Advanced Methodology and Analysis in Coal Mine Gas Control

The mechanical behavior associated with the flow of ore-rock bulk materials is an important factor leading to the instability and failure of the shaft wall of the ore storage section in ore passes. It is of great significance for accurately understanding the stability failure characteristics of the shaft wall in the ore storage section in the ore-drawing process to understand the flow characteristics and internal mechanical transfer mechanism of ore-rock bulk. The flow characteristics, contact compactness, stress distribution characteristics, and contact force probability distribution of the ore-rock bulk are analyzed by the discrete element method, which realizes the quantitative characterization of the damage degree of ore-rock flow and reveals the damage mechanism of the shaft wall in the storage section of the ore pass. The results show that (1) in the process of ore-rock particle flow in the ore pass storage section, the macroscopic flow pattern of ore-rock particles changes from a “—” shape to a “V” shape, and the friction between ore-rock particles, particles, and the ore-pass wall is an important reason for the change of the macroscopic flow pattern; (2) the probability distribution of contact force strength between the particles decreases exponentially in the whole ore-drawing process, in which the strong force chains play a major role in the stability of the bulk system; and (3) the overpressure frequency and overpressure coefficient could be used to quantitatively characterize the wall damage degree under the action of ore-rock flow. The dynamic lateral pressure fluctuates periodically in exponential form and decreases, and the dynamic load formed by the ore-rock flow mainly acts on the lower part of the ore storage section. Full article

Based on the ‘three highs and one low’ geological conditions of high gas pressure, high gas content, high ground stress, and low permeability in deep coal seams, this study proposes a dual method of hydraulic fracturing of key layers of overlying rock layers combined with pre-extraction of gas via large-diameter caving boreholes. The aim is to unload and dissipate the coal seam by fracturing the overlying key strata, allowing the stress and energy from the excavation working face to be transmitted and transferred to the deep coal seam. Additionally, large-diameter drilling effectively increases the effective drainage radius of the coal seam, resulting in a shorter extraction time. To validate this approach, a fracturing model and a gas extraction model were established for the key layers of the overlying rock layer using the engineering background of the 15,111 excavation working face of a mine in Shanxi. FLAC3D software v.6.0 was utilized to simulate the stress and energy changes of the coal seam before and after fracturing of the key layers, while COMSOL software v.6.0 was used to analyze the gas migration conditions, permeability, and effective drainage radius changes before and after drilling and caving drilling. The findings, combined with the engineering test results, conclude that key strata fracturing combined with large-diameter caving can effectively increase the permeability of coal seams and improve gas extraction. This study serves as a theoretical basis for guiding the design of gas drainage technology under the effects of coal seam pressure relief and permeability enhancement. Full article

A numerical simulation method combining the detailed chemical reaction mechanism of methane deflagration with an approximate real tunnel structure was proposed to confirm whether the unevenness of the tunnel wall during a coal mine gas explosion can be ignored. The approximate real tunnel model and smooth wall tunnel model were developed using 3D modeling methods. The propagation and attenuation processes of shock waves in the two tunnel models, as well as the different dynamic responses of the two tunnel walls, were compared and analyzed. Research results show that the non-uniformity of the tunnel wall decreases the shock wave overpressure and propagation velocity. The peak overpressure reduction value of the shock wave reaches 81.91 kPa, and the shock wave overpressure reaches its peak at an extended maximum time of 7.4 ms. The stress distribution on the approximate real tunnel wall is discontinuous, the propagation speed of stress waves in the bend tunnel is slower, and the duration of high load is relatively low. The displacement of the approximate real tunnel after gas explosion is lower than that of tunnels with smooth walls, and the displacement of most measuring points on the tunnel on the right is only 1/3–1/2 that of the smooth tunnel. Full article

This study aimed to examine gas extraction technology in the goaf of an L-shaped borehole in the mining fissure zone of a short-distance coal seam group. The numerical simulation method was used to analyze the failure law of overlying rock during mining, and a mathematical model was established for gas migration in the mining overburden. Finally, gas extraction tests were performed for the L-shaped borehole in the mining fissure zone. The results showed that as the coal mining project progressed, the damage area of the overlying strata in the goaf became larger, and the plastic damage area of the overlying rock along the strike had a saddle shape, being concave in the middle and convex at both ends. The closer the L-shaped borehole in the mining fissure zone was to the coal seam roof, the greater the amount of air leaking from the working face into the goaf, and the lower the overall gas concentration in the goaf. When the vertical distance of the L-shaped borehole was too high, the ability of the L-shaped borehole to control the gas concentration in the lower goaf was weakened. Moreover, the mining fracture zone was a good space for gas migration and storage. Thus, arranging the L-shaped borehole in this zone can greatly improve the efficiency of borehole gas extraction. According to the overlying rock conditions and mining conditions of Tunlan Mine, the L-shaped borehole was positioned 43 m away from the roof of the coal seam. The extraction rate of the L-shaped borehole reached 9.30 m³∙min⁻¹, and the gas concentration in the corners of the working face was kept below 0.4%, yielding an excellent extraction effect. Full article

In order to study the influence law of gas desorption accumulation and emission characteristics under hydraulic fracturing, this experiment uses coal-rock adsorption–desorption test equipment to carry out isothermal desorption tests of water-bearing coal under various stress paths. The experimental object is anthracite from Four Seasons Chun coal mine in Guizhou Province. In this experiment, the influence law of the desorption emission characteristics of coal under different stresses is analyzed. Research shows that the stress directly affects the gas desorption of coal and plays a decisive role in the gas desorption and emission characteristics of water-bearing coal in the stress-affected zone. Under equivalent gas adsorption of water-bearing coal, the total accumulated gas desorption displayed by coal increases with the increase in stress under certain conditions and the increase rate slows down with the time; coal samples differing in moisture content are subjected to various stress paths, leading to the difference in the total gas desorption. The total accumulated gas desorption displayed by coal with higher moisture content is generally smaller than that with lower moisture content. Through field observation, a zone with high accumulated gas desorption is formed in the stress-affected zone beyond the radius of effective fracture influence, generating an imbalance of gas desorption and emission. The study results are of theoretical and practical engineering significance for the prevention and control of stress-induced disasters and gas disasters in deep coal seams. Full article

The mechanical properties of water-rich coal and rock in a subzero environment are very different from those at room temperature, which causes many unexpected hazards for projects. In this study, coal and rock samples subjected to the coupled effects of water, temperature, and dynamic loads were taken as the research object, and the discussion was shaped around their mechanical properties. The crack evolution trend and different gradient impact velocities were determined using a split-Hopkinson pressure bar (SHPB). Multiple fractals were based on high-speed digital image correlation (HS-DIC) technology and the quality-screening method; the evolution trend of the surface cracks in the crushing process and the distribution characteristics of the specimen fragments after crushing were examined from the perspective of fractals. This provided a powerful supplement to the existing research system on the problem of mining via the freezing method, and it accounted for the shortcomings of the existing research to a certain extent. In this research, the results mainly showed four points: (1) The coal samples were determined to have a wave velocity between 1.68 and 2.01 km/s, while the rock samples were between 2.24 and 2.61 km/s. Under the same conditions, the rock’s resistance to deformation and damage was greater than that of coal. (2) In the saturated state, the plastic strength of the coal and rock samples was greater than that in the dry state, due to the strengthening of their internal stresses caused by the presence of fissure water. (3) With decreasing temperature, the degree of the dynamic compression factor of coal and rock showed a trend of initially increasing, then decreasing, and then increasing. With the increase in the loading rate, the destruction of the coal and rock was more intense, and the destruction process was accelerated. (4) After the saturated coal and rock samples were frozen, their interiors were affected by the dual factors of contraction under the influence of temperature and expansion under the influence of the freezing expansion force. The internal fissures closed or shrank, and the water in the pores turned into ice, leading to an increase in pore volume. Full article

When rockbursts and coal and gas outbursts simultaneously occur in a coal mine, changes in gas adsorption (concentration of ambient methane) and displacement of coal and rock must occur. The co-associated minerals in coal reservoirs can affect the mechanical properties and methane adsorption capacity, which are commonly disregarded. It is important to construct compound molecular structure models of coal and rock and conduct molecular dynamic simulations to gain a microscopic understanding of underground disasters. In this work, the molecular structure models of anthracite and coking coal–rock compound models containing different contents of calcite and kaolinite were constructed, and the methane adsorption amount and mechanical properties considering temperature, pressure, and mineral contents were simulated and analysed. The results showed that the methane adsorption amount of the compound models increased rapidly, then increased moderately, and stabilized eventually with increasing adsorption pressure, and the Langmuir fitting findings were good. The saturation adsorption amount of methane in the coal models linearly decreased with increasing temperature, while the methane adsorption heat increased. The presence of minerals adsorbed a certain amount of methane, and the methane adsorption amount increased with increasing mineral contents. The mechanical properties of coal molecules changed when mineral molecules such as calcite and kaolinite were present, which had opposite contribution effects. The addition of kaolinite minerals to the coal molecular model always increased the bulk modulus and shear modulus, while the addition of calcite decreased the bulk modulus of the anthracite, causing an increase in the brittleness of the models. The results of the study further explain the adsorption behaviour and mechanical properties of methane in coal and minerals. Full article

In order to effectively control the stability of surrounding rock in ultra-large span open-off cuts by employing the techniques of support strength theory calculations and analogical application methods, two sets of rational support schemes were proposed, and the optimal design of active support parameters in thick coal seams with ultra-large span open-off cuts was explored by using theoretical analysis, numerical simulation, and field experiments. The results demonstrated that the span is one of the key factors influencing the stability of the roadway roof, exhibiting an inverse quadratic relationship with the peak stress borne by the roadway roof. By utilizing the pre-stressing force of anchor cables and support strength formulas, two sets of active support schemes for controlling the surrounding rock in thick coal seams with ultra-large span open-off cuts were established, and an optimized support scheme was obtained through numerical simulation. These findings provide references and guidance for related mining engineering under actual conditions in mines. Full article

To improve the accuracy of gas outburst early warning, this paper proposes a gas outburst risk warning model based on XGBoost–GR–stacking. The statistic is based on gas outburst data from 26 mines and establishes a data generation model based on XGBoost. The obtained virtual datasets are analyzed through visualization analysis and ROC curve analysis with respect to the original data. If the augmented data has an ROC area under the curve of 1, it indicates good predictive performance of the augmented data. Grey correlation analysis is used to calculate the grey correlation degrees between each indicator and the “gas emission”. The indicator groups with correlation degrees greater than 0.670 are selected as the main control factor groups based on the sorting of correlation degrees. In this study, SVM, RF, XGBoost, and GBDT are selected as the original models for stacking. The original data and virtual data with correlation degrees greater than 0.670 are used as inputs for SVM, RF, XGBoost, GBDT, and stacking fusion models. The results show that the stacking fusion model has an MAE, MSE, and R2 of 0.031, 0.031, and 0.981. Comparing the actual and predicted values for each model, the stacking fusion model achieves the highest accuracy in gas outburst prediction and the best model fitting effect. Full article

In underground coal mines, the stability of the retracement channel in the surrounding rock is crucial for the safe and efficient retracement of the equipment and to guarantee the continuity of the retracement work. To reveal the deformation and damage mechanism of the surrounding rock of an auxiliary retracement channel (ARC) and the determination method for the reasonable spacing of two retracement channels during the end of the mining period, the deviatoric stress field in front of the working face and the change in the shape characteristics of the plastic zone in the ARC are investigated in this paper. The formation of ultimate stress equilibrium, high deviatoric stress, decreasing deviatoric stress, and low deviatoric stress environments in front of the working face during the end of mining occur successively, and the different deviatoric stress environments are the main reasons for the different shape characteristics of the plastic zone in the surrounding rock. The changes in the shape characteristics of the plastic zone correspond to the changes in the shape characteristics in the zone with deviatoric stress and exhibit the following order: full plastic deformation zone, butterfly-shaped zone, elliptical zone, and circular plastic zone. A reasonable spacing determination method for the two retracement channels is proposed: the ARC is arranged in the decreasing deviatoric stress environment, where the surrounding rock plastic zone shape is elliptical, and the ARC is relatively stable. Based on this research result, the spacing of the double retracement channels at the Lijiahao 22-116 working face was determined to be 25 m, which achieved a positive application effect and allowed the safe and efficient retracement of the working face equipment. Full article

Coal mine gas accidents will cause great economic losses and casualties. It is of great significance to find out the essential causes of coal mine gas accidents and put forward measures to prevent them. In this paper, 110 coal mine gas accidents which occurred in China from 2001 to 2022 are selected to analyze the causes of the accidents by extracting the keywords of human factors, equipment factors, environment factors, and management factors from the accident investigation reports. Firstly, the accident statistical analysis is carried out from three dimensions of factor frequency, accident type, and accident grade. Secondly, the Apriori algorithm is used for data mining to obtain frequent item sets and association rules of coal mine gas accident factors. Finally, the coal mine gas accident cause chains which are obtained by using the association rule. The frequent terms of 9 factors, 23 association rules, and 3 coal mine gas accident cause chains are obtained. The results show that the production of coal mine enterprises by illegal organizations is an important reason for the occurrence of coal mine gas accidents. The lack of good management culture easily leads to habitual violations of personnel and decision-making errors, and then causes equipment problems, reflected in the ventilation system which is not perfect, resulting in gas accumulation. The occurrence of coal mine gas accidents can be prevented to a large extent by preventing the absence of good management culture in enterprise management and the occurrence of illegal production behaviors. Full article
