Actuators, Volume 8, Issue 3 (September 2019) – 18 articles

Various actuator topologies are discussed for the purpose of powering periodic processes and particularly walking robots. The Clutched Parallel Elastic Actuator (CPEA) is proposed to reduce the energy consumption of active exoskeletons. A nonlinear model of the CPEA is presented in addition to the mechanical design. The CPEA prototype is operated with a passive load on the walking trajectory of the hip joint. The actuator is controlled with a cascaded position control and a superimposed Iterative Learning Controller (ILC). The controller was chosen to ensure comparability between active and deactivated spring operation. The application of the CPEA has the potential to increase efficiency in the design of exoskeletons. Full article

Actuators play an important role in modern active flow control technology. Dielectric barrier discharge plasma can be used to induce localized velocity perturbations in air, so as to accomplish modifications to the global flow field. This paper presents a selective review of applications from the published literature with emphasis on interactions between plasma-induced perturbations and original unsteady fields of bluff-body flows. First, dielectric barrier discharge (DBD)-plasma actuator characteristics, and the local disturbance fields these actuators induce into the exterior flow, are described. Then, instabilities found in separated flows around bluff bodies that controlled actuation should target at are briefly presented. Key parameters for effective control are introduced using the nominally two-dimensional flow around a circular cylinder as a paradigm. The effects of the actuator configuration and location, amplitude and frequency of excitation, input waveform, as well as the phase difference between individual actuators are illustrated through examples classified based on symmetry properties. In general, symmetric excitation at frequencies higher than approximately five times the uncontrolled frequency of vortex shedding acts destructively on regular vortex shedding and can be safely employed for reducing the mean drag and lift fluctuations. Antisymmetric and symmetric excitation at low frequencies of the order of the natural frequency can amplify the wake instability and increase the mean and fluctuating aerodynamic forces, respectively, due to vortex locking-on to the excitation frequency or its subharmonics. Results from several studies show that the geometry and arrangement of the electrodes is of utmost significance. Power consumption is typically very low, but the electromechanical efficiency can be optimized by input waveform modulation. Full article

In modern times, the design and optimization of different actuator systems for controlling a high-precision position control system represent a popular interdisciplinary research area. Initially, only single-stage actuator systems were used to control most of the motion control applications. Currently, dual-stage actuation systems are widely applied to high-precision position control systems such as hard disk drive (HDD) servo systems. In the dual-stage system, a voice coil motor (VCM) actuator is used as the primary stage and a piezoelectric micro-actuator is applied as the secondary stage. However, a dual-stage control architecture does not show significant performance improvements to achieve the next-generation high-capacity HDD servo system. Research continues on how to fabricate a tertiary actuator for a triple-stage HDD servo system. A thermal positioning controller (TPC) actuator is considered promising as the tertiary stage. The triple-stage system aims to achieve greater bandwidth, track density, and disk speed, with minimum sensitivity and greater error minimization. In this work, these three actuation systems with different combinations of proportional plus integral (PI), proportional plus derivative (PD), and proportional plus integral plus derivative (PID) controller, lag-lead controller, lag filter, and inverse lead plus a PI controller were designed and analyzed through simulation to achieve high-precision positioning. The comparative analyses were done on the MATLAB/Simulink simulation platform. Full article

The paper aims to develop improved acoustic-based structural health monitoring (SHM) and nondestructive evaluation (NDE) techniques, which provide the waves directivity emitted by the angle beam wedge actuators in thin-walled structures made of plastic materials and polymeric composites. Our investigation includes the dispersive analysis of the waves that can be excited in the studied plastic panel. Its results allowed to find two kinds of generated acoustic waves—anti-symmetric Lamb waves (A0) and shear horizontally polarized SH waves (SS0). The bounds of the chosen frequency range for the experimental and numerical studies were accepted as a compromise between the desire to obtain a high defect resolution by generating short waves, their adjustable directivity, and maximum propagation length. The finite element model for the transducer was built by using the results of an actuator structure experimental study. The frequency response functions for the actuator current and oscillation amplitude of the footprint surface demonstrated good agreement. The found eigenfrequencies of the actuator’s structure were used for the numerical and experimental study of the Lamb and SH wave generation and propagation in a thin-walled plastic panel. Our results convincingly demonstrated the satisfactory directivity of the actuated waves at their excitation on the frequencies that corresponded to the natural modes of the actuator oscillation. The authors assume that an efficient use of the proposed technique for other analyzed quasi-isotropic materials and applied actuators can be provided by preliminary research using a similar approach and methods presented in this article. Full article

New robotic applications, among others, in medical and related fields, have in recent years boosted research in the development of new actuators in the search for solutions that are lighter and more flexible than conventional actuators. Shape-Memory Alloy (SMA)-based actuators present characteristics that make them an excellent alternative in a wide variety of applications. This paper presents the design, tests (with the control description) and analysis of various configurations of actuators based on SMA wires: flexible SMA actuators, different mechanical design to multiply the displacement and different configurations for actuators with multiple SMA wires. The performance of the actuators has been analyzed using wires of different activation temperatures. The influence of the Bowden sheath of the flexible actuator has been tested, as has the thermal behavior of actuators with several wires. This work has allowed determination of the most effective configuration for the development of a flexible actuator based on SMA, from the point of view of dimensions, efficiency, and work frequency. This type of actuator has been applied in the development of soft robots and light robotic exoskeletons. Full article

Soft robotics is a novel approach in the field of robotics. Soft robots or soft actuators are typically polymer-based and are characterized by their flexibility and adaptability, which brings new far-reaching applications. Soft robotics is currently at the peak of its research. One circumstance that is also present in this age is constant climate change; there is a demand for sustainability. This goes hand in hand with the design of products that are suitable for recycling. Today, more is expected of an engineer than just function-oriented design. This article looks at soft robotics from the point of view of sustainability. Since nature operates in cycles, the aim is to design products in such a way that they can be introduced into cycles. Three recycling cycles for products can be distinguished, which take place during production, during product use, and after product life. Within the framework of this work, special design measures are reviewed for fluidic elastomer actuators—a characteristic type of soft actuators—so that they can be integrated into the recycling process. Full article

This paper evaluates possible applications for SMAs (Shape Memory Alloys) based on the requirements in the field of aircraft interiors. The authors gather requirements regarding industry standards and regulations by detailed literature research and lead user interviews. They develop a classification scheme for SMA-based actuators, which consists of SMA-specific technical attributes and requirements. This classification scheme allows one to evaluate the feasibility of using SMA-based systems in aircraft interiors. Furthermore, this paper clusters critical requirements and discusses solutions for limitations of SMAs in aircraft interiors. The authors identify critical and noncritical requirements for the implementation of SMA-based actuators. They suggest solutions for critical requirements in order to improve the possible range of applications for SMAs. The study exclusively regards the field of aircraft interiors and the currently existing industry standards and only indirectly takes laws into account. The evaluated requirements and proposed solutions can be transferred to other areas such as the automotive industry. This structured analysis of the feasibility of SMA-based systems in aircraft interiors is an innovative research work and, therefore, is valuable in order to benefit from the advantageous properties of SMAs. Full article

In industrial applications, rotatory motions and torques are often needed. State-of-the-art actuators are based on either combustion engines, electro-motors, hydraulic, or pneumatic machines. The main disadvantages are the construction space, the high weight, and a large amount of needed peripheral devices. To overcome these limitations, compact and light-weight actuator systems can be built by using shape memory alloys (SMAs), which are known for their superior energy density. In this paper, the development of a scalable bi-directional rotational actuator based on SMA wires is presented. The scalability was based on a modular design, which allowed the actuator to be adapted to various application specifications by customizing the rotational angle and the output torque. On the mechanical side, each module enabled a small rotatory motion, which added up to the total angle of the actuator. The SMA wires were arranged in an agonist-antagonist configuration to provide active rotation in both directions. The presented prototype achieved a total rotation of 100°. The modularity of the mechanical concept is also reflected in the electronics, which is discussed in this paper as well. This consideration allows the electronics to be adapted to the mechanics with minimal changes. As a result, a prototype, including the presented mechanical and electronic design, is reported in this study. Full article

Hydrostatic actuation has gained interest from both academia and industry due to the unquestionable energetic advantages when compared to valve-controlled actuators; the main feature being the absence of throttling losses due to the direct control of the cylinder by the pump. However, the fact that the great majority of applications are based on single-rod cylinders has been both a challenge and a source of inspiration for a variety of different circuit designs. In an attempt to compensate for the uneven flows coming in and out of differential cylinders, several solutions have been proposed, including the use of hydraulic transformers, individual pumps connected to the cylinder ports or pumps with unmatched input and output flows. The simplest approach, however, seems to be the use of compensation valves in the circuit, which is the focus of this paper. Here, we analyse some representative circuits proposed along the years in a direct and elucidative manner, showing that the definitive solution to the single-rod actuator control problem has been established, paving the road for introducing stable and trustworthy circuits, which can be commercially used in the near future. Full article

Nowadays, the development or improvement of soft actuation mechanisms is a crucial topic for the achievement of dexterous manipulation using. Then, a primary target of research is the design of actuation and driving devices. Consequently, in this paper, we introduce a soft driving epicyclical mechanism that mimics human muscle behavior and fulfills motion requirements to achieve grasping gestures using a robotic finger. The prototype is experimentally assessed, and results show that our approach has enough performance for the implementation in grasping tasks. Furthermore, we introduce the basis for a new soft epicyclical mechanism merger with shape memory alloys to allow active stiffness control of the mechanism. Full article

A self-bearing motor (SBM) is an electric motor with a magnetically integrated bearing function, that is, it can provide levitation and rotation simultaneously as a single actuator. This paper presents the design, operating principle and control system for the slotless self-bearing motor (SSBM). In this design, the stator has no iron core but includes six-phase coils. The rotor consists of a permanent magnet and an enclosed iron yoke. Magnetic forces generated by the interaction between stator currents and the magnetic field of the permanent magnet are used to control the rotational speed and radial position of the rotor. In this paper, the torque and radial bearing forces are analyzed theoretically with the aim to develop an improved control system. In order to confirm the proposed control method, an experimental system was constructed and tested. Simulation and measurement results show that the SSBM can work stably in modes such as start, reverse, rotation load and external radial pulse forces. Full article

A novel discrete-valued model-predictive control (DVMPC) algorithm termed DVMPC2 for the position control of pneumatic actuators using inexpensive on/off valves is presented. DVMPC2 includes a more flexible cost function, an improved prediction strategy, and other improvements. The actuator is a double-acting cylinder with two on/off solenoid poppet valves connected to each chamber. To reduce the switching frequency and prolong the valve life, DVMPC2 directly switches the valves when necessary, instead of using relatively high-frequency pulse-width modulation. Experimental comparisons are made with the state-of-the-art sliding-mode control (SMC) algorithm and the previous DVMPC algorithm. The comparisons are based on the five performance metrics: integral of time-weighted absolute error (ITAE), root mean square error (RMSE), overshoot (OS), steady-state error (SSE), and valve switches per second (SPS). The robustness is evaluated by increasing and decreasing the total mass of the moving components while keeping the controller parameters constant. The experimental results show that the proposed algorithm is superior to the previous DVMPC and outperformed SMC by a wide margin. Specifically, DVMPC2 reduced ITAE by 80%, RMSE by 52%, OS by 43%, and SPS by 20% relative to SMC. There was no clear winner in terms of SSE. Full article

This study presents the experimental evaluation of a piezo-inductive mechanical system for applications of energy harvesting with low-frequency vibrations. The piezo-inductive vibration energy harvester (PI-VEH) device is composed of a voice coil motor (VCM) extracted from a hard disk drive. The proposed design allows the integration of different element types as beams and masses. The dynamic excitations in the system produce a pendular motion carried out by a hybrid arm (rigid-flexible) that generates energy with the rotations (with a coil) and the beam strains (with a piezoelectric material). The electrical assessment was performed through different working modes classified as inductive, inductive with magnetic instabilities, and piezo-inductive. The instabilities in the harvester refer to external forces induced by two magnets that repel each other. The first two inductive configurations were designed as a function of three parameters (length, mass, instability angle) to debug these using the maximum output voltage. The selected experiments were conducted in a piezo-inductive configuration. The results showed two effects on the output voltage—the first one is related to a system without resonances (higher broadband), and the second effect is associated with a multi-resonant system. As a final conclusion, it is pointed out that the electrical performance can be improved with the magnetic instabilities since these considerably amplified the output voltages. Full article

This paper describes the analysis, from a statistical point of view, of a maritime gas turbine, under various operating conditions, so as to determine its state. The data used concerns several functioning parameters of the turbines, such as temperatures and vibrations, environmental data, such as surrounding temperature, and past failures or quasi-failures of the equipment. The determination of the Mean Time Between Failures (MTBF) gives a rough estimate of the state of the turbine, but in this paper we show that it can be greatly improved with graphical and statistical analysis of data measured during operation. We apply the Laplace Test and calculate the gas turbine reliability using that data, to define the gas turbine failure tendency. Using these techniques, we can have a better estimate of the turbine’s state, and design a preventive observation, inspection and intervention plan. Full article

This paper reviews Artificial Immune Systems (AIS) that can be implemented to compensate for actuators that are in a faulted state or operating abnormally. Eventually, all actuators will fail or wear out, and these actuator faults must be managed if a system is to operate safely. The AIS are adaptive algorithms which are inherently well-suited to these situations by treating these faults as infections that must be combated. However, the computational intensity of these algorithms has caused them to have limited success in real-time situations. With the advent of distributed and cloud-based computing these algorithms have begun to be feasible for diagnosing faulted actuators and then generating compensating controllers in near-real-time. To encourage the application of AIS to these situations, this work presents research for the fundamental operating principles of AIS, their applications, and a brief case-study on their applicability to fault compensation by considering an overactuated rover with four independent drive wheels and independent front and rear steering. Full article

In this work, the parametric structural schematic diagrams of a multilayer electromagnetoelastic actuator and a multilayer piezoactuator for nanomechanics were determined in contrast to the electrical equivalent circuits of a piezotransmitter and piezoreceiver, the vibration piezomotor. The decision matrix equation of the equivalent quadripole of the multilayer electromagnetoelastic actuator was used. The structural-parametric model, the parametric structural schematic diagram, and the matrix transfer function of the multilayer electromagnetoelastic actuator for nanomechanics were obtained. Full article

The work at hand focuses on the modeling, prototyping, and experimental functionality test of a smart actuator based on shape memory polymer technology. Particular attention is paid to the specific modeling approach, here conceived as an effective predictive scheme, quick and, at the same time, able to face those nonlinearity aspects, strictly related to the large displacements shape memory polymers usually undergo. Shape memory polymer composites (SMPCs) may play a critical role for many applications, ranging from self-repairing systems to deployable structures (e.g., solar sails, antennas) and functional subcomponents (e.g., pliers, transporters of small objects). For all these applications, it is very important to have an effective tool that may drive the designers during the preliminary definition of the main parameters of the actuation system. For the present work, a SMPC plate sample has been conceived and realized in view of aerospace applications. An external fibre optic sensor has been then fixed with special adhesive. The temperatures needed for the activation of the Shape Memory Polymer (SMP) and strain storing have been provided by a thermo-gun and complete load–unload cycles, including strain storing, have been performed. Experimental displacements and strains have been used to validate a dedicated predictive theoretical approach, suited for laminates integrated with SMP layers. Full article

A branch of robotics, variable impedance actuation, along with one of its subfields variable stiffness actuation (VSA) targets the realization of complaint robotic manipulators. In this paper, we present the modeling, identification, and control of a discrete variable stiffness actuator (DVSA), which will be developed for complaint manipulators in the future. The working principle of the actuator depends on the involvement of series and parallel springs. We firstly report the conceptual design of a stiffness varying mechanism, and later the details of the dynamic model, system identification, and control techniques are presented. The dynamic parameters of the system are identified by using the logarithmic decrement algorithm, while the control schemes are based on linear quadratic control (LQR) and computed torque control (CTC), respectively. The numerical simulations are performed for the evaluation of each method, and results showed the good potentialities for the system. Future work includes the implementation of the presented approach on the hardware. Full article
