Search Results (21)

The deep shale gas resources of the Sichuan Basin are abundant and constitute an important component of China’s natural gas production. Complicated by fault zones and other geostructures, the in situ stress state of the deep shale gas reservoirs in the Luzhou block remains poorly understood. This study integrated multiple datasets, including acoustic logging, diagnostic fracture injection testing (DFIT), imaging logging, and laboratory stress measurements, for calibration and constraint. A high-precision geomechanical model of the Luzhou block was constructed using the finite element method. This model characterizes the geomechanical properties of the reservoir and explores its applications in optimizing shale gas horizontal well placement, drilling processes, and fracture design. The study findings indicate that the Longmaxi Formation reservoir demonstrates abnormally high pore pressure, with gradients ranging from 16.7 to 21.7 kPa/m. The predominant stress regime is strike-slip, with an overburden stress gradient of 25.5 kPa/m and a minimum horizontal principal stress gradient ranging from 18.8 to 24.5 kPa/m. Based on a three-dimensional geomechanical model, a quantitative delineation of areas conducive to density reduction and pressure control drilling was conducted, and field experiments were implemented in well Y65-X. Utilizing an optimized drilling fluid density of 1.85 g/cm³, the deviated horizontal section was completed in a single trip, resulting in a 67% reduction in the drilling cycle compared to adjacent wells. Similarly, the Y2-X well demonstrated a test daily output of 506,900 cubic meters following an optimization of segmentation clustering and fracturing parameters. Studies indicate that 3D geomechanical modeling, informed by multi-source data constraints, can markedly enhance model precision, and such geomechanical models and their results can effectively augment drilling operational efficiency, elevate single-well production, and are advantageous for development. Full article

Poor wellbore cleaning is a significant challenge in oil drilling, primarily due to the accumulation of cuttings at the bottom of the well, particularly in deviated and horizontal wells. This study addresses this issue by employing Computational Fluid Dynamics (CFD) with the commercial software ANSYS FLUENT (2023-R1) to simulate a solid–liquid multiphase flow in an annulus. The primary objective is to analyze the cuttings concentration, pressure loss, and solid velocity profiles across various drilling parameters, including drill pipe rotation, the flow rate, rate of penetration, inclination angle, and fluid rheology. Our results underscore the critical role of these parameters in enhancing cuttings transport efficiency. Specifically, the drill pipe rotation, flow rate, and rate of penetration emerge as the most influential factors affecting the wellbore cleaning performance. With a validated model exhibiting an average error of 4.24%, this study provides insights into optimizing drilling operations to improve wellbore cleaning and increase hydrocarbon recovery. Full article

Titanium alloy is widely used as oil drill pipe material because of its light weight, high strength, good toughness, corrosion resistance, fatigue resistance, and good process performance. However, due to its low hardness, poor wear resistance, serious oxidation at high temperature (700 °C), and difficulty in lubrication, in oil and gas field exploration and development drilling, especially in deep wells, high displacement wells, horizontal wells, and highly deviated wells, wear and tear are prone to occur. The application and development of titanium alloys are greatly limited. This paper introduces the research status of the common surface modification technologies of titanium alloys, such as laser cladding, magnetron sputtering, plasma spraying, micro arc oxidation, etc. It points out the improvement effect of various modification technologies on the wear resistance and high-temperature oxidation resistance of titanium alloys and discusses the advantages and disadvantages of various modification technologies. A proposed method for enhancing the wear resistance and high-temperature oxidation resistance of titanium alloys was finally introduced, and its potential for future development was investigated. Full article

This paper presents a coupled computational fluid dynamics–discrete element method (CFD–DEM) simulation to predict cuttings transport by the drilling fluid (mud) in different oil well drilling conditions. The mud rheology is expressed by the Herschel–Bulkley behaviour and modelled in a Eulerian framework (CFD), while the cuttings are modelled using the Lagrangian approach (DEM). In this work, the effects of drill string rotation, inclination angle, cutting size, mud rheology, and annular velocity on cleaning efficiency are investigated. It is found that increasing the well deviation from vertical to horizontal leads to a higher cuttings concentration. However, at low annular velocity, the cuttings concentration for the inclined (45-degree) annulus is found to be higher than the horizontal one due to the sliding motion of cuttings on the lower section of the annulus. Overall, the drill pipe rotation has little effect on decreasing the cuttings concentration, but the effect is more pronounced at low annular velocity. Full article

In recent years, the development of two offshore low-permeability oil fields has revealed unexpected challenges. The actual productivity of these fields significantly deviates from the designed capacity. Some wells even outperform the expectations for low-permeability limestone fields. This discrepancy primarily stems from a lack of accurate understanding of natural fractures before and after drilling, resulting in substantial errors in capacity assessment. This paper addresses these challenges by proposing a new production capacity model and evaluation method for both vertical and horizontal wells in low-permeability limestone reservoirs. The method leverages logging curve data, incorporating vertical gradation and fractal analysis to effectively represent the fracture’s complexity and connectivity. It uniquely considers factors such as fracture fractal dimensions, threshold pressure, and stress sensitivity, significantly enhancing prediction accuracy. Furthermore, by analyzing the longitudinal gradient in logging curves, the method effectively identifies strong heterogeneity, leading to more accurate capacity evaluations in actual fields. The results demonstrate that our model reduces the average prediction error to less than 15%, markedly outperforming traditional methods. Calculation results of the newly developed capacity formula align closely with actual production data and tracer test results, showcasing its practical applicability and potential for widespread use. This study notably advances the evaluation of reasonable production capacity in similar offshore reservoirs. Full article

Production logging (PL) instruments play a pivotal role in the comprehensive management and monitoring of oil and gas reservoirs. These devices facilitate the resolution of complex flow diagnosis challenges throughout the life cycle of hydrocarbon field exploitation. However, the advent of highly deviated well drilling technology has exposed certain limitations inherent in conventional centralized logging sensing techniques. When fluid flow within horizontal wells becomes segregated or even laminar, these traditional methods struggle to accurately decipher the zonal productions of oil, gas, and water. To address this challenge, multi-array production logging tools were developed in the late 1990s. Historically, these tools were characterized by considerable lengths, reaching up to 30 feet for an entire suite incorporating flow speed and holdup sensors that were not always collocated. Despite the integration of multiple sensors, uncertainties in determining flow profiles persisted. In this paper, we propose a novel integrated multi-parameter evaluation method based on measurements from a recently developed ultracompact flow array sensing tool, aimed at enhancing the accuracy of reservoir evaluation. The validity of the multi-parameter method is substantiated through a comparison of the new tool with an industry benchmark array PL tool on the same well. By combining the monitoring results, an optimization strategy for oil and gas extraction is presented, which is expected to improve the oil and gas recovery rate, thereby providing guidance for subsequent extraction endeavors. Moreover, we demonstrate how this innovative integrated workflow significantly enhances energy savings and efficiency, further underlining its value in modern oil and gas field management. Full article

As global oil demand continues to increase, in recent years, countries have continued to expand the development of oil reserves, highlighting the importance of oil. In order to adapt to different strata distribution conditions, domestic drilling technology is becoming more and more perfect, resulting in a gradual increase in horizontal and inclined wells. Because of the influence of various downhole factors, the flow pattern in the wellbore will be more complex. Accurately identifying the flow pattern of multiphase flow under different well deviation conditions is very important to interpreting the production log output profile accurately. At the same time, in order to keep up with the footsteps of artificial intelligence, big data and artificial intelligence algorithms are applied to the oil industry. This paper uses the GA-BP neural network and random forest algorithm to conduct fluid flow pattern prediction research on the logging data of different water cuts at different inclinations and flow rates. It compares the predicted results with experimental fluid flow patterns. Finally, we can determine the feasibility of these two algorithms for predicting flow patterns. We use the multiphase flow simulation experiment device in the experiment. During the process, the flow patterns are observed and recorded by visual inspection, and the flow pattern is distinguished by referring to the theoretical diagram of the oil-water two-phase flow pattern. The prediction results show that the accuracy of these two algorithms can reach 81.25% and 93.75%, respectively, which verifies the effectiveness of these two algorithms in the prediction of oil–water two-phase flow patterns and provides a new idea for the prediction of oil–water two-phase flow patterns and other phases. Full article

The drilling industry has evolved significantly over the years, with new technologies making the process more efficient and effective. One of the most crucial issues of drilling is borehole cleaning, which entails removing drill cuttings and keeping the borehole clean. Inadequate borehole cleaning can lead to drilling problems such as stuck pipes, poor cementing, and formation damage. Real-time drilling evaluation has seen significant improvements, allowing drilling engineers to monitor the drilling process and make adjustments accordingly. This paper introduces a novel real-time borehole cleaning performance evaluation model based on the transport index (TI_m). The novel TI_m model offers a real-time indication of borehole cleaning efficiency. The novel model was field-tested and validated for three wells, demonstrating its ability to determine borehole cleaning efficiency in typical drilling operations. Using TI_m in Well-A led to a 56% increase in the rate of penetration (ROP) and a 44% reduction in torque. Moreover, the efficient borehole cleaning obtained through the use of TI_m played a significant role in improving drilling efficiency and preventing stuck pipes incidents. The TI_m model was also able to identify borehole cleaning efficiency during a stuck pipe issue, highlighting its potential use as a tool for optimizing drilling performance. Full article

The main challenge in deviated and horizontal well drilling is hole cleaning, which involves the removal of drill cuttings and maintaining a clean borehole. Insufficient hole cleaning can lead to issues such as stuck pipe incidents, lost circulation, slow rate of penetration (ROP), difficult tripping operations, poor cementing, and formation damage. Insufficient advancements in real-time drilling evaluation for complex wells can also lead to drilling troubles and an increase in drilling costs. Therefore, this study aimed to develop a model for the hole-cleaning index (HCI) that could be integrated into drilling operations to provide an automated and real-time evaluation of deviated- and horizontal-drilling hole cleaning based on hydraulic and mechanical drilling parameters and drilling fluid rheological properties. This HCI model was validated and tested in the field in 3 wells, as it was applied when drilling 12.25″ intermediate directional sections and an 8.5″ liner directional section. The integration of the HCI in Well-A and Well-B helped achieve much better well drilling performance (50% ROP enhancement) and mitigate potential problems such as pipe sticking due to hole cleaning and the slower rate of penetration. Moreover, the HCI model was also able to identify hole-cleaning efficiency during a stuck pipe issue in Well-C, which highlights its potential usage as a real-time model for optimizing drilling performance and demonstrates its versatility. Full article

During the drilling of highly deviated and horizontal wells, a pump shutdown causes drill cuttings to settle and form a cuttings bed in the annulus. This study investigated the incipient motion law of the particles on the cuttings bed surface when the drilling fluid starts circulating again. This work could help field engineers to determine a reasonable incipient pump displacement to improve hole-cleaning efficiency. In this study, the effects of the well inclination angle, cuttings size, and different cuttings densities on the critical velocity of particle motion are analyzed experimentally, using a large-scale flow loop. Next, based on a stress analysis of the particles on the cutting bed surface and on the boundary layer flow around the particles, an analytical formula for the surface shear force of the drilling fluid on particles is derived and a critical velocity model for incipient motion is established. Verification is then carried out and combined with the experimental results. This study has important implications for the design of drilling operations and for the management of cuttings transport in oil and gas wells. It can guide the setting and prediction of pump discharge to improve hole-cleaning efficiency. Full article

The relevance of the application of hydraulic thruster technology is determined by the technological limitations of drilling both vertical and horizontal wells. The existing experimental studies confirm the effectiveness of the technology, but its widespread implementation is hindered by the lack of scientific foundations for its operation in combination with a downhole motor and bit. Our research methodology includes methods for analyzing scientific and technical information as well as methods of numerical modeling using programming languages and ready-made software packages for CFD calculations. Verification of the simulation results was carried out on the basis of the experimental field studies previously conducted with the participation of the authors of the article. This article presents the results of the analysis of the current state of the problem and computer physical and mathematical modeling of the work of the thruster together with the bit and downhole motor when drilling a deviated section of a well. Based on the simulation results, the expediency of using hydraulic thrusters in the practice of drilling wells with the possibility of predicting and operatively regulating the operation parameters of the “Hydraulic Thrusting Device—Downhole Motor—Bit” system is theoretically substantiated and scientifically confirmed. Full article

With the development of different segments within the drilling technology in the last three decades, well drilling has become possible in harsh downhole conditions. The vertical well provides access to oil and gas reserves located at a certain depth directly below the wellsite, and a large number of vertical wells are required for the exploitation of hydrocarbons from spatially expanded deposits. However, the borehole can deviate from the vertical well, which means that the target zone can be reached by a horizontal directional well. With this type of well, especially in the case of drilling an extended-reach well (ERW), the length of the wellbore in contact with the reservoir and/or several separate reservoirs is significantly increased, therefore, it is a much better option for the later production phase. Unfortunately, the application of extended-reach drilling (ERD technology), with all of its advantages, can cause different drilling problems mostly related to the increased torque, drag, hole cleaning and equivalent circulation density (ECD), as well as to an increase in the well price. Overcoming these problems requires continuous operational change to enable operators to address downhole challenges. Today, the longest well reaches 15,240 m (50,000 ft), which raises the question of the technological and economic feasibility of this type of drilling project, especially with the lower oil price on the energy market. This paper provides a comprehensive overview of extended-reach drilling technology, discusses the main problems and analyzes current achievements. Full article

Downhole vibrations caused by rock breaking when drilling through pebbled sandstone formations negatively affect the rate of penetration (ROP) and the safety of downhole tools. Therefore, it is of great significance to study the cutting characteristics of pebbled sandstone and find a method of reducing the drilling vibrations of pebbled sandstone formations. Based on the DEM (discrete element method), a simulation model of pebbled sandstone considering the random filling of high-strength gravels was established by using the random polygon distribution method. The influence of gravel content on the strength parameters and the breaking state of the pebbled sandstone samples was analyzed. Additionally, a DEM model of PDC cutting rocks loaded by a spring–mass system was established, and the Stribeck effect of contact friction between the PDC cutter and the rock was analyzed. The periodic vibration and the stick–slip phenomenon of the cutting system during the drilling process were presented by this model. The model was employed to simulate and explore the influence of composite impact load on stick–slip vibration during PDC cutting of pebbled sandstone. The simulation results showed that the composite impact load had a more obvious effect on mitigating the vibration of PDC cutting of pebbled sandstone under the condition of a higher horizontal impact amplitude coefficient (q_h = 40%). Based on the simulation results, a composite impactor with a large impact angle α = 70° was selected to conduct the field tests in the pebbled sandstone formation of Well T1. The results showed that, compared to conventional drilling, the average WOB (weight on bit) of the section drilled with the composite impactor decreased by 57.13%, the standard deviation of the WOB decreased by 57.29%, and the average ROP increased by 98.31%. The employing of composite impactors in pebbled sandstone formations can significantly reduce drilling vibration, improve ROP, and protect bits and downhole instruments. Full article

The design of the wellbore trajectory directly affects the construction quality and efficiency of drilling. A good wellbore trajectory is conducive to guiding on-site construction, which can effectively reduce costs and increase productivity. Therefore, further optimization of the wellbore trajectory is inevitable and necessary. Based on this, aiming at the three-segment, five-segment, double-increase-profile extended reach wells, this paper considered the constraints of formation wellbore stability; formation strength; and the determination of the deviation angle, deviation point position, and target range by the work of deflecting tools. In addition, the optimization objective function of the shortest total length of the wellbore, minimum error of the second target, lowest cost, minimum friction of the lifting and lowering string, and minimum torque of rotary drilling were proposed and established. The objective function of the longest extension limit of the horizontal section of the extended reach well is established. Taking the 14-8 block of the Lufeng Oilfield in the eastern South China Sea as an example, the actual data of the field were modeled, and the independence of the objective function was verified by comparing the number of non-inferior solutions of the two objective functions. By normalizing simplified to double-, three-, and four-objective functions, using a genetic algorithm and particle swarm optimization results, it can be found that the new method of optimization design established in this paper has an obvious optimization effect compared with the original design. Full article

Borehole instability problems are commonly encountered while drilling highly deviated and horizontal shale gas wells within the shale formations associated with high-dip bedding planes. An integrated rock mechanical study is described in this paper to evaluate the risk of the borehole instability problems in this area. First, a set of uniaxial compressive tests are carried out to measure the strength of the bedding shales on cores with different angles between the load direction and the bedding planes. A critical strength criterion is then proposed based on the test results. Next, the stress state of the borehole with arbitrary inclination and azimuth is determined through coordinate transformations. Finally, through combining the strength criterion and the stress state of the borehole, the risk of borehole instability is investigated for deviated and horizontal wells in shale formations with different bedding dips (0–90°) and dip directions (45° and 90° to the direction of minimum horizontal stress ${\sigma }_h$). The results show the dependence of borehole instability on the orientation of bedding planes of the formation as well as inclination and azimuth of the well. The most desirable borehole trajectory from the viewpoint of borehole stability is at the direction normal to the bedding planes. For a horizontal well specifically, if the bedding direction is perpendicular to the direction of ${\sigma }_h$, the risk of instability is relatively high for most drilling directions except drilling along the dip direction of the bedding planes. However, if there is a moderate acute angle (e.g., 45°) between the dip direction and the direction of ${\sigma }_h$, the risk of instability is relatively low for most drilling directions unless drilling along the direction of ${\sigma }_h$. Full article
