Designs, Volume 6, Issue 3 (June 2022) – 20 articles

With the increase in demand for more sustainable energy sources, recent researchers have been looking into harvesting energy spent by humans for various purposes. One of the available sources of such energy is exercise equipment. While a few products are available in the market to harvest the power expended during an exercise session, these products are costly, and the cost may prohibit a day-to-day user from purchasing those. Motivated by this challenge, this paper describes a long-running research project that uses a static exercise bicycle to sustainably harvest human energy. A regenerative spin bike that uses the friction between a flywheel and a BaneBots wheel was designed and deployed. For the motor mount, two methods are investigated: linear preloading and rotary preloading. A commercially available indoor static bicycle is modified to incorporate the flywheel and the motor attachment. The generated electricity is converted to DC using a three-phase rectifier. A car charger is used for charging any devices attached to the setup. The resulting configuration is very effective in operating small electronic devices. This setup, which uses only off-the-shelf components, can be considered a replacement for its expensive custom-made counterparts. Full article

As is well known, the realization of a zero-waste society is strongly desired in a sustainable society. In particular, architectural elements that provide an energy-neutral living environment are attractive. This article presents the novel environmentally friendly architectural elements that generate hydrogen energy by the photosystem II (PSII) solution extracted from waste vegetables. In the present work, as an architectural element, the window (PSII window panel) and roof (PSII roof panel) were fabricated by injecting a PSII solution into a transparent double-layer panel, and the aging properties of the power generation and the appearance of these PSII panels are investigated. It was found that the PSII roof can generate energy for 18 days under the sun shining and can actually drive the electronic device. In addition, the PSII window, for which light intensity is weaker than that for the PSII roof, can maintain power generation for 40 days. These results indicate that the PSII roof and PSII window become the architectural elements generating energy, although the lifespan depends on the total light intensity. Furthermore, as an additional advantage, the roof and window panels composed of the semitransparent PSII panel yield an interior space with the natural color of the leaf, which gradually changes over time from green to yellow. Further, it was also found that the thermal fluctuation of the PSII window is smaller than that of the typical glass window. These results indicate that the roof and window panels composed of the PSII solution extracted from waste vegetables can be used as the actual architectural elements to produce not only the electrical energy but also the beautiful, transparent natural green/yellow spaces. Full article

Sustainability-related information affects people’s choices and evaluation. The literature has made significant efforts to understand the best ways of delivering this kind of information to shape consumer behavior. However, while most studies have focused on packaged products and direct information provided through eco-labels, preferences could be formed differently in other design domains. The paper investigates the effect of the perceived amount of indirect information on the evaluation of an architectural artefact. A sample of 172 participants visited a locally produced mobile tiny house, made with a considerable amount of sustainable materials. The same participants answered a questionnaire about their perceived knowledge, quality, appropriateness and sustainability of the tiny house. The general level of knowledge of the tiny house was used as a proxy of the amount of indirect information received. Although the knowledge of the tiny house was generally low, ratings regarding the other dimensions were overall extremely positive. In particular, no evident relation was found between knowledge of the tiny house and sustainability, while the latter is significantly linked to quality aspects. These outcomes deviate from the evidence from other studies; this might be due to indirect vs. direct information and the peculiarity of the study carried out in the field of buildings. The gathered demographic and background data of the participants make it possible to highlight the role played by gender and age in affecting the evaluations, but the absence of a significant impact of experience in the field, education and origin. The results are compared with findings related to the evaluation of sustainable products and green buildings in particular. Full article

Transit-Oriented Development (TOD) assessment models are commonly used to assess existing and planned metro station catchment areas. Elements like diversity, density, design, destination, distance, and demand management are considered in the 6Ds TOD assessment model. Assessment of these elements in the designing stage depends on the TOD expert’s involvement to ensure the effectiveness of the model. The aim of this research is to develop novel pre-TOD assessment guidelines that consist of Spatial Analysis, Virtual Function of Transit Station (VFTS), and Estimated Spatial Analysis, which can improve the reliability of the assessment conclusion according to the 16 planning elements. The research applies three methodologies: (1) analytical approach to evaluate the TOD concept and its assessment model; (2) development of pre-TOD assessment guidelines using the Delphi technique; and (3) conduct a case study of the Doha Exhibition and Convention Center metro station in Qatar to validate the developed model. The findings are a new concept, called the Dependent Component Area (DCA) of the metro station, and VFTS classifications of the metro station include an urban connector, suburban connector, destination, and destination connector. The newly developed pre-TOD assessment guidelines can enhance TOD assessment methods, especially in emerging cities. Moreover, these assessment guidelines will provide TOD and planning experts with more precise data and information related to the DCA. Full article

The range of applications of RPAs in various industries indicates that their increased usage could reduce operational costs and time. Remotely piloted aircraft systems (RPASs) can be deployed quickly and effectively in numerous distribution systems and even during a crisis by eliminating existing problems in ground transport due to their structure and flexibility. Moreover, they can also be useful in data collection in damaged areas by correctly defining the condition of flight trajectories. Hence, defining a framework and model for better regulation and management of RPAS-based systems appears necessary; a model that could accurately predict what will happen in practice through the real simulation of the circumstances of distribution systems. Therefore, this study attempts to propose a multi-objective location-routing optimization model by specifying time window constraints, simultaneous pick-up and delivery demands, and the possibility of recharging the used batteries to reduce, firstly, transport costs, secondly, delivery times, and thirdly, estimated risks. Furthermore, the delivery time of the model has been optimized to increase its accuracy based on the uncertain conditions of possible traffic scenarios. It is also imperative to note that the assessment of risk indicators was conducted based on the Specific Operations Risk Assessment (SORA) standard to define the third objective function, which was conducted in a few previous studies. Finally, it shows how the developed NSGA-II algorithm in this study performed successfully and reduced the objective function by 31%. Comparing the obtained results using an NSGA-II meta-heuristic approach, through the rigorous method GAMS, indicates that the results are valid and reliable. Full article

Fixed-tilt mechanical racking, consisting of proprietary aluminum extrusions, can dominate the capital costs of small-scale solar photovoltaic (PV) systems. Recent design research has shown that wood-racking can decrease the capital costs of small systems by more than 75% in North America. To determine if wood racking provides enough savings to enable labor to be exchanged profitably for higher solar electric output, this article develops a novel variable tilt angle open-source wood-based do-it-yourself (DIY) PV rack that can be built and adjusted at exceptionally low costs. A detailed levelized cost of electricity (LCOE) production analysis is performed after the optimal monthly tilt angles are determined for a range of latitudes. The results show the racking systems with an optimal variable seasonal tilt angle have the best lifetime energy production, with 5.2% more energy generated compared to the fixed-tilt system (or 4.8% more energy, if limited to a maximum tilt angle of 60°). Both fixed and variable wooden racking systems show similar LCOE, which is only 29% of the LCOE of commercial metal racking. The results of this study indicate that the novel variable tilt rack, whether used as a small-scale DIY project or scaled up to fulfill larger energy demands, provides both the lowest cost option even when modest labor costs are included and also may provide specific advantages for applications such as agrivoltaics. Full article

The acceleration demand from the driver in electric vehicles (EVs) should be supported by high-power energy storage systems (ESSs). In order to satisfy the driver’s request, the employed ESS should have high power densities. On the other hand, high energy densities are required at the same time for EVs’ traction to minimize the range anxiety. In this context, a novel ESS has emerged that can provide high power and energy densities at the same time. Such technology is called lithium-ion capacitor (LiC), which employs Li-doped carbon as negative electrode and activated carbon as positive electrode. However, high heat generation in high current applications is an issue that should be managed to extend the LiCs life span. Hence, a proper thermal management system (TMS) is mandatory for such a hybrid technology. Since this ESS is novel, there are only several TMSs addressed for LiCs. In this review article, a literature study regarding the developed TMSs for LiCs is presented. Since LiCs use Li-doped carbon in their negative electrodes, lithium-titanate oxide (LTO) batteries are the most similar lithium-ion batteries (LiBs) to LiCs. Therefore, the proposed TMSs for lithium-ion batteries, especially LTO batteries, have been explained as well. The investigated TMSs are active, passive, and hybrid cooling methods The proposed TMSs have been classified in three different sections, including active methods, passive methods, and hybrid methods. Full article

The heating, ventilation, and air conditioning (HVAC) system is a major energy consumer in office buildings, and its operation is critical for indoor thermal comfort. While previous studies have indicated that reinforcement learning control can improve HVAC energy efficiency, they did not provide enough information about end-to-end control (i.e., from raw observations to ready-to-implement control signals) for centralized HVAC systems in multizone buildings due to the limitations of reinforcement learning methods or the test buildings being single zones with independent HVAC systems. This study developed a model-free end-to-end dynamic HVAC control method based on a recently proposed deep reinforcement learning framework to control the centralized HVAC system of a multizone office building. By using the deep neural network, the proposed control method could directly take measurable parameters, including weather and indoor environment conditions, as inputs and control indoor temperature setpoints at a supervisory level. In some test cases, the proposed control method could successfully learn a dynamic control policy to reduce HVAC energy consumption by 12.8% compared with the baseline case using conventional control methods, without compromising thermal comfort. However, an over-fitting problem was noted, indicating that future work should first focus on the generalization of deep reinforcement learning. Full article

Although the benefits of the Lean Six Sigma (LSS) methodology have been proven for more than 20 years, it is still underutilized in environmental science, (e.g., in anaerobic digestion and biogas production). In order to obtain a structural and data-oriented perspective for process optimization in the renewable energy sector, LSS application must be considered one of the most valuable tools. To inform this paper, the LSS analysis phase was conducted in a scaled-down environment through detailed laboratory experiments. Results showed not only the feasibility of LSS application in biogas technology, but also some useful findings such as possible root causes for low production, such as impurities, waiting time, and existing pre-treatment methods for the defined problem. The results of the experiments show that the use of old substrates can reduce the biogas production up to half of the production with fresh substrates, and that even a 10% sand content can reduce the production up to 14.2%, which shows the need for a solution to these two issues. Full article

The ageing society is a challenging social issue, yet it implies a growing demand for elderly goods and services. The current development of elderly textile products, however, appears to neglect everyday use. This paper used a case study to demonstrate the utilization of design thinking, a human-centric methodology, in order to design and develop a creative solution for elderly care in elderly centers, taking into account their needs and preferences with regard to textiles. Starting from empathy, complex problems were identified, and ideas were generated. As a skin-protective home textile, chitosan, a natural antibacterial material, has been suggested for development. By using iterative processes, the spinning problem was tackled; the biological and physical characteristics were studied; design, sizing, patterns and printing were created and refined to fulfill the needs; mass production of bedding, apron and handkerchief were successfully achieved; a pre-posttest trial was conducted to determine the satisfaction level and potential help of the prototypes. The feedback was generally positive and highly satisfied. Hence, this study indicates that the design thinking approach may provide an effective method of understanding empathy and discovering solutions most likely to meet the needs of the users. Full article

The Search for Hidden Particles (SHiP) experiment is a new purpose fixed target facility proposed for the CERN Super Proton Synchrotron accelerator to search for long-lived exotic particles associated with Hidden Sectors and Dark Matter. This paper reports on the development of BIM integrated design for the SHiP experiment, applied initially to the Decay Volume, a >2000 m³ conical steel vessel under a vacuum hosting several large particle physics detector systems. A BIM methodology is used to address all the design phases of the Decay Volume of the SHiP experiment from the conceptual planning to the constructive drawings production. This proposed workflow is a basic plan to be repeated for each sub-component of the SHiP experiment in order to have a full and overall integration of the experiment. In particular, the Decay Volume’s geometrical and structural design and the simulation of its assembly process, both in factory and on site, are proposed. Moreover, the use of collaborative platforms to speed up the ideas exchange, as the basis of a highly multidisciplinary and complex project, is discussed. The complexity, multidisciplinary nature, and size of the SHiP project severely challenge design information management. The final plan to solve this issue is to have a BIM integrated design of each experiment sub-component, such as that demonstrated in this work for the Decay Volume, in order to have a full and multidisciplinary integration of the overall project. Full article

Academic libraries include college and university libraries. Interior design is an important way to bring about the required change in transforming academic libraries from a repository of books into places for research and communication. While interior design plays a major role in providing an innovative functional design in academic libraries within universities, the problem of the study lies in the importance of academic libraries and their main role in university education institutions in encouraging and supporting scientific research among students and faculty members. According to the role of interior design in designing academic libraries, the researcher finds that there are problems with interior design in the academic library at the College of Education. It needs to be re-designed to improve functionality and aesthetics and enhance the internal space for users to achieve effective use of the internal library space. The study aims to create a better design of interior environments in academic libraries in order to feature creativity and innovation. The research method is descriptive–analytical to describe and analyze the current interior design of the academic library at the College of Education at King Faisal University and collect real information about the library and the problems of interior design. Then, it was presented through the opinion poll tool to the beneficiaries to know their opinions about the current design of the library and to benefit from them in the design proposal of the academic library according to the correct design considerations. Then, the opinion poll tool was displayed again according to the design proposal to know the views of the beneficiaries again to contribute to providing an appropriate research environment for students and faculty members. Full article

In this paper, the buckling analysis on simply supported rectangular plates and stiffened panels is carried out. Three different plate thicknesses were proposed (i.e., 3 mm, 4 mm, and 5 mm). The thickness of the longitudinal stringers and sub-stiffeners were also varied. The material that was used was marine grade steel. The load versus the displacement curve and the total energy were measured. The buckling analysis results were examined via finite element (FE) computation. To ensure that the results of the methodology for the finite element were reliable, the benchmark buckling analysis of the experimental test was reconstructed. For the selection of mesh size, the element to thickness ratio method (ELT) was used. The results revealed that the thickness of the plate increases the strength of the stiffened panel. The plate thickness of 5 mm increased by 65.7% and 20.61% compared with the 3 mm and 4 mm plate thicknesses. A change in the thickness of the sub-stiffeners does not significantly change the strength of the stiffened panels. Material S355JR-EN10210 produced a higher ultimate panel collapse load compared with S235JR-EN10025 (A) and S235JR-EN10025 (B). Full article

Happiness is a natural human right that all seek to achieve. The quality of people’s lives may be directly affected by the quality of their working life, which is affected by the quality of their work environment. This has become the focus of attention of work institutions in society due to its great importance and strong impact on success. The purpose of this study was to investigate the institutional work environment at King Faisal University by surveying faculty and staff members regarding their opinions on meeting their environmental and functional needs at work by improving the interior design of workspaces to create happiness in the work environment. The aim of this study was to reveal the relationship between employees’ performance levels and their work environment, in addition to making happiness and quality of life major priorities and creating a stimulating work environment. The researcher used descriptive analysis to analyze the relationship between aspects of work and the levels of job satisfaction and happiness among employees of King Faisal University. The researcher used a five-point Likert scale to measure the responses to the questionnaire items, and reached several conclusions, including that the level of job happiness at King Faisal University is not affected by the variables of gender, social status, or the nature of the job, and that the university provides a work environment that helps achieve job happiness and allows for job innovation and creativity. Full article

The current study focuses on minimising the bubbles in polyester-insulated ignition coils, which were produced with a defect level of ~21–25% or 210–250 coils per 1000 batch size by using the potting method. This high-level rejection makes a substantial financial impact by increasing waste material, manufacturing, and after-sales costs. Hence, to control the bubbled problem without using expensive and maintenance-heavy techniques, the process parameters in the potting method were alternated and investigated using one factor at a time, which played a vital role in the formation/reduction of bubbles in the ignition coil insulation. Process parameters, including pre/process heating, the appropriate MEKP/cobalt naphthenate ratio, the pouring amount/increments, and the stirring speeds, reduced the bubble formation per lot from 205 ± 30 to 146 ± 25, 108 ± 21, 61 ± 17, and 10 ± 2 per 1000 lot accordingly. In addition, a comparative study was conducted in terms of performance and life cycle endurance, using Japanese and Indian standards. Furthermore, an after-sale warranty claim also supports the proposed changes in the potting technique. This modification may reduce the after-sales rejection within two years to approximately ~85%. This modification in the potting technique is extremely cost-effective in comparison to expensive processes, i.e., vacuum-pressure impregnation and vacuum impregnation, which require extensive labour and maintenance. Full article

In this paper, we propose a metamaterial (MTM)-based low-profile wideband antenna and its array using a substrate integrated cavity (SIC) feed structure for 5G wireless cellular networks. The proposed wideband antenna consists of two sets of square mushroom-like arrays; a semi-ground plane and a microstrip line-fed bow-tie radiator. Due to the unique in-phase reflection characteristic of the mushroom-like metamaterial, the bow-tie antenna wideband performance is maintained while the distance between the bow-tie radiator and the metamaterial-based semi-ground is considerably reduced to 0.014λ₀ (λ₀ is the operating wavelength at 5 GHz in free space), thereby satisfying the compact size requirement desirable in many wireless communication systems. The in-phase reflection of the mushroom unit cell is applied to analyze and explain the wideband performance of the presented antenna. The proposed dielectric-filled (${\epsilon }_r=3.55$) MTM-based wideband antenna element has an overall size of 1.0λ₀ × 0.8λ₀ × 0.054λ₀ and attains a measured ($\left|{\mathrm{S}}_{11}\right|<-10\mathrm{dB}$) bandwidth of 31.3%. Subsequently, an SIC feed structure is employed to form an array antenna, and a measured ($\left|{\mathrm{S}}_{11}\right|<-10\mathrm{dB}$) bandwidth of about 17% is obtained. Across the operating bandwidth, which partly covers the 5G wireless communication in the sub-6 GHz band and 5-GHz WLAN, the antenna array achieved an average gain of 6.6 dBi and a radiation efficiency greater than 73%. Full article

The following case study portrays the several steps required to conceive a product from scratch. The first step involves an in-depth analysis of today’s electric bicycle market in order to obtain data and information relating to the levels of innovation and comfort required by customers. Then, we evaluate the implementation of a useful method to understand the level of innovation that the product must have to be competitive on the market. The second part studies the architecture of the product, considering the different components already sold on the market which will become part of the project. The third part concerns a comparison between different stylistic trends that the vehicle may have (in order to outline the best one). The fourth part concerns the CAD realization of the virtual model complete with all its parts, including a structural verification study of the frame. The last part studies the presentation of the product to the customer, exploring different effective ways to communicate what the strengths of the new product will be (also allowing them to customize it before its realization). The plan for the realization of the new product, starting from the concept to arrive at the final presentation to the customer, follows the methods proposed by applying a series of steps to develop a generic new product in an efficient, sensible, and methodical manner. Therefore, we will refer to quality function deployment (QFD), benchmarking (BM), design for X, until reaching the final prototyping and testing phases. Full article

Although small solar photovoltaic (PV) systems avoid most soft costs, they still have a relatively high $/W value due to racking costs. In order to fulfill the promise of small-scale plug-and-play solar, a do-it-yourself PV rack design is provided and analyzed here for six criteria: (1) made from locally-accessible renewable materials, (2) 25-year lifetime to match PV warranties, (3) able to be fabricated by average consumers, (4) able to meet Canadian structural building codes, (5) low cost and (6) that it is shared using an open-source license. The open-source wood-based fixed-tilt ground-mounted bifacial photovoltaic rack design evaluated here was found to be appropriate throughout North America. Economic analysis of the bill of materials showed the racking system ranges from 49% to 77% less expensive compared to commercial proprietary racking in Canada. The racking design, however, is highly dependent on the cost of lumber that varies widely throughout the world. Even for an absolute lower-cost design in Togo due to a lower fixed tilt angle and lower loads from lack of snow, it was not found to be economic because of the relatively high cost of wood. The recent volatile lumber market warrants local evaluation from those considering the use of the open-source design. This design, however, provides for a PV rack that can be manufactured with distributed means throughout most of the world enabling more equitable access to solar energy to support a circular bioeconomy. Full article

A sugarcane harvester prototype was fabricated and evaluated to save time, labor, and harvesting expenses, which are included in production costs. The single-row harvester prototype fits the functional needs of the physical qualities of sugarcane and was designed to be installed on a tractor. One serrated edge cutter disc, three forward speeds, and three cutter disc speeds were used to evaluate the performance of the fabricated sugarcane harvester. The results of the technical evaluation showed that the average forward speed was 5 km h⁻¹, and the average cutter disc speed was 2000 rpm by a cutter disc with a serrated edge produced the ideal sugarcane harvesting parameters. The actual field capacity, the power required and the specific energy requirements, were determined. Despite that economic evaluation empathies that the combination of 3.5 km h⁻¹ forward speed and a 1000 rpm cutting speed also achieved the highest benefits ($115.12/ha). Full article
