Search Results (23)

The settlement and deformation of abandoned mining tunnels can lead to cracking, deformation, or even the collapse of surface structures. Recently, a dual-direction, four-lane expressway, designed a speed of 100 km/h, is planned to be constructed between Yuanling County and Chenxi County. This expressway will pass through a long-abandoned refractory clay mining area in Chenxi County. This study focuses on this abandoned mining area and employs the Electrical Resistivity Tomography (ERT) method to investigate the underground conditions, aiming to determine the location and scale of the subterranean goaf. A total of five survey lines were deployed for the investigation. The inversion results indicate the presence of five low-resistivity anomalies in the underground structure (with six low-resistivity anomalies identified along line L1). These low-resistivity anomalies are preliminarily interpreted as subsurface cavities. Subsequent borehole verification revealed that the five low-resistivity anomalies correspond to a total of eight water-filled cavities, including six abandoned mining tunnels and two karst caves. At the location K33+260~K33+350, a large low-resistivity anomaly was identified which actually consisted of three closely spaced water-filled abandoned mining tunnels. Additionally, the surrounding strata primarily consisted of fractured mudstone, which has a high water content and thus exhibits low resistivity. These two factors combined resulted in the three water-filled abandoned mining tunnels appearing as a single large low-resistivity anomaly in the inversion profile. Meanwhile, at K33+50~K33+110, two water-filled abandoned mining tunnels were found. These tunnels are far apart along line L1 but are relatively close to each other on the other four survey lines. Consequently, in the inversion results, line L1 displays these as two separate low-resistivity anomalies, while the other four survey lines show them as a single large low-resistivity anomaly. Based on the 2D inversion results, a 3D model of the study area was constructed. This model provides a more intuitive visualization of the underground cavity structures in the study area. The findings not only serve as a reference for the subsequent remediation of the goaf area but also offer new insights into the detection of abandoned mining tunnels. Full article

Existing coal filling mining technologies face significant challenges of controlled surface subsidence, efficient utilization of waste rock in coal mines, and a shortage of adequate filling materials. This study introduces an innovative cut-and-fill mining method designed to strategically partition the goaf into cutting and filling zones. In the cutting zone, in situ filling materials are employed to construct waste rock column supports adjacent to the filling zone, thereby achieving controlled surface subsidence. This approach is integrated with long-wall mining operations and implemented using advanced, comprehensive equipment. FLAC3D simulations were conducted to investigate the patterns of stress distribution, surface deformation, and plastic zone formation within the mining field. With the implementation of the cut-and-fill mining balance, key observations include a reduction in maximum principal stress near the center of the goaf, an increasing trend in minimum principal stress, regular displacement distributions, and intact plastic zones positioned vertically away from the stope and horizontally close to the center of the stope. Compared to traditional caving methods, the cut-and-fill technique significantly reduces maximum vertical displacement, by nearly 95%, and maximum horizontal displacement, by approximately 90%. Additionally, it minimizes energy accumulation, lowers overall energy release, and prolongs the release period. Importantly, this method facilitates the resourceful utilization of approximately 800 million tons of waste rock, potentially leading to an estimated reduction of 500 million tons in CO₂ emissions. By achieving a balance of three effects—harmonizing coal extraction and filling capacity, aligning the supply and demand of filling materials, and optimizing the balance between filling costs and mining benefits—this method provides a sustainable and eco-friendly solution for the coal mining industry. The findings of this study are crucial for guiding the industry towards more environmentally responsible practices. Full article

The collapse of surface goaf beneath highways can result in instability and damage to roadbeds. However, filling the goaf areas with foam concrete can significantly enhance the stability of the roadbeds while considerably reducing the costs of filling materials. This study analyzes the effects on destructive characteristics, mechanical properties, stress–strain curve features, and relevant metrics, while also observing the microstructure of basalt fiber-calcined gangue-silty clay foam concrete (BF-CCG-SCFC). The results indicate that the water–binder ratio significantly influences the cubic compressive strength, split tensile strength, and fluidity of BF-CCG-SCFC. Silty clay reduces the cubic compressive strength, split tensile strength, and fluidity of BF-CCG-SCFC. Conversely, an appropriate amount of calcined gangue and basalt fiber significantly increases the cubic compressive strength and split tensile strength, while decreasing fluidity. To satisfy the strength and fluidity requirements of the filler material in hollow areas, the optimal water–binder ratio for BF-CCG-SCFC is 0.55, the ideal mixing ratio of calcined gangue to silty clay is 2:2, and the basalt fiber content should be 1%. The study examines the influence of varying water–binder ratios, the combined proportions of calcined gangue and silty clay, and different basalt fiber contents on the elastic modulus, peak stress, and peak strain of BF-CCG-SCFC. Additionally, the water–binder ratio influences the matrix strength through the non-hydration reactions of doped particles, while gangue and clay induce a “gradient hydration effect” during the hydration process. The incorporation of basalt fibers enhances the mechanical interlocking between the fibers and the matrix. Full article

The goaf treatment of underground metal mines is an important link in mining, and it is particularly important to master the laws of overlying rock strata and surface movement of goaf. In this paper, Persistent Scatterer Interferometric Synthetic Aperture Radar (PS-InSAR) technology is used to monitor the surface subsidence of the Taibao lead-zinc mine, and the surface subsidence laws of goaf-closure, partial-filling, and full-filling treatments are analyzed by the time-series method. The findings indicate that the surface subsidence of the closed goaf is solely governed by the pillars, with the quality of these pillars playing a pivotal role in controlling such subsidence. Factors like stope span also influence the surface subsidence of partially filled goaf. Prior to compaction, it is primarily the pillars that control surface subsidence; however, after compaction, filling and pillars jointly regulate this phenomenon. Notably, in filled goaf, the quality of both roof and pillars significantly impacts surface subsidence. Before compaction occurs, control over surface subsidence is not evident, yet post-compaction, the filling is effective and tends to stabilize this process. The research findings are significant in enhancing goaf’s treatment efficacy, mitigating surface damage and minimizing ecological environmental impact. Full article

Against the background of the prevailing green development paradigm, numerous coal mines have embraced the adoption of gob-side entry retaining mining technology. The most commonly employed form of gob-side entry retaining involves building an artificial wall along the edge of the goaf behind the working face to maintain the roadway. The pivotal challenge in gob-side entry retaining lies in the roadside support. Currently, commonplace concrete serves as the predominant material for the roadside filling body. Nevertheless, traditional concrete exhibits drawbacks, including inadequate tensile strength and poor toughness, leading to wall cracks or even collapses in the retaining wall. Steel fiber, a frequently employed reinforcement and toughening agent in concrete, has found widespread application in the construction sector and other fields. However, its use as a roadside filling material in underground coal mines remains infrequent. Therefore, in this paper, the flow and mechanical properties of steel fiber concrete were tested and analyzed, and field industrial tests were conducted. Results of indoor experiments show that steel fibers reduce the slump of concrete. The addition of steel fibers shifted the pore compacting stage, linear elasticity stage, and destabilization stage forward and improved the post-peak bearing capacity. The addition of steel fibers makes the concrete compressive and tensile strength show a “first increase and then decrease” trend; both peaked at 1.5%, and the increase in tensile strength is more pronounced. Steel fibers enhance the strength of compressive strength of concrete at an early age, weaker at a late age, and tensile strength inversely. The addition of steel fiber can change the concrete matrix from tensile damage to shear damage, and the toughness index shows the trend of “first increase and then decrease”, and reaches the peak value when the dosage is 1.5%. Industrial test results show that steel fiber concrete as a roadside filling body can reduce the surrounding rock surface displacement and bolt (cable) force. Full article

The deformation and re-crushing characteristics of different lithological caving crushed gangues in mine goaf directly affect the overburden strata movement, which significantly affects the surface subsidence of mining goaf. The effect of particle size on the re-crushing characteristics of different lithological caving crushed gangues in mine goaf is investigated in this study based on an innovative compression–AE (acoustic emission) measuring method. The results showed the following: (1) The compression deformation was divided into three stages: rapid, slow, and stable compaction. With the increase in axial pressure, the large particle skeletons were destroyed, medium particles were displaced and slid, and small particles filled the pores. (2) For singular lithologies, stress was positively correlated with pressure, and porosity was negatively correlated with stress. The composite sample was between the singular gangue samples. (3) The fractal dimension of crushed gangue samples was exponentially related to the proportion of gangue in singular and combined lithologies. (4) The cumulative AE count and energy of the combined lithological gangue samples were between those of the singular samples. The research results provide a theoretical foundation for further research into the characteristics of the overlying strata, surface movement, and safety management of the goaf. Full article

Strip filling mining in a goaf is of great significance for solving the ‘three under’ coal-pressure and mining-area ecological environment problems in Central and Eastern China, but the disturbance characteristics of filling parameters on overlying rock are not clear at present. Taking the geological conditions of the CT30101 working face in Mahuangliang coal mine and the short-wall interval strip filling as a background, the strength parameters (cohesion and friction angle), deformation parameters (elastic modulus and Poisson’s ratio), and structural parameters (strip width and spacing) of the filling body were selected as experimental factors, and the maximum settlement of the direct roof and the ground surface was taken as the evaluation index. The influence degree of each factor was quantitatively characterized via a variance analysis and an F test, and the main control factors of the strip filling overburden settlement were proposed. The roof and surface displacement, the stress evolution law of the filling body, and the shape change of the surrounding rock plastic zone under different levels of main control factors in the entire process of mining filling coupling were analyzed in detail. The results showed that the cohesion of the backfill had a highly significant impact on the direct roof settlement, the strip spacing and the friction angle of backfill had a significant impact on it, the cohesion of the backfill and the strip spacing had a certain impact on the surface settlement, and the two had a cross-coupling effect. In the process of mining and filling, the stress evolution of the filling body was extremely complex, and it finally presented a saddle shape that was high on both sides and low in the middle; the majority of the strata and the filling body primarily exhibited shear damage, with a small amount of tensile failure zones appearing only in the direct roof and mid-section of the filling body. The above conclusions have a certain guiding significance for the optimal design of strip filling in a goaf. Full article

The particularity of the occurrence conditions of the ore body in Xianglushan Tungsten Mine determines the mining form of the ore body and the particularity of the ground pressure distribution after mining. A large number of mined-out areas, supporting pillars, and natural and human factors have formed a comprehensive disaster environment. This can lead to frequent disasters, great harm, serious economic losses, and the necessity of severe environmental protection operations in the mine. This study aims to establish a microseismic monitoring system according to the actual needs of the site and to reveal the law of ground pressure manifestation by analyzing the distribution characteristics of microseismic events; to analyze the occurrence stability of the goaf; further verify it laterally; and finally, demonstrate the feasibility and effectiveness of the microseismic monitoring sensor system. In view of the current ground pressure problem in Xiangxuoshan tungsten mine, the stress change characteristics during dynamic mining and filling were obtained through comparative analysis of different perspectives such as surface change, energy release, and mining loudness, and key areas were identified to improve the reliability of underground ground pressure monitoring. The results show that the process of deposit destabilization caused by ore body mining can be further analyzed by microseismic monitoring, and the combination of surface settlement, mining intensity, and energy release can verify the accuracy of stress distribution and ground pressure transfer. In turn, the general reliability of underground ground pressure hazard warning is empirically improved. Full article

Mining systems for ore deposit extraction with the backfilling of the goaf solve the problem of preserving the surface and the complete extraction of rich ores. This paper considers the filling of mined-out stopes with a viscous fluidal solution for the formation of an artificial strong massif, which results in a conglomerate formed on contact with the ore deposit. It was established that exogenous fracturing at the Pivdenno-Belozirske deposit significantly affects the stability of the sides and ceilings in the chamber. This phenomenon can be observed at the first stage of processing. At chambers (the second stage of processing), the artificial rock mass is exposed. It has been established that the chamber mining systems do not ensure the operational stability of the vertical outcrop in the zones of exogenous intensive fracture of the rock mass, especially in the places where they intersect. The zonal location of intense fracture was established along the strike and dip of the steep ore deposit, as was its importance in the formation of rock fallouts. An analytical solution algorithm has been developed to determine the penetration of the backfilling mixture in the plane of the intersection of zones of intense cracking, with opposite azimuths of incidence at steep angles of macrocracking. The features of penetration into microcracks of the backfilling mixture used at the mine, which are affected by their granulometric and physicochemical compositions, have been determined. The influence of the height of the layer and the procedure of backfilling the chamber space in the liquid phase on the formation of the necessary pressure for the opening of a microcrack was studied. The priority of backfilling the exogenous macrocracks with significant gaps and those between tectonic blocks with mixtures has been analytically substantiated and confirmed by experimental methods of research in the mine. Full article

Large–scale underground coal mining is bound to cause serious surface subsidence problems. However, conventional filling and mining methods have problems such as high cost and process difficulty. In order to achieve the purpose of high efficiency and low cost, this paper proposes using the technology of CGSG. To achieve the effective control of overburden strata movement and ground surface settlement using cemented gangue strip filling in the goaf (CGSG), this paper studies the design principles and methods of the key parameters of the strip–filling structure including the strength, compressed deformation characteristics, and sizes. Based on the analysis of the structures and movement characteristics of the overburden strata above the coal seam, the mechanical relationship between the strip–filling structure and the overburden strata was established. Formulas for calculating the parameters of the strip–filling structure were derived. Guided by the obtained index parameters, the material ratios and mechanical experiments of the filling body were designed. The research results demonstrated that the strengths of the cemented gangue filling body at different ages should be greater than the compressive load of the strata roof movement on the filling body during the same period; under the compression of the maximum load, the ultimate compressive deformation of the filling body should be less than the ultimate subsidence deflection of the basic roof strata. The width of the strip–filling structure was inversely proportional to its ultimate strength, while the width of the non–filling area was greatly affected by the length of the rock beam formed after the basic roof strata fractured. The research results were applied in the No. 7402 experimental strip–filling workface in Zhaizhen coal mine, China. Reasonable parameters of the cemented gangue strip–filling structure were designed. The field application results demonstrated that, after using the technology of CGSG, there was no obvious pressure appearance when the working face was mined. The maximum sinking value of the ground surface was only 30 mm after the mining of the working face was completed; at the same time, the filling cost was about one–third less than the complete–filling technology in the goaf. Full article

Coal gangue, as a solid waste produced in the coal mining process, can be disposed by being prepared into backfill materials and then filled in underground goafs, thus controlling strata movement and surface subsidence. However, gangue backfill materials are non-continuous; therefore, research into the surface deformation induced by backfill mining should consider the creep compression behavior of gangue backfill materials. The research took a backfill panel in Tangshan Coal Mine (Tangshan City, Hebei Province, China) as the background. In addition, broken coal gangue was collected in the field to prepare specimens of gangue backfill materials, and their creep compression properties were measured. The corresponding constitutive equation of creep compression was then established and embedded in the numerical software, FLAC^3D. By building the numerical model for surface deformation induced by backfill mining, the surface deformation above the backfill panel under conditions of different creep durations of backfill materials was simulated and evaluated. In addition, two measuring lines were arranged on the surface to monitor changes in surface subsidence. After surface subsidence stabilized, the maximum surface subsidence was 163.4 mm, which satisfied the fortification criterion of surface buildings. This means the backfill mining did not affect nearby buildings. The results provide a theoretical basis for predicting surface deformation induced by backfill mining and its effective control. Full article

To address the problem of surface subsidence caused by the compression of filling gangue in deep mines, a layered compaction test was designed based on the zonation of the failure of the overburden in the goaf and layered property of the filling gangue. The deformation characteristics of filling gangue in natural and water-bearing states were obtained. The deformation of filling gangue during the 0~100 kN loading stage was an approximately positive S-type, which reflects the relative “advancement” in terms of deformation. The filling gangue deformation in the 100~500 kN loading stage was an approximately inverted S-type, which reflects the relative “lag” in terms of deformation. In a natural state, the load-time curves of the dead load stage were consistent. Under a water-bearing condition, the load-time curve for the dead load stage had apparent “step” characteristics and presented a special phenomenon of displacement rebound. Under gradient loading, the strain showed an exponential growth model, and energy dissipation showed a logarithmic growth model. Under a natural state, the energy dissipation showed consistently increasing distribution patterns, while the energy dissipation showed a normal distribution model under the water-bearing state. Full article

Because of the problem of gangue discharge and surface subsidence during coal mining, the current research on underground filling mainly focuses on the paste filling, solid filling, and grouting filling of the overburden separation layer after scaffolding. We proposed the technology of fluidization gangue grouting for filling the collapse area based on our previous research. The prediction method of residual space in the collapse area and the diffusion law of gangue fluidization filling slurry are two essential points for successfully implementing the technology and maximizing the use of goaf for gangue backfilling and reducing overburden settlement. To further explore the remaining space distribution law of the collapsed goaf in thick seam fully mechanized top coal caving mining and the effect of coal gangue fluidization filling, the caving goaf of the 3307 fully mechanized top coal caving face in Sangshuping No. 2 coal mine in the Weibei mining area was detected by the transient electromagnetic method. We studied the distribution law of the measured abnormal area in the caving goaf, which reflects the distribution law of the remaining space from one aspect. The coefficient of the remaining space was calculated to be 19.5%. Then, we applied COMSOL simulation software. The diffusion law of coal gangue fluidized slurry in the caving goaf was simulated and analyzed. It shows that the most obvious diffusion direction of the coal gangue slurry is the trend of the gradual expansion of the “cavity pore” multi-type residual space, indicating that with the increase in the diffusion distance, the diffusion resistance gradually increases, and the slurry morphology gradually presents the “claw” form. According to the space theory and fractal dimension theory, the prediction method of the remaining space in the caving goaf is given, and the design basis of the filling drilling parameters is determined. Finally, the field-filling test was carried out. The results show that the high- and low-level fluidized filling in the caving goaf can safely and efficiently handle the gangue in the mine, and the residual space characteristics and slurry diffusion law in the caving goaf are consistent with the above. The research results provide theoretical support for the fluidization filling technology of coal gangue in thick seam fully mechanized top coal caving areas. Full article

Subsidence deformation of abandoned goafs can induce cracking, distortion and even collapse of surface buildings (structures), and thus, subsidence deformation poses a great threat. Accurate detection of the abandoned goaf location and overburden morphology is an important prerequisite for stability evaluation and scientific management of surface buildings (structures), and effective detection methods are bottlenecks for accurate detection. Taking the abandoned goaf in the Tengzhou section of China’s Mu Shi expressway as an engineering example, step-by-step detection, traditional detection and combination methods are used to determine the location of the underlying abandoned goaf and overburden morphology. First, we conduct disaster investigation on the expressway and surface within the affected area of the abandoned goaf and initially determine the detection area. Then, according to the principle that the detection range can be examined step-by-step from large to small, the high-density resistivity method is used for detection, and the high-resolution seismic method is further selected to analyze the target area. Then, based on the results of the resistivity method, the position of the abandoned goaf is evaluated with the high-resolution seismic method, and the distributions of the overburden subsidence, the water-filled fractured zone and the caving zone (the three belts) are determined. Finally, boreholes are drilled deep into the bottom of the abandoned goaf at specific locations and the distributions of the abandoned goaf and three belts are verified and corrected with drilling data, acoustic detection and borehole TV imaging technology, thereby providing accurate data on abandoned goafs for highway stability evaluation. Full article

Large-scale goafs are left after coal seam mining. Due to the low-lying terrain, the goaf will be filled and soaked by groundwater, which may lead to instability of the remaining coal pillars in the goaf and cause uneven settlement of the overlying rock. Consequently, there may be overlying rock movement and surface subsidence, which endangers the safety of the building (structure) above the goaf. Considering the strip goaf of Dai Zhuang coal pillar as an example, this study investigated the evolution of instability and deformation of surrounding rocks affected by water immersion using the similar material simulation test method. The results of the study reveal that under the effect of prolonged water immersion in the goaf, the damage to the coal pillar in the strip underwent a stagewise evolution process of several instances of creep damage at the edge of coal pillar followed by overall destabilization damage, and the overburden movement revealed stage characteristics of small step subsidence several times followed by sudden large subsidence. Furthermore, based on Wilson’s coal pillar instability theory, the instability mechanism of the strip coal pillar under the action of water immersion was found to be triggered by the reduced strength of the coal pillar from the effect of water immersion, the continuous creep damage to the strip coal pillar from outside to inside, and the continuous shortening of the elastic zone of the coal pillar until its bearing capacity was lower than the load it was carrying. The research results are expected to serve as theoretical guidance for the study of coal pillar stability and the development and utilization of surface construction above goafs. Full article
