3%, the stirrup shows a delayed yield (the yield load is increased by 11.6%) and lower strain level (250 kN is reduced by 23.7%), and the oblique reinforcement optimizes the internal force transfer path and delays the reinforcement yield. A CDP finite element model was established for verification, and the failure mode and crack propagation process of the corbel were accurately reproduced. The prediction error of ultimate load was less than 2.27%. Based on the test data, the existing standard method is tested and a modified formula of the triangular truss model based on the horizontal inclination angle of the tie rod is proposed. The prediction ratio of the bearing capacity is highly consistent with the test value. A function correlation model between the inclination angle of the steel bar and the bearing capacity is constructed, which provides a quantitative theoretical tool for the optimal design of RC corbel inclination parameters. Full article

Reinforced concrete (RC) deep beams constructed with low-strength concrete are susceptible to sudden splitting failures in the strut region due to shear–compression stresses. To mitigate this vulnerability, various strengthening techniques, including steel plates, fiber-reinforced polymer sheets, and cementitious composites, have been explored to confine the strut area. This study investigates the structural performance of RC deep beams with low-strength concrete, strengthened externally using an Engineered Cementitious Composite (ECC) layer. To ensure effective confinement and uniform shear distribution, shear reinforcement was provided at equal intervals with configurations of zero, one, and two vertical shear reinforcements. Four-point bending tests revealed that the ECC layer significantly enhanced the shear capacity, increasing load-carrying capacity by 51.6%, 54.7%, and 46.7% for beams with zero, one, and two shear reinforcements, respectively. Failure analysis through non-linear finite element modeling corroborated experimental observations, confirming shear–compression failure characterized by damage in the concrete struts. The strut-and-tie method, modified to incorporate the tensile strength of ECC and shear reinforcement actual stress values taken from the FE analysis, was used to predict the shear capacity. The predicted values were within 10% of the experimental results, underscoring the reliability of the analytical approach. Overall, this study demonstrates the effectiveness of ECC in improving shear performance and mitigating strut failure in RC deep beams made with low-strength concrete. Full article

This study investigates the issues of non-unique model configurations and insufficient guidance for reinforcement design encountered when applying the strut-and-tie model (STM) method to reinforced concrete deep beams with openings. Using concrete deep beam specimens with three openings as a case study, the topology optimization method was employed to establish the initial STM, which was subsequently refined through crack propagation simulation technology to develop the final optimized STM for guiding reinforcement design. Experimental investigations and comparative analyses with existing literature demonstrate that the proposed approach offers significant advantages in controlling initial concrete cracking, improving structural load-bearing capacity, and reducing steel reinforcement consumption for such perforated deep beams designed with this optimized STM methodology. Full article

In this study, seven wet joint specimens of contact U-bars are designed in order to evaluate the flexural behavior of the wet joints in precast concrete slabs through four-point bending tests. This study investigates the effects of lap length, wet joint width, and water stop strips on the flexural behavior. The test results show that the ultimate bending capacity of the specimen with a lap length of 240 mm is 13.4% and 17.7% higher than that of the specimens with 160 mm and 80 mm. Water stop strips weaken the ductility of the specimen. The numerical model is established in ABAQUS finite element software and verified by the experimental results. Based on both test outcomes and finite element analysis, this study analyzes the deterioration effect of U-bars on the concrete within wet joints and proposes a calculation formula for flexural bending capacity that accounts for this deterioration. The proposed formula is shown to effectively predict the flexural capacity, since the theoretical predictions and the test results differ by less than 10%. Full article

The connection between a prefabricated reinforced concrete column and a pocket foundation is a case treated from a general perspective in the European Standard named EN 1992-1-1 (EC2), and when the structural engineer deals with the dimensioning or verification of the connection, he must tackle several unknowns. The present work aims to fill in the missing information by presenting detailed calculation models based on the strut-and-tie method for four widely used pocket foundations: a pedestal pocket foundation with smooth, rough or keyed internal walls and a pad foundation with a pocket possessing keyed internal walls. In establishing the strut-and-tie models and writing the equation for the internal forces, we consider several standards (EC2, NBR 9062 and DIN 1045-1), good practices (from Austria, England, Germany and Romania) and numerous experimental and numerical investigations. Additionally, detailed design prescriptions applicable to seismic areas are given. This manuscript covers a wide range of design and technology aspects necessary for designing and building columns connected with pocket foundations, information for which is shown only in fragmented form or partially in other publications. Afterward, as a case study, a pocket foundation is designed in all four variations, with the structural design particularities, similitudes and differences being pointed out. Finally, to conclude, we mention the advantages and disadvantages of pocket foundations with respect to the type of internal wall surface used. Quantifiable data based on the case study undertaken are available. Full article

This study aimed to investigate the shear performance of reinforced concrete corbels and to evaluate the accuracy and safety of the Chinese code GB 50010-2010’s triangular truss model and the American code ACI 318-19’s strut-and-tie model under various design parameters with a specified design load. A total of 22 corbel specimens with different dimensions and reinforcement configurations were designed and simulated using the finite element software ABAQUS 2020, incorporating the microplane M7 material model, which was validated against experimental data. The findings reveal that for corbels with high-strength concrete or larger shear spans, the Chinese code offers a higher safety margin. Conversely, the safety margin according to the American code initially increases and then decreases with the enhancement of concrete strength, while changes in the shear span have an insignificant impact on the safety margin, which tends to decrease as the shear span increases. Additionally, the inclusion of stirrup reinforcement significantly improves the load-bearing capacity of corbels, with an increase ranging from 15% to 46% compared to those without stirrups. Full article

Anchor bolts are often used in nuclear power plants to connect equipment and equipment foundations. Under a severe earthquake, tensile breakout failure is prone to occur in the anchor bolts. As the total amount of installed machines rises, the inertial forces transferred to the anchor bolts under seismic loads also increase significantly. Therefore, the capacity is no longer satisfied by concrete alone, and specialized supplementary reinforcement needs to be installed around the bolts. The study analyzed the tensile behavior of anchor bolts in foundations with supplementary reinforcement experimentally. A total of 16 single-headed anchors in RC foundations with various diameters, yield strengths, and forms of supplementary reinforcement were tested under monotonic tensile loading. The results show that supplemental tie bars and supplemental U-shaped bars, respectively, rely on the bond with the concrete and their own tensile strength to increase the tensile breakout capacity. Furthermore, based on the failure mechanism, a new model considering the terms of concrete resistance and reinforcement resistance for the tensile breakout capacity of headed anchors around with supplementary reinforcement was proposed. Compared with the strut–tie model by EN 1992-4:2018, the predicted results of the model proposed by this study are relatively consistent with the experimental results, while the results by EN 1992-4:2018 are overly conservative. Full article

The strength of prestressed steel strands has developed towards high strength, increasing from 1860 MPa to over 2200 MPa. The stress in the prestressed anchorage zone is more concentrated and complex, and the anchor plates for dispersed loads need to be optimized in design. This article proposes a design scheme for adding a middle pressure-bearing step based on the existing anchor plate and then establishes a 1/4 model of the concrete anchoring area of the anchor plate for finite element analysis. Based on the theory of the strut-and-tie model, the position of the middle pressure-bearing step is determined according to the maximum angle of the strut-and-tie model. Then, carry out force transfer tests in the anchorage zone for verification. The research results indicate that after adding a middle pressure bearing step to the anchor plate, the angle between the strut-and-tie model in the anchorage zone increases, and the bearing capacity improves. The position of the middle pressure-bearing step in the anchor plate is different, and the angle between the strut-and-tie models is different. According to the middle step position parameter, λ (the ratio of the effective width of the middle step to the distance from the middle step to the end face of the anchor plate) is 0.533 to optimize the anchor plate, and the bearing capacity of its anchorage zone is relatively high. The main tensile and main compressive stresses of the anchor plate after optimization increased by 6.2% and 5.74%, respectively, compared to the anchor plate before optimization. The main tensile stress of the spiral reinforcement under the anchor plate decreased by 0.59%, the main compressive stress decreased by 2.89%, and the von-Mises stress decreased by 2.32%. The side surface tensile stress of concrete under the anchor plate was reduced by 4.3 percent. Finally, three concrete specimens were poured for force transfer testing in the anchorage zone, verifying the safety and reliability of the optimized anchor plate in the 2200 MPa-level prestressed anchorage zone. Full article

Within the research project ITSAFE, two full-scale structures were built, one consisting of a single-storey, two-span, 7.00 × 14.00 m² RC frame with a solid slab and another consisting of a two-storey, 7.00 × 7.00 m² RC frame with solid slabs. In the two-span frame, one of the central supports was first demolished using a pneumatic hammer, resulting in rather limited damage (a 14–15 cm deflection at the removed support location). However, torsional cracks appeared at the interface between a column and slab in one of the outer supports. When the second central support was removed, the structure collapsed with the failure of the support–slab connection. The same type of cracking was observed in the two-storey structure, where the column removal was dynamic, and a 22 cm deflection was measured. These experimental results question current practice in which, for internal supports, alternative load path mobilizing membrane forces in the slab are said to prevent their collapse, or in the cases of edge and corner columns, rupture line analysis is used and suggests that special reinforcement at the column–support connection is also needed to prevent the premature failure of the structure. Full article

In this paper, the shear behavior of concrete beams reinforced with FRP stirrups is studied. The shear performances of six concrete beams with a size of 150 mm × 300 mm × 3000 mm under four-point loading up to failure were experimentally analyzed. The critical parameters included the shear span to depth ratio (λ) and stirrup spacing (S). The test results revealed that as λ increased from 1 to 2, 3, and 4, the ultimate shear capacity of the beam decreases by 50.5%, 67.7%, and 69.2%, respectively. Meanwhile, as S increased from 100 mm to 150 mm and 200 mm, the ultimate shear capacity decreased by 16.1% and 44.6%, respectively. A new shear capacity calculation model of concrete beam reinforced with FRP stirrups was also proposed, which further considered the shear capacity of the FRP stirrups on the basis of the shear capacity of an RC beam without stirrups using the strut-and-tie model. Finally, the experiment and calculation results of 56 beam specimens reinforced with FRP stirrups extracted from this paper and previous studies were compared using the calculation models proposed in this paper, in order to evaluate the accuracy of these calculation models. Full article

In this paper, the loading mechanism of steel-fiber-reinforced concrete (SFRC) shear wall (SW) under low-cycle repeated loading is analyzed, and the softened strut-and-tie model (SSTM) of SFRC SW composed of horizontal and vertical resistant members and diagonal strut is proposed, in which the contributions of distributed web reinforcement, concrete, and steel fiber (SF) to the shear bearing capacity (SBC) of SFRC SW is identified. Furthermore, a new algorithm to obtain the SBC of SFRC SW is established, and then it is validated by using the test results of steel-fiber-reinforced high-strength concrete (SFHSC) SW and SFRC SW under low-cycle repeated loading. The results show that the calculated values are in good agreement with the experimental values for the 11 SFRC SWs, and the average strength ratio between calculated and experimental values (V_jh,t/V_jh,c) is 0.958. Therefore, the proposed calculation method is scientific and accurate for analyzing and predicting the SBC of SFRC SW. In addition, the proposed calculation method can scientifically and accurately analyze and predict the SBC of SFRC SW. Full article

Timber has long been extensively employed within the construction industry as a famous, environmentally friendly, and low-carbon material. Considering that construction constitutes one of the most significant contributors to carbon emissions throughout the entire life-cycle of a building, there is an urgent desire to incorporate timber into this domain. Nevertheless, the use of timber faces inherent challenges stemming from its anisotropic nature, a result of the natural growth of timber fibers, which makes it challenging for it to function as a primary load-bearing material in coping with the various complex stresses inherent in architectural applications. Numerous designers have attempted to address this limitation through over-sized members and reinforcement at joints; however, none have satisfactorily resolved this issue in an economical manner. In this article, we introduce the Strut-and-Tie models (STM) from Graphic Statics (GS) and a topological optimization algorithm. This algorithm has the capability to generate a ‘load-minimizing path’ STM based on external load support conditions and the maximum structural path span. Regardless of the complexity of the initial external loads, each load transfer path in the optimized STM bears loads in only one direction, representing an optimal solution with minimal internal loads that align seamlessly with the characteristics of timber. Consequently, we endeavor to adopt this optimization algorithm to propose a structural design methodology, with the aspiration of designing structural systems that harness the unique attributes of timber perfectly and applying them to various architectural scenarios. Ultimately, we conclude that structural systems designed based on optimized STM are adaptable to diverse architectural contexts, and when applied to small-scale buildings, this method can save approximately 20% of material consumption compared to conventional timber frame structures, while in the case of mid-rise to high-rise buildings, it can lead to a material savings of approximately 5%. Full article

In this study, the feasibility of utilizing locally produced coarse recycled aggregate (RA) from demolition waste in the UAE for structural applications was investigated. A comprehensive literature review on the subject showed that the shear and flexural responses of reinforced beams utilizing aggregate from concrete demolition waste are greatly dependent on the aggregate replacement ratio and the quality of the recycled aggregate. The experimental program in this study consisted of three phases. Phase I focused on the evaluation of the physical and mechanical characteristics of the RA, Phase II addressed the mix design and fresh and hard properties of the concrete, and Phase III dealt with the flexural and shear behavior of structural members. The research involved twelve 150 mm × 300 mm reinforced concrete beams with a length of 1500 mm or 2000 mm that were made with 0% (control), 50%, or 100% recycled coarse aggregate, replacing natural coarse aggregate (NA). Two target concrete compressive strengths, 25 and 35 MPa, were considered in the investigation. The results showed that the recycled aggregates had lower crushing and LA abrasion values by 40% and 18–28%, respectively, whereas the absorption capacity was 40–300% higher compared to the natural aggregate. In addition, the mechanical properties of the concrete made with different replacement ratios (R%) of RA were either similar or slightly less than those of the control mix. The shear beam tests with $f_c^{\prime }$ = 25 MPa showed that the 50%- and 100%-replacement-ratio beams demonstrated closely matched normalized shear strength values that exceeded their corresponding NA beam by 12.5%, while the shear beam tests with $f_c^{\prime }$ = 35 MPa showed that the NA beam exhibited normalized shear strength surpassing the 50% RA and 100% RA beams by 12.5% and 17.5%, respectively. In the flexural beam tests, the flexural strength exhibited minimal disparities for the beams that shared the same RA% but differed in their compressive strength targets, and overall, the variation in the RA% had a marginal impact on the flexural strength of the beams. Further, an increase in the RA% corresponded to an increase in the shear ductility index, which was in contrast with the findings on the flexural ductility index. Furthermore, predictions of flexural strength using the ACI318-19 code and shear strength using the strut-and-tie model yielded comparable results to the experimental ones. Full article

Reinforced concrete corbels were examined in this study for the cracking behavior and strength evaluation, focusing on defects typically found in these structures. A total of 11 corbel specimens were tested, including healthy specimens (HS), specimens with lower concrete strength (LC), specimens with less reinforcement ratio (LR), and specimens with more concrete cover than specifications (MC). The HS specimens were designed using the ACI conventional method. The specimens were tested under static loading conditions, and the actual strengths along with the crack patterns were determined. In the experimental tests, the shear capacity of the HS specimens was 28.18% and 57.95% higher than the LR and LC specimens, respectively. Similarly, the moment capacity of the HS specimens was 25% and 57.52% greater than the LR and LC specimens, respectively. However, in the case of the built-up sections, the shear capacity of the HS specimens was 9.91% and 37.51% higher than the LR and LC specimens, respectively. Likewise, the moment capacity of the HS specimens was 39.91% and 14.30% higher than the LR and LC specimens, respectively. Moreover, a detailed nonlinear finite element model (FEM) was developed using ABAQUS, and a more user-friendly strut and tie model (STM) was investigated toward its suitability to assess the strengths of the corbels with construction defects. The results from FEM and STM were compared. It was found that the FEM results were in close agreement with their experimental counterparts. Full article

As a transfer member at the discontinuous place of vertical load, the deep beam has a complex stress mechanism and many influencing factors, such as compressive strength of concrete, shear span ratio, and reinforcement ratio. At the same time, the stress analysis principle of traditional shallow beams is no longer applicable to the design and calculation of deep-beam structure. The main purpose of this paper was to use the strut-and-tie model to analyze its stress mechanism, and to verify the applicability of the model. Nine high-strength concrete deep-beam specimens with longitudinal reinforcement with an anchor plate of the same size were tested by two-point concentrated loading method. The effects of shear span ratio (0.3, 0.6, and 0.9), longitudinal reinforcement ratio (0.67%, 1.05%, and 1.25%), horizontal reinforcement ratio (0.33%, 0.45%, and 0.50%), and stirrup reinforcement ratio (0.25%, 0.33%, and 0.50%) on the failure mode, deflection curve, characteristic load, crack width, steel bar, and concrete strain of the specimens were analyzed. The results showed that the failure mode of deep-beam specimens was diagonal compression failure. The normal section cracking load was about 15 to 20% of the ultimate load, and the inclined section cracking load was about 30~40% of the ultimate load. The shear span ratio increased from 0.3 to 0.9, and the bearing capacity decreased by 32.9%. When the longitudinal reinforcement ratio increased from 0.67% to 1.25%, the ultimate load increased by 42.6%. The shear span ratio and longitudinal reinforcement ratio have a significant effect on the bearing capacity of the high-strength concrete deep beams with longitudinal reinforcement with an anchor plate. The shear capacity of nine high-strength concrete deep-beam specimens with longitudinal reinforcement with an anchor plate was calculated by national standards, and the results were compared with the calculation results of the Tan–Tang model, the Tan–Cheng model, SSTM, and SSSTM. The analysis showed that the softened strut-and-tie model takes into account the softening effect of compressive concrete, and is a more accurate mechanical model, which can be applied to predict the shear capacity of high-strength concrete deep-beam members with longitudinal reinforcement with an anchor plate. Full article
