Actuators

24 pages, 6389 KiB

Open AccessArticle

Local Heat Transfer Analysis of Dual Sweeping Jet, Double Sweeping Jets, and Double Circular Jets Impinging at a Flat Surface

by Muhammad Zubair, Feng Ren and Xin Wen

Actuators 2025, 14(3), 109; https://doi.org/10.3390/act14030109 - 21 Feb 2025

Abstract

A sweeping jet is commonly preferred over a steady jet owing to its ability to better cool the region away from the strong core of an impinging jet. For industrial applications, it is important to study the thermal fields of oscillating jets in [...] Read more.

A sweeping jet is commonly preferred over a steady jet owing to its ability to better cool the region away from the strong core of an impinging jet. For industrial applications, it is important to study the thermal fields of oscillating jets in a multi-jet configuration to focus on the region that falls between the two consecutive fluidic oscillators and, hence, suggest a mechanism to uniformly cool the targeted flat surface. A comparative experimental study of dual sweeping jets (DSJs), double sweeping jets (DbSJs), and double circular jets (DbCJs) was conducted at different jet-to-plate spacings, various Re numbers, and three aspect ratios. The multi-circular and sweeping jets were impinged on a flat hot surface, which was heated at a constant flux of current, and thermocouples were employed to efficiently collect the time-averaged heat transfer distribution along the sweeping and transverse directions. It was determined that heat transfer, in terms of the Nusselt number, generally increased with increasing Re number and reduced the jet-to-wall spacing for the DSJ, DbSJ, and DbCJ, with some minor exceptions. The relative performance of these fluidic devices suggested that the best performance of DSJ was at small spacing and higher Re, DbSJ at moderate spacing and lower Re, and DbCJ at moderate spacing and moderate Re. The mutual comparison showed that along the sweeping motion, in the central region, DbCJ was better than both DSJ and DbSJ; in the right region, DSJ performance was far better than DbCJ and DbSJ; in the left region, DSJ was better than DbSJ when comparing the respective centers of DSJ and DbSJ. The dominance of DSJ over DbSJ at the centers of their respective bodies even extends in the transverse direction. Finally, for higher aspect ratios, the DSJ performed better in the outer regions, while the DbSJ performed well in the central region. Similarly, for both DSJ and DbSJ unanimously, the effect of changing the aspect ratio is interesting as initially, the Nu values increase for a higher aspect ratio, but by increasing the AR further, it causes a divergence of the fluidic volume from the central region to the surrounding region. Full article

(This article belongs to the Special Issue Active Flow Control: Recent Advances in Fundamentals and Applications—3rd Edition)

► Show Figures

Figure 1

59 pages, 1357 KiB

Open AccessReview

Advances in Control Techniques for Rehabilitation Exoskeleton Robots: A Systematic Review

by Gazi Mashud, SK Hasan and Nafizul Alam

Actuators 2025, 14(3), 108; https://doi.org/10.3390/act14030108 - 21 Feb 2025

Abstract

This systematic review explores recent advancements in control methods for rehabilitation exoskeleton robots, which assist individuals with motor impairments through guided movement. As robotics technology progresses, precise, adaptable, and safe control techniques have become accessible for effective human–robot interaction in rehabilitation settings. Key [...] Read more.

This systematic review explores recent advancements in control methods for rehabilitation exoskeleton robots, which assist individuals with motor impairments through guided movement. As robotics technology progresses, precise, adaptable, and safe control techniques have become accessible for effective human–robot interaction in rehabilitation settings. Key control methods, including computed torque and adaptive control, excel in managing complex movements and adapting to diverse patient needs. Robust and sliding mode controls address stability under unpredictable conditions. Traditional approaches, like PD and PID control schemes, maintain stability, performance, and simplicity. In contrast, admittance control enhances user–robot interaction by balancing force and motion. Advanced methods, such as model predictive control (MPC) and Linear Quadratic Regulator (LQR), provide optimization-based solutions. Intelligent controls using neural networks, Deep Learning, and reinforcement learning offer adaptive, patient-specific solutions by learning over time. This review provides an in-depth analysis of these control strategies by examining advancements in recent scientific literature, highlighting their potential to improve rehabilitation exoskeletons, and offering future recommendations for greater efficiency, responsiveness, and patient-centered functionality. Full article

(This article belongs to the Section Actuators for Robotics)

16 pages, 827 KiB

Open AccessArticle

Coupled Dynamics Modeling and Validation of Maglev Vehicle and Bridge Systems

by Fei Zhou and Xiaolong Li

Actuators 2025, 14(3), 107; https://doi.org/10.3390/act14030107 - 21 Feb 2025

Abstract

To address the vehicle-bridge coupling vibration issue of the Qingyuan Maglev Tourist Line, it is necessary to establish a maglev vehicle–bridge coupling dynamics simulation model that reflects the actual line conditions. Based on the vehicle and bridge structural parameters of the Qingyuan Maglev [...] Read more.

To address the vehicle-bridge coupling vibration issue of the Qingyuan Maglev Tourist Line, it is necessary to establish a maglev vehicle–bridge coupling dynamics simulation model that reflects the actual line conditions. Based on the vehicle and bridge structural parameters of the Qingyuan Maglev Tourist Line, this paper utilizes multi-body dynamics simulation software to create a medium–low-speed maglev vehicle dynamics model, and employs finite element software to construct a bridge model. Using the modal reduction method, the bridge finite element model is imported into the vehicle dynamics model through a rigid–flex coupling interface, establishing a medium–low-speed maglev vehicle suspension system–bridge coupling dynamics model. The accuracy of the established coupling simulation model was verified by comparing the simulation data from the coupling model with the dynamic response measured data from the Qingyuan Maglev Tourist Line. Finally, the impact of different control parameters on the vehicle–bridge coupling system was calculated, and the results indicate that selecting appropriate suspension control parameters can reduce the coupling vibration response between the maglev vehicle and the bridge. The main work of this paper is closely related to engineering, modeling based on the actual maglev line’s vehicle and bridge parameters, and validating the model through the dynamic test results of the line, laying the foundation for the suppression of maglev vehicle–bridge coupling vibration and system optimization. Full article

(This article belongs to the Special Issue Advanced Theory and Application of Magnetic Actuators—2nd Edition)

31 pages, 4082 KiB

Open AccessArticle

A Study on a Speed Regulation Method for Mining Scraper Conveyors and a Control Strategy for Permanent Magnet Drive Systems

by Xi Zhang, Mingming Ren, Hongju Wang, Hongyu Xu, Bin Shi and Miaomiao Gao

Actuators 2025, 14(3), 106; https://doi.org/10.3390/act14030106 - 21 Feb 2025

Abstract

To address the mismatch between materials and operational speed in mine scraper conveyors under time-varying load conditions, this paper proposes a methodology for the regulation of speed based on the quantity of coal transported by the scraper conveyor. Furthermore, a vector control strategy [...] Read more.

To address the mismatch between materials and operational speed in mine scraper conveyors under time-varying load conditions, this paper proposes a methodology for the regulation of speed based on the quantity of coal transported by the scraper conveyor. Furthermore, a vector control strategy for permanent magnet synchronous motors (PMSMs) is presented, underpinned by a global fast terminal sliding mode controller. Firstly, a calculation model for the real-time coal volume of the scraper conveyor was developed based on the double-end oblique cutting coal mining technology in fully mechanized mining operations. This model takes into account the operational condition of the shearer and the scraper conveyor. In addition, a graded speed regulation control method was introduced. Secondly, a global fast terminal controller was developed by integrating the features of linear and terminal sliding mode surfaces. An enhanced sliding mode vector control strategy for the permanent magnet drive motor of the scraper conveyor was subsequently proposed. Finally, a simulation and ground test were subsequently performed on the PMSM experimental bench and SGZ2×1200 scraper conveyor to validate the proposed control strategy. The results indicated that the proposed control strategy not only diminished the overshoot of the rotational speed and decreased the dynamic response time but also improved the anti-interference capabilities of the PMSM relative to the original PI control. Moreover, the ground test validated the feasibility of the suggested speed regulation method. Full article

(This article belongs to the Section Control Systems)

26 pages, 2287 KiB

Open AccessArticle

Robust Adaptive Cascade Trajectory Tracking Control for an Aircraft Towing and Taxiing System

by Weining Huang, Pengjie Xu, Tianrui Zhao, Wei Zhang and Yanzheng Zhao

Actuators 2025, 14(3), 105; https://doi.org/10.3390/act14030105 - 20 Feb 2025

Abstract

With the rapid growth of the civil aviation industry, the aircraft towing and taxiing (ATT) system has gained significant attention in the literature. Due to its nonlinear and underactuated characteristics, the path tracking and control of the ATT system is a challenging issue. [...] Read more.

With the rapid growth of the civil aviation industry, the aircraft towing and taxiing (ATT) system has gained significant attention in the literature. Due to its nonlinear and underactuated characteristics, the path tracking and control of the ATT system is a challenging issue. Therefore, in this paper, a robust adaptive cascade control structure is proposed for the path tracking of the ATT system. Firstly, the system description is established via kinematic and dynamics modeling, and the lumped system disturbance is derived for the controller design. Next, the robust adaptive cascade control structure consisting of the adaptive MPC and the CSMC or the RASMC-based dynamics controller is designed with the application of the extended Kalman filter. The system stability in the dynamics loop is verified through the Lyapunov method. The simulation results reveal that the combination of the adaptive MPC and the RASMC can provide a more accurate tracking performance and smoother trajectories under the given disturbances and uncertainties, while both ensuring passenger comfort and meeting the civil aviation regulations, indicating its potential in practical applications. Full article

(This article belongs to the Special Issue Flight Control Systems and Dynamic Simulation for Aerospace Applications)

► Show Figures

Figure 1

25 pages, 4799 KiB

Open AccessArticle

Optimized Structural Design of a Reciprocating Wing for the Reciprocating Airfoil (RA)-Driven Vertical Take-Off and Landing (VTOL) Aircraft

by Johnson Imumbhon Okoduwa, Osezua Obehi Ibhadode and Yiding Cao

Actuators 2025, 14(3), 104; https://doi.org/10.3390/act14030104 - 20 Feb 2025

Abstract

The development of unconventional and hybrid unoccupied aerial vehicles (UAVs) has gained significant momentum in recent years, with many designs utilizing small fans or rotary blades for vertical take-off and landing (VTOL). However, these systems often inherit the limitations of traditional helicopter rotors, [...] Read more.

The development of unconventional and hybrid unoccupied aerial vehicles (UAVs) has gained significant momentum in recent years, with many designs utilizing small fans or rotary blades for vertical take-off and landing (VTOL). However, these systems often inherit the limitations of traditional helicopter rotors, including susceptibility to aerodynamic inefficiencies and mechanical issues. Additionally, achieving a seamless transition from VTOL to fixed-wing flight mode remains a significant challenge for hybrid UAVs. A novel approach is the reciprocating airfoil (RA) or reciprocating wing (RW) VTOL aircraft, which employs a fixed-wing configuration driven by a reciprocating mechanism to generate lift. The RA wing is uniquely designed to mimic a fixed-wing while leveraging its reciprocating motion for efficient lift production and a smooth transition between VTOL and forward flight. Despite its advantages, the RA wing endures substantial stress due to the high inertial forces involved in its operation. This study presents an optimized structural design of the RA wing through wing topology optimization and finite element analysis (FEA) to enhance its load-bearing capacity and stress performance. A comparative analysis with existing RA wing configurations at maximum operating velocities highlights significant improvements in the safety margin, failure criteria, and overall stress distribution. The key results of this study show an 80.4% reduction in deformation, a 43.8% reduction in stress, and a 78% improvement in safety margin. The results underscore the RA wing’s potential as an effective and structurally stable lift mechanism for RA-driven VTOL aircraft, demonstrating its capability to enhance the performance and reliability of next-generation UAVs. Full article

(This article belongs to the Special Issue Aerospace Mechanisms and Actuation—Second Edition)

► Show Figures

Figure 1

18 pages, 5366 KiB

Open AccessArticle

Regenerative Structural Fatigue Testing with Digital Displacement Pump/Motors

by Win Rampen, Marek J. Munko, Sergio Lopez Dubon and Fergus Cuthill

Actuators 2025, 14(3), 103; https://doi.org/10.3390/act14030103 - 20 Feb 2025

Abstract

Historically, a large fraction of fatigue testing of both components and structures has been performed using hydraulic actuators. These are typically driven by servo-valves, which are in themselves very inefficient. But, as most tests involve elastically stressing mechanical components, a lot of stored [...] Read more.

Historically, a large fraction of fatigue testing of both components and structures has been performed using hydraulic actuators. These are typically driven by servo-valves, which are in themselves very inefficient. But, as most tests involve elastically stressing mechanical components, a lot of stored energy could be recovered. Unfortunately, servo-valves are not regenerative—simply metering out fluid in order to relax the system prior to the start of the next cycle. There is much to be gained with a more intelligently controlled system. The FastBlade facility in Scotland uses a new type of regenerative test hydraulics. Digital displacement pump/motors (DDPMs), originated by Artemis Intelligent Power, now Danfoss Scotland, are used to load and unload the test structure directly via hydraulic rams. The DDPMs are driven by induction motors supplied by three-phase frequency converters, each with a very loose speed correction target, such that they can speed up or slow down according to the instantaneous torque exerted by the load. The rotating assembly of the induction motor and DDPM is designed to have sufficient inertia so as to function as a kinetic energy storage flywheel. The loading energy is then cyclically transferred between the rotating inertia of the motor/DDPM and the spring energy in the test structure. The electric motor provides sufficient energy to maintain the target average cyclical shaft speed of the DDPM whilst the bulk of the system energy oscillates between the two storage mechanisms. Initial tests (at low load) suggest that this technique requires only 30% of the energy previously needed. FastBlade is a unique facility built by the University of Edinburgh and Babcock, with support from the UK EPSRC, conceived as a means of testing and certifying turbine blades for marine current turbines. However, this approach can be used in any cyclical application where elastic energy is stored. Full article

(This article belongs to the Special Issue Actuation and Control in Digital Fluid Power)

► Show Figures

Figure 1
