Innovation and Inventions in Aerospace and UAV Applications

Journal Name	Impact Factor	CiteScore	Launched Year	First Decision (median)	APC
Aerospace aerospace	2.1	3.4	2014	21.3 Days	CHF 2400	Submit
Drones drones	4.4	5.6	2017	19.2 Days	CHF 2600	Submit
Inventions inventions	2.1	4.8	2016	18.5 Days	CHF 1800	Submit
Materials materials	3.1	5.8	2008	13.9 Days	CHF 2600	Submit
Sensors sensors	3.4	7.3	2001	18.6 Days	CHF 2600	Submit
Polymers polymers	4.7	8.0	2009	14.5 Days	CHF 2700	Submit
Applied Sciences applsci	2.5	5.3	2011	18.4 Days	CHF 2400	Submit
Energies energies	3.0	6.2	2008	16.8 Days	CHF 2600	Submit

37 pages, 6840 KiB

Open AccessArticle

Parametric Analysis of Landing Capacity for UAV Fleet Operations with Specific Airspace Structures and Rule-Based Constraints

by Peng Han, Xinyue Yang, Kin Huat Low and Yifei Zhao

Drones 2024, 8(12), 770; https://doi.org/10.3390/drones8120770 - 19 Dec 2024

Viewed by 1313

Abstract

As Urban Air Mobility (UAM) moves toward implementation, managing high-density, high-volume flights in urban airspaces becomes increasingly critical. In such environments, the design of vertiport airspace structures plays a key role in determining how many UAVs can operate safely and efficiently within a [...] Read more.

As Urban Air Mobility (UAM) moves toward implementation, managing high-density, high-volume flights in urban airspaces becomes increasingly critical. In such environments, the design of vertiport airspace structures plays a key role in determining how many UAVs can operate safely and efficiently within a specific airspace. Existing studies have not fully explored the complex interdependencies between airspace structure parameters and fleet operation capacity, particularly regarding how various structural components and their configurations affect UAV fleet performance. This paper addresses these gaps by proposing a multi-layered funnel-shaped airspace structure for vertiports, along with an adjustable parameter model to assess factors affecting landing capacity. The proposed design includes the assembly layer, upper layer, lower layer, and approach point, forming the basis for fleet operations, divided into three phases: arrival, approach, and landing. By modeling fleet operations with various constraints and time-based algorithms, simulations have been conducted to analyze the impact of changing airspace structure parametric dimensions on UAV fleet operation capacity. The results reveal that fleet capacity is closely influenced by two limitations: the distance traveled in each phase and the availability of holding points at each layer. These findings provide valuable insights and contribute to future airspace design efforts for UAM vertiports. Full article

(This article belongs to the Topic Innovation and Inventions in Aerospace and UAV Applications)

► Show Figures

Figure 1

18 pages, 7535 KiB

Open AccessArticle

Pitch-Regulated Control Strategy for Coaxial Drone with Variable Rotor Space Ratio

by Zhifang Ke, Molei Zhao, Yu Hu, Yongjie Shu, Weibo Liu, Qingkai Meng, Jinghan Tu, Haitao Zhang, Zhaopu Yao and Wei Wei

Drones 2024, 8(12), 703; https://doi.org/10.3390/drones8120703 - 25 Nov 2024

Viewed by 1004

Abstract

This study investigates the impact of rotor spacing on the aerodynamic performance of a coaxialcopter and promotes an innovative regulated control strategy for the coaxial drone. The present research introduces a coaxialcopter with variable rotor spacing, and employing finite element numerical simulations, we [...] Read more.

This study investigates the impact of rotor spacing on the aerodynamic performance of a coaxialcopter and promotes an innovative regulated control strategy for the coaxial drone. The present research introduces a coaxialcopter with variable rotor spacing, and employing finite element numerical simulations, we assess the aerodynamic behavior of this novel configuration. Through comprehensive measurements and analysis of its aerodynamic performance across varying rotor spacings from 0.1 R to 1 R, we validate the effectiveness of a rotor-spacing control strategy for enhancing takeoff maneuvers. The numerical simulation and experiment results reveal that the performance characteristics of both the upper and lower rotors converge toward that of a single rotor as the space ratio increases, along with a reduction in their thrust fluctuations and aerodynamic performance periodicity. Considering stable power consumption patterns and endurance performance, we analyzed the interrelations binding the pitch distance of the rotors, rotational speed, and pitch angle, vis à vis the thrust coefficient and power coefficient. Through the parameter optimization method, we demonstrate that adjusting rotor spacing offers a practical means to enhance payload capacity without increasing the power input, thereby improving efficiency, which validates the practicality and efficacy of the parameter optimization approach. Furthermore, optimizing rotor spacing for specific operational scenarios enhances overall aerodynamic performance, suggesting a viable flight control strategy for takeoff and landing conditions for coaxial drones. Full article

(This article belongs to the Topic Innovation and Inventions in Aerospace and UAV Applications)

► Show Figures

Figure 1

24 pages, 5160 KiB

Open AccessArticle

Operating Characteristics of a Wave-Driven Plasma Thruster for Cutting-Edge Low Earth Orbit Constellations

by Anna-Maria Theodora Andreescu, Daniel Eugeniu Crunteanu, Maximilian Vlad Teodorescu, Simona Nicoleta Danescu, Adrian Stoicescu, Alexandru Cancescu and Alexandru Paraschiv

Inventions 2024, 9(5), 107; https://doi.org/10.3390/inventions9050107 - 29 Sep 2024

Viewed by 1218

Abstract

This paper outlines the development phases of a wave-driven Helicon Plasma Thruster for cutting-edge Low Earth Orbit (LEO) constellations. The two-stage ambipolar electric propulsion (EP) system combines the efficient ionization of an ultra-compact helicon reactor with plasma acceleration based on an ambipolar electric [...] Read more.

This paper outlines the development phases of a wave-driven Helicon Plasma Thruster for cutting-edge Low Earth Orbit (LEO) constellations. The two-stage ambipolar electric propulsion (EP) system combines the efficient ionization of an ultra-compact helicon reactor with plasma acceleration based on an ambipolar electric field provided by a magnetic nozzle. This paper reveals maturation challenges associated with an emerging EP system in the hundreds-watt class, followed by outlook strategies. A 3 cm diameter helicon reactor was operated using argon gas under a time-modulated RF power envelope ranging from 250 W to 500 W with a fixed magnetic field strength of 400 G. Magnetically enhanced inductively coupled plasma reactor characteristics based on half-wavelength right helical and Nagoya Type III antennas under capacitive (E-mode), inductive (W-mode), and wave coupling (W-mode) were systematically investigated based on Optical Emission Spectroscopy. The operation characteristics of a wave-heated reactor based on helicon configuration were investigated as a function of different operating parameters. This work demonstrates the ability of two-stage HPT using a compact helicon reactor and a cusped magnetic field to outperform today’s LEO spacecraft propulsion. Full article

(This article belongs to the Topic Innovation and Inventions in Aerospace and UAV Applications)

► Show Figures

Figure 1

32 pages, 3865 KiB

Open AccessReview

Addressing Constraint Coupling and Autonomous Decision-Making Challenges: An Analysis of Large-Scale UAV Trajectory-Planning Techniques

by Gang Huang, Min Hu, Xueying Yang, Peng Lin and Yijun Wang

Drones 2024, 8(10), 530; https://doi.org/10.3390/drones8100530 - 28 Sep 2024

Cited by 1 | Viewed by 2724

Abstract

With the increase in UAV scale and mission diversity, trajectory planning systems faces more and more complex constraints, which are often conflicting and strongly coupled, placing higher demands on the real-time and response capabilities of the system. At the same time, conflicts and [...] Read more.

With the increase in UAV scale and mission diversity, trajectory planning systems faces more and more complex constraints, which are often conflicting and strongly coupled, placing higher demands on the real-time and response capabilities of the system. At the same time, conflicts and strong coupling pose challenges the autonomous decision-making capability of the system, affecting the accuracy and efficiency of the planning system in complex environments. However, recent research advances addressing these issues have not been fully summarized. An in-depth exploration of constraint handling techniques and autonomous decision-making issues will be of great significance to the development of large-scale UAV systems. Therefore, this paper aims to provide a comprehensive overview of this topic. Firstly, the functions and application scenarios of large-scale UAV trajectory planning are introduced and classified in detail according to the planning method, realization function and the presence or absence of constraints. Then, the constraint handling techniques are described in detail, focusing on the priority ranking of constraints and the principles of their fusion and transformation methods. Then, the importance of autonomous decision-making in large-scale UAV trajectory planning is described in depth, and related dynamic adjustment algorithms are introduced. Finally, the future research directions and challenges of large-scale UAV trajectory planning are outlooked, providing directions and references for future research in the fields of UAV clustering and UAV cooperative flight. Full article

(This article belongs to the Topic Innovation and Inventions in Aerospace and UAV Applications)

► Show Figures

Figure 1

31 pages, 3212 KiB

Open AccessFeature PaperEditor’s ChoiceReview

A Comprehensive Review of Energy-Efficient Techniques for UAV-Assisted Industrial Wireless Networks

by Yijia Zhang, Ruotong Zhao, Deepak Mishra and Derrick Wing Kwan Ng

Energies 2024, 17(18), 4737; https://doi.org/10.3390/en17184737 - 23 Sep 2024

Cited by 2 | Viewed by 1888

Abstract

The rapid expansion of the Industrial Internet-of-Things (IIoT) has spurred significant research interest due to the growth of security-aware, vehicular, and time-sensitive applications. Unmanned aerial vehicles (UAVs) are widely deployed within wireless communication systems to establish rapid and reliable links between users and [...] Read more.

The rapid expansion of the Industrial Internet-of-Things (IIoT) has spurred significant research interest due to the growth of security-aware, vehicular, and time-sensitive applications. Unmanned aerial vehicles (UAVs) are widely deployed within wireless communication systems to establish rapid and reliable links between users and devices, attributed to their high flexibility and maneuverability. Leveraging UAVs provides a promising solution to enhance communication system performance and effectiveness while overcoming the unprecedented challenges of stringent spectrum limitations and demanding data traffic. However, due to the dramatic increase in the number of vehicles and devices in the industrial wireless networks and limitations on UAVs’ battery storage and computing resources, the adoption of energy-efficient techniques is essential to ensure sustainable system implementation and to prolong the lifetime of the network. This paper provides a comprehensive review of various disruptive methodologies for addressing energy-efficient issues in UAV-assisted industrial wireless networks. We begin by introducing the background of recent research areas from different aspects, including security-enhanced industrial networks, industrial vehicular networks, machine learning for industrial communications, and time-sensitive networks. Our review identifies key challenges from an energy efficiency perspective and evaluates relevant techniques, including resource allocation, UAV trajectory design and wireless power transfer (WPT), across various applications and scenarios. This paper thoroughly discusses the features, strengths, weaknesses, and potential of existing works. Finally, we highlight open research issues and gaps and present promising potential directions for future investigation. Full article

(This article belongs to the Topic Innovation and Inventions in Aerospace and UAV Applications)

► Show Figures

Figure 1

19 pages, 1460 KiB

Open AccessArticle

Azimuthal Solar Synchronization and Aerodynamic Neuro-Optimization: An Empirical Study on Slime-Mold-Inspired Neural Networks for Solar UAV Range Optimization

by Graheeth Hazare, Mohamed Thariq Hameed Sultan, Dariusz Mika, Farah Syazwani Shahar, Grzegorz Skorulski, Marek Nowakowski, Andriy Holovatyy, Ile Mircheski and Wojciech Giernacki

Appl. Sci. 2024, 14(18), 8265; https://doi.org/10.3390/app14188265 - 13 Sep 2024

Viewed by 1116

Abstract

This study introduces a novel methodology for enhancing the efficiency of solar-powered unmanned aerial vehicles (UAVs) through azimuthal solar synchronization and aerodynamic neuro-optimization, leveraging the principles of slime mold neural networks. The objective is to broaden the operational capabilities of solar UAVs, enabling [...] Read more.

This study introduces a novel methodology for enhancing the efficiency of solar-powered unmanned aerial vehicles (UAVs) through azimuthal solar synchronization and aerodynamic neuro-optimization, leveraging the principles of slime mold neural networks. The objective is to broaden the operational capabilities of solar UAVs, enabling them to perform over extended ranges and in varied weather conditions. Our approach integrates a computational model of slime mold networks with a simulation environment to optimize both the solar energy collection and the aerodynamic performance of UAVs. Specifically, we focus on improving the UAVs’ aerodynamic efficiency in flight, aligning it with energy optimization strategies to ensure sustained operation. The findings demonstrated significant improvements in the UAVs’ range and weather resilience, thereby enhancing their utility for a variety of missions, including environmental monitoring and search and rescue operations. These advancements underscore the potential of integrating biomimicry and neural-network-based optimization in expanding the functional scope of solar UAVs. Full article

(This article belongs to the Topic Innovation and Inventions in Aerospace and UAV Applications)

► Show Figures

Figure 1

16 pages, 4935 KiB

Open AccessArticle

Design and Implementation of a Generalized Safety Fault Diagnosis System for China Space Station Scientific Experimental Rack

by Yifeng Wang, Tianji Zou, Lin Guo, Chenchen Zhang and Lu Zhang

Sensors 2024, 24(16), 5102; https://doi.org/10.3390/s24165102 - 6 Aug 2024

Viewed by 906

Abstract

As astronauts stay in the China Space Station for a long time during the operation phase, how to ensure the long-term safety of the scientific experimental rack (SER) in the field of space application is a problem that needs to be solved urgently. [...] Read more.

As astronauts stay in the China Space Station for a long time during the operation phase, how to ensure the long-term safety of the scientific experimental rack (SER) in the field of space application is a problem that needs to be solved urgently. Each SER in the field of space station applications is a complex system that faces risks from different hazards. At present, there is no generalized monitoring and diagnosis system for the common risks faced by the SER. In this paper, a generalized safety fault diagnosis system is proposed to ensure the long-term safe and stable work of SERs in orbit, considering the actual risks faced by the SER. With the design of a generalized main control board, a measurement and control board, and an SSPC (solid-state power controller) board, the software and hardware cooperate to realize the acquisition of various physical quantities, data processing, power supply and distribution management, and other functions. Combined with relevant fault detection algorithms, the real-time detection and diagnosis of the relevant risks, abnormality warnings, and fault disposal operations are realized, which can effectively ensure the safety of the payloads in the field of space application, astronauts, and the space-station system. Full article

(This article belongs to the Topic Innovation and Inventions in Aerospace and UAV Applications)

► Show Figures

Figure 1

27 pages, 16494 KiB

Open AccessArticle

Dispersion Analysis of Plane Wave Propagation in Lattice-Based Mechanical Metamaterial for Vibration Suppression

by Natsuki Tsushima, Yuta Hayashi and Tomohiro Yokozeki

Aerospace 2024, 11(8), 637; https://doi.org/10.3390/aerospace11080637 - 4 Aug 2024

Cited by 1 | Viewed by 2082

Abstract

Phononic crystals based on lattice structures provide important wave dispersion characteristics as band structures, showing excellent compatibility with additive manufacturing. Although the lattice structures have shown the potential for vibration suppression, a design guideline to control the frequency range of the bandgap has [...] Read more.

Phononic crystals based on lattice structures provide important wave dispersion characteristics as band structures, showing excellent compatibility with additive manufacturing. Although the lattice structures have shown the potential for vibration suppression, a design guideline to control the frequency range of the bandgap has not been well established. This paper studies the dispersion characteristics of plane wave propagation in lattice-based mechanical metamaterials to realize effective vibration suppression for potential aerospace applications. Triangular and hexagonal periodic lattice structures are mainly studied in this paper. The influence of different geometric parameters on the bandgap characteristics is investigated. A finite element approach with Floquet–Bloch’s principles is implemented to effectively evaluate the dispersion characteristics of waves in lattice structures, which is validated numerically and experimentally with a 3D-printed lattice plate. Based on numerical studies with the developed analysis framework, the influences of the geometric parameters of lattice plate structures on dispersion characteristics can mainly be categorized into three patterns: change in specific branches related to in-plane or out-of-plane vibrations, upward/downward shift in frequency range, and drastic change in dispersion characteristics. The results obtained from the study provide insight into the design of band structures to realize vibration suppression at specific frequencies for engineering applications. Full article

(This article belongs to the Topic Innovation and Inventions in Aerospace and UAV Applications)

► Show Figures

Figure 1

19 pages, 6572 KiB

Open AccessArticle

Non-Line-of-Sight Positioning Method for Ultra-Wideband/Miniature Inertial Measurement Unit Integrated System Based on Extended Kalman Particle Filter

by Chengzhi Hou, Wanqing Liu, Hongliang Tang, Jiayi Cheng, Xu Zhu, Mailun Chen, Chunfeng Gao and Guo Wei

Drones 2024, 8(8), 372; https://doi.org/10.3390/drones8080372 - 3 Aug 2024

Cited by 4 | Viewed by 1339

Abstract

In the field of unmanned aerial vehicle (UAV) control, high-precision navigation algorithms are a research hotspot. To address the problem of poor localization caused by non-line-of-sight (NLOS) errors in ultra-wideband (UWB) systems, an UWB/MIMU integrated navigation method was developed, and a particle filter [...] Read more.

In the field of unmanned aerial vehicle (UAV) control, high-precision navigation algorithms are a research hotspot. To address the problem of poor localization caused by non-line-of-sight (NLOS) errors in ultra-wideband (UWB) systems, an UWB/MIMU integrated navigation method was developed, and a particle filter (PF) algorithm for data fusion was improved upon. The extended Kalman filter (EKF) was used to improve the method of constructing the importance density function (IDF) in the traditional PF, so that the particle sampling process fully considers the real-time measurement information, increases the sampling efficiency, weakens the particle degradation phenomenon, and reduces the UAV positioning error. We compared the positioning accuracy of the proposed extended Kalman particle filter (EKPF) algorithm with that of the EKF and unscented Kalman filter (UKF) algorithm used in traditional UWB/MIMU data fusion through simulation, and the results proved the effectiveness of the proposed algorithm through outdoor experiments. We found that, in NLOS environments, compared with pure UWB positioning, the accuracy of the EKPF algorithm in the X- and Y-directions was increased by 35% and 39%, respectively, and the positioning error in the Z-direction was considerably reduced, which proved the practicability of the proposed algorithm. Full article

(This article belongs to the Topic Innovation and Inventions in Aerospace and UAV Applications)

► Show Figures

Figure 1

23 pages, 3775 KiB

Open AccessArticle

Advanced Scale-Propeller Design Using a MATLAB Optimization Code

by Stephen D. Prior and Daniel Newman-Sanders

Appl. Sci. 2024, 14(14), 6296; https://doi.org/10.3390/app14146296 - 19 Jul 2024

Viewed by 1923

Abstract

This study investigated the efficiency of scale-propellers, typically used on small drones. A scale-propeller is accepted as having a diameter of 7 to 21 inches. Recent special operations has demonstrated the utility of relatively small, low-cost first-person view (FPV) drones, which are attritable. [...] Read more.

This study investigated the efficiency of scale-propellers, typically used on small drones. A scale-propeller is accepted as having a diameter of 7 to 21 inches. Recent special operations has demonstrated the utility of relatively small, low-cost first-person view (FPV) drones, which are attritable. This investigation outlines the development of a MATLAB optimisation code, based on minimum induced loss propeller theory, which calculates the optimal chord and twist distribution for a chosen propeller operating in known flight conditions. The MATLAB code includes a minimum Reynolds number functionality, which provides the option to alter the chord distribution to ensure the entire propeller is operating above a set threshold value of Reynolds (>100,000), as this has been found to be a transition point between low and high section lift-to-drag ratios. Additional functions allow plotting of torque and thrust distributions along the blade. The results have been validated on experimental data taken from an APC ‘Thin Electric’ 10” × 7” propeller, where it was found that both the chord and twist distributions were accurately modelled. The MATLAB code resulted in a 16% increase in the maximum propulsive efficiency. Further work will investigate a direct interface to SolidWorks to aid rapid propeller manufacturing capability. Full article

(This article belongs to the Topic Innovation and Inventions in Aerospace and UAV Applications)

► Show Figures

Figure 1

19 pages, 71545 KiB

Open AccessArticle

UAV Imagery-Based Classification Model for Atypical Traditional Village Landscapes and Their Spatial Distribution Pattern

by Shaojiang Zheng, Lili Wei, Houjie Yu and Weili Kou

Drones 2024, 8(7), 297; https://doi.org/10.3390/drones8070297 - 4 Jul 2024

Cited by 1 | Viewed by 1083

Abstract

For atypical traditional villages, their invaluable historical traces and cultural memories are preserved in the existing village landscapes. Rapid and accurate acquisition of the spatial information of various surface elements in a village is an important prerequisite for a scientific, reasonable, feasible planning [...] Read more.

For atypical traditional villages, their invaluable historical traces and cultural memories are preserved in the existing village landscapes. Rapid and accurate acquisition of the spatial information of various surface elements in a village is an important prerequisite for a scientific, reasonable, feasible planning and design scheme for conserving, progressing, and developing atypical villages. Taking Qianfeng Village as an example, this research proposes the atypical traditional village landscape classification model based on unmanned aerial vehicle (UAV) imagery (ATVLUI) by virtue of the UAV RGB images and the object-oriented fuzzy logic membership classification technique that extracts objects according to their spectrums, textures, geometries, and context relationships, aiming at precise extraction of atypical traditional village landscapes. Based on the landscape information, the landscape pattern indexes are calculated to explore the spatial distribution characteristics of different landscapes and analyze the current conditions of Qianfeng Village as the epitome of atypical traditional villages. Accordingly, suggestions for protecting, planning, and developing atypical villages are proposed. The results show that: (1) the ATVLUI boasts excellent identification for village landscapes in a complex scenario, with a classification accuracy for traditional structures of 84%, an overall accuracy of 93%, and a Kappa coefficient of 0.89. This model is proven superior to K-nearest neighbors (KNN), decision tree (DT), and random tree (RT); (2) according to the area and proportion calculations, the structures account for 33.94% of Qianfeng Village’s total area, in which 29.69% and 4.25% are modern and traditional structures, respectively. The number of traditional structures is 202, accounting for 13% of the total number of structures; (3) within the village, connectivity between and extension of the modern structures can be recognized, suggesting a trajectory where the traditional structures are being gradually substituted by modern ones. The ecological environment at the periphery of the village is favorable. The building-to-building common boundaries are long. The modern structures are densely distributed. The discretely distributed traditional structures gather as small clusters. In general, different structures are highly interlaced to form a fragmented distribution pattern. Full article

(This article belongs to the Topic Innovation and Inventions in Aerospace and UAV Applications)

► Show Figures

Figure 1

15 pages, 2399 KiB

Open AccessArticle

The Influence of Temporal Disturbances in EKF Calculations on the Achieved Parameters of Flight Control and Stabilization of UAVs

by Jędrzej Szczepaniak, Bogusław Szlachetko and Michał Lower

Sensors 2024, 24(12), 3826; https://doi.org/10.3390/s24123826 - 13 Jun 2024

Cited by 1 | Viewed by 3936

Abstract

This article investigates the causes of occasional flight instability observed in Unmanned Aerial Vehicles (UAVs). The issue manifests as unexpected oscillations that can lead to emergency landings. The analysis focuses on delays in the Extended Kalman Filter (EKF) algorithm used to estimate the [...] Read more.

This article investigates the causes of occasional flight instability observed in Unmanned Aerial Vehicles (UAVs). The issue manifests as unexpected oscillations that can lead to emergency landings. The analysis focuses on delays in the Extended Kalman Filter (EKF) algorithm used to estimate the drone’s attitude, position, and velocity. These delays disrupt the flight stabilization process. The research identifies two potential causes for the delays. First cause is magnetic field distrurbances created by UAV motors and external magnetic fields (e.g., power lines) that can interfere with magnetometer readings, leading to extended EKF calculations. Second cause is EKF fusion step implementation of the PX4-ECL library combining magnetometer data with other sensor measurements, which can become computionally expensive, especially when dealing with inconsistent magnetic field readings. This can significantly increase EKF processing time. The authors propose a solution of moving the magnetic field estimation calculations to a separate, lower-priority thread. This would prevent them from blocking the main EKF loop and causing delays. The implemented monitoring techniques allow for continuous observation of the real-time operating system’s behavior. Since addressing the identified issues, no significant problems have been encountered during flights. However, ongoing monitoring is crucial due to the infrequent and unpredictable nature of the disturbances. Full article

(This article belongs to the Topic Innovation and Inventions in Aerospace and UAV Applications)

► Show Figures

Figure 1

18 pages, 22173 KiB

Open AccessArticle

Structural Analysis and Testing of a Flexible Rudder Using a Cosine Honeycomb Structure

by Jinwei Huang, Weidong Liu, Yue Zhou and Dian Liu

Aerospace 2024, 11(6), 462; https://doi.org/10.3390/aerospace11060462 - 8 Jun 2024

Cited by 1 | Viewed by 1466

Abstract

This paper introduces a new type of flexible rudder surface based on the cosine-type zero Poisson’s ratio honeycomb to enhance the adaptive capabilities of aircraft and enable multi-condition, rudderless flight. The zero Poisson’s ratio honeycomb structure exhibits exceptional in-plane and out-of-plane deformation capacities, [...] Read more.

This paper introduces a new type of flexible rudder surface based on the cosine-type zero Poisson’s ratio honeycomb to enhance the adaptive capabilities of aircraft and enable multi-condition, rudderless flight. The zero Poisson’s ratio honeycomb structure exhibits exceptional in-plane and out-of-plane deformation capacities, as well as a high load-bearing capability. To investigate the deformation characteristics of flexible rudder surfaces utilizing cosine honeycomb structures, this study undertakes a comprehensive investigation through finite element simulation and 3D printing experiments. Moreover, this study analyzed the impact of honeycomb parameters and layout on the deflection performance and weight. The flexible rudder surface, fabricated from nylon, achieves smooth and consistent chordwise bending deformation, as well as uniform spanwise deformation within a tolerance of ±25°, and the maximum equivalent stress observed was 31.99 MPa, which is within the material’s allowable stress limits (50 MPa). Finite element simulation results indicate that once the deflection angle of the rocker exceeds 15°, a discernible deviation arises between the actual deflection angle of the flexible control surface and that of the rocker. Furthermore, this deviation escalates with increasing rocker rotation angles, and this discrepancy can be mitigated by augmenting the number of cosine honeycomb cells within the flexible rudder surface. Finally, a prototype of the flexible rudder surface was successfully produced using 3D printing technology, and the experimental results confirmed the deformation behavior, aligning with simulation outcomes with a deviation of less than 20%. These findings confirm the effective deflection performance of the designed flexible rudder surface, highlighting its potential application in small unmanned aerial vehicles. Full article

(This article belongs to the Topic Innovation and Inventions in Aerospace and UAV Applications)

► Show Figures

Figure 1

17 pages, 22150 KiB

Open AccessArticle

Real-Time Recognition Algorithm of Small Target for UAV Infrared Detection

by Qianqian Zhang, Li Zhou and Junshe An

Sensors 2024, 24(10), 3075; https://doi.org/10.3390/s24103075 - 12 May 2024

Cited by 8 | Viewed by 1965

Abstract

Unmanned Aerial Vehicle (UAV) infrared detection has problems such as weak and small targets, complex backgrounds, and poor real-time detection performance. It is difficult for general target detection algorithms to achieve the requirements of a high detection rate, low missed detection rate, and [...] Read more.

Unmanned Aerial Vehicle (UAV) infrared detection has problems such as weak and small targets, complex backgrounds, and poor real-time detection performance. It is difficult for general target detection algorithms to achieve the requirements of a high detection rate, low missed detection rate, and high real-time performance. In order to solve these problems, this paper proposes an improved small target detection method based on Picodet. First, to address the problem of poor real-time performance, an improved lightweight LCNet network was introduced as the backbone network for feature extraction. Secondly, in order to solve the problems of high false detection rate and missed detection rate due to weak targets, the Squeeze-and-Excitation module was added and the feature pyramid structure was improved. Experimental results obtained on the HIT-UAV public dataset show that the improved detection model’s real-time frame rate increased by 31 fps and the average accuracy (MAP) increased by 7%, which proves the effectiveness of this method for UAV infrared small target detection. Full article

(This article belongs to the Topic Innovation and Inventions in Aerospace and UAV Applications)

► Show Figures

Graphical abstract

30 pages, 7313 KiB

Open AccessArticle

Rapid Approximation of Low-Thrust Spacecraft Reachable Sets within Complex Two-Body and Cislunar Dynamics

by Sean Bowerfind and Ehsan Taheri

Aerospace 2024, 11(5), 380; https://doi.org/10.3390/aerospace11050380 - 9 May 2024

Cited by 3 | Viewed by 2237

Abstract

The reachable set of controlled dynamical systems is the set of all reachable states from an initial condition over a certain time horizon, subject to operational constraints and exogenous disturbances. In astrodynamics, rapid approximation of reachable sets is invaluable for trajectory planning, collision [...] Read more.

The reachable set of controlled dynamical systems is the set of all reachable states from an initial condition over a certain time horizon, subject to operational constraints and exogenous disturbances. In astrodynamics, rapid approximation of reachable sets is invaluable for trajectory planning, collision avoidance, and ensuring safe and optimal performance in complex dynamics. Leveraging the connection between minimum-time trajectories and the boundary of reachable sets, we propose a sampling-based method for rapid and efficient approximation of reachable sets for finite- and low-thrust spacecraft. The proposed method combines a minimum-time multi-stage indirect formulation with the celebrated primer vector theory. Reachable sets are generated under two-body and circular restricted three-body (CR3B) dynamics. For the two-body dynamics, reachable sets are generated for (1) the heliocentric phase of a benchmark Earth-to-Mars problem, (2) two scenarios with uncertainties in the initial position and velocity of the spacecraft at the time of departure from Earth, and (3) a scenario with a bounded single impulse at the time of departure from Earth. For the CR3B dynamics, several cislunar applications are considered, including L1 Halo orbit, L2 Halo orbit, and Lunar Gateway 9:2 NRHO. The results indicate that low-thrust spacecraft reachable sets coincide with invariant manifolds existing in multi-body dynamical environments. The proposed method serves as a valuable tool for qualitatively analyzing the evolution of reachable sets under complex dynamics, which would otherwise be either incoherent with existing grid-based reachability approaches or computationally intractable with a complete Hamilton–Jacobi–Bellman method. Full article

(This article belongs to the Topic Innovation and Inventions in Aerospace and UAV Applications)

► Show Figures

Figure 1

21 pages, 7280 KiB

Open AccessArticle

Determining the Location of the UAV When Flying in a Group

by Milan Džunda, Peter Dzurovčin, Sebastián Čikovský and Lucia Melníková

Aerospace 2024, 11(4), 312; https://doi.org/10.3390/aerospace11040312 - 17 Apr 2024

Cited by 1 | Viewed by 1352

Abstract

This paper created a flight trajectory model of five uncrewed aerial vehicles (UAVs) in the geocentric coordinate system, provided the UAVs fly in the specified formation. Based on this model, equations for determining the position of a selected member of a group of [...] Read more.

This paper created a flight trajectory model of five uncrewed aerial vehicles (UAVs) in the geocentric coordinate system, provided the UAVs fly in the specified formation. Based on this model, equations for determining the position of a selected member of a group of UAVs were created, provided that the group communicates with each other in its telecommunications network. The simulation confirmed that if we know the exact coordinates of the four member UAVs of the group and their distances from the leader of the group, then the mean value of the error in determining its position in flight is equal to 0.044 m, and the variance is equal to 2.9 m². We consider these errors to be methodological errors of the proposed method. Next, we checked how the error of determining the position of the group leader depends on the distance measurement errors between the individual UAVs and the group leader. The simulation confirmed that if errors in measuring the distance between individual UAVs and the group leader are from 0.01 m to 12.0 m, the mean values of group commander position determination errors range from 0.11 m to 34.6 m. The simulation result showed that to accurately determine the group commander’s position, the distance measurement errors between individual UAVs and the group commander must be less than 1.9 m. The research results showed that the telemetry method can be used to determine the position of individual members of the UAV group. The advantage of this method is that it does not require the reception of signals from satellite navigation systems, which can be interfered with under certain conditions. The disadvantage of the method is the need to synchronize the time bases of individual UAVs that communicate in the telecommunications network. Full article

(This article belongs to the Topic Innovation and Inventions in Aerospace and UAV Applications)

► Show Figures

Figure 1

20 pages, 14188 KiB

Open AccessArticle

Enhancing Coastal Risk Recognition: Assessing UAVs for Monitoring Accuracy and Implementation in a Digital Twin Framework

by Rui Yuan, Hezhenjia Zhang, Ruiyang Xu and Liyuan Zhang

Appl. Sci. 2024, 14(7), 2879; https://doi.org/10.3390/app14072879 - 29 Mar 2024

Cited by 1 | Viewed by 1760

Abstract

This paper addresses the intricate challenges of coastal management, particularly in rapidly forming tidal flats, emphasizing the need for innovative monitoring strategies. The dynamic coastal topography, exemplified by a newly formed tidal flat in Shanghai, underscores the urgency of advancements in coastal risk [...] Read more.

This paper addresses the intricate challenges of coastal management, particularly in rapidly forming tidal flats, emphasizing the need for innovative monitoring strategies. The dynamic coastal topography, exemplified by a newly formed tidal flat in Shanghai, underscores the urgency of advancements in coastal risk recognition. By utilizing a digital twin framework integrated with state-of-the-art unmanned aerial vehicles (UAVs), we systematically evaluate three configurations and identify the optimal setup incorporating real-time kinematics (RTK) and light detection and ranging (LiDAR). This UAV configuration excels in efficiently mapping the 3D coastal terrain. It has an error of less than 0.1 m when mapping mudflats at an altitude of 100 m. The integration of UAV data with a precise numerical ocean model forms the foundation of our dynamic risk assessment framework. The results showcase the transformative potential of the digital twin framework, providing unparalleled accuracy and efficiency in coastal risk recognition. Visualization through Unity Engine or Unreal Engine enhances accessibility, fostering community engagement and awareness. By predicting and simulating potential risks in real-time, this study offers a forward-thinking strategy for mitigating coastal dangers. This research not only contributes a comprehensive strategy for coastal risk management but also sets a precedent for the integration of cutting-edge technologies in safeguarding coastal ecosystems. The findings are significant in paving the way for a more resilient and sustainable approach to coastal management, addressing the evolving environmental pressures on our coastlines. Full article

(This article belongs to the Topic Innovation and Inventions in Aerospace and UAV Applications)

► Show Figures

Figure 1

34 pages, 2373 KiB

Open AccessArticle

Modeling of the Flight Performance of a Plasma-Propelled Drone: Limitations and Prospects

by Sylvain Grosse, Eric Moreau and Nicolas Binder

Drones 2024, 8(3), 114; https://doi.org/10.3390/drones8030114 - 21 Mar 2024

Cited by 3 | Viewed by 3742

Abstract

The resurgence in interest in aircraft electro-aerodynamic (EAD) propulsion has been sparked due to recent advancements in EAD thrusters, which generate thrust by employing a plasma generated through electrical discharge. With potentially quieter propulsion that could contribute to the generation of lift or [...] Read more.

The resurgence in interest in aircraft electro-aerodynamic (EAD) propulsion has been sparked due to recent advancements in EAD thrusters, which generate thrust by employing a plasma generated through electrical discharge. With potentially quieter propulsion that could contribute to the generation of lift or the control of attitude, it is important to determine the feasibility of an EAD-propelled airplane. First, the main propulsive characteristics (thrust generation and power consumption) of EAD thrusters were drawn from the literature and compared with existing technologies. Second, an algorithm was developed to couple standard equations of flight with EAD propulsion performance and treat the first-order interactions. It fairly replicated the performance of the only available autonomous EAD-propelled drone. A test case based on an existing commercial UAV of 10 kg equipped with current-generation EAD thrusters anticipated a flight of less than 10 min, lower than 30 m in height, and below 8 m · s ⁻¹ in velocity. Achieving over 2 h of flight at 30 m of height at 10 m · s ⁻¹ requires the current EAD thrust to be doubled without altering the power consumption. For the same flight performance as the baseline UAV, the prediction asked for a tenfold increase in the thrust at the same power consumption. Full article

(This article belongs to the Topic Innovation and Inventions in Aerospace and UAV Applications)

► Show Figures

Figure 1

13 pages, 12174 KiB

Open AccessArticle

Virtual Validation of In-Flight GNSS Signal Reception during Jamming for Aeronautics Applications

by Veenu Tripathi and Stefano Caizzone

Aerospace 2024, 11(3), 204; https://doi.org/10.3390/aerospace11030204 - 5 Mar 2024

Cited by 2 | Viewed by 2474

Abstract

Accurate navigation is a crucial asset for safe aviation operation. The GNSS (Global Navigation Satellite System) is set to play an always more important role in aviation but needs to cope with the risk of interference, possibly causing signal disruption and loss of [...] Read more.

Accurate navigation is a crucial asset for safe aviation operation. The GNSS (Global Navigation Satellite System) is set to play an always more important role in aviation but needs to cope with the risk of interference, possibly causing signal disruption and loss of navigation capability. It is crucial, therefore, to evaluate the impact of interference events on the GNSS system on board an aircraft, in order to plan countermeasures. This is currently obtained through expensive and time-consuming flight measurement campaigns. This paper shows on the other hand, a method developed to create a virtual digital twin, capable of reconstructing the entire flight scenario (including flight dynamics, actual antenna, and impact of installation on aircraft) and predicting the signal and interference reception at airborne level, with clear benefits in terms of reproducibility and easiness. Through simulations that incorporate jamming scenarios or any other interference scenarios, the effectiveness of the aircraft’s satellite navigation capability in the real environment can be evaluated, providing valuable insights for informed decision-making and system enhancement. By extension, the method shown can provide the ability to predict real-life outcomes even without the need for actual flight, enabling the analysis of different antenna-aircraft configurations in a specific interference scenario. Full article

(This article belongs to the Topic Innovation and Inventions in Aerospace and UAV Applications)

► Show Figures

Figure 1

14 pages, 2443 KiB

Open AccessArticle

A Fruit Harvesting Mechanism Capable of Multidimensional Movements: A Preliminary Study on the Integrated Mechanism with a Hexacopter

by Hanmin Park, Hyeongseok Kang, Bohyun Hwang, Seonggun Joe and Byungkyu Kim

Aerospace 2024, 11(3), 203; https://doi.org/10.3390/aerospace11030203 - 4 Mar 2024

Viewed by 2374

Abstract

This study introduces a fruit harvesting mechanism powered by a single motor, designed for integration with unmanned aerial vehicles (UAVs). The mechanism performs reciprocating motion by converting linear motion into rotational motion. Consequently, the end-effector can execute multi-dimensional kinematic trajectories, including biaxial and [...] Read more.

This study introduces a fruit harvesting mechanism powered by a single motor, designed for integration with unmanned aerial vehicles (UAVs). The mechanism performs reciprocating motion by converting linear motion into rotational motion. Consequently, the end-effector can execute multi-dimensional kinematic trajectories, including biaxial and rotational movements, synchronized with the motor’s position. These axial and rotational motions facilitate the gripper’s ability to reach, retrieve, and detach fruit from branches during the harvesting process. Notably, a critical consideration in designing this fruit harvesting mechanism is to generate the necessary torque at the end-effector while minimizing reaction forces and torque that could destabilize the UAV during flight. With these considerations in mind, this preliminary study aimed to harvest a Fuji apple and conduct a dynamic analysis. We constructed a prototype of the single motor-driven fruit harvesting mechanism using a suitable servo motor. To assess its mechanical performance and evaluate its impact on the hexacopter, we developed both a specific test platform featuring a six-spherical-prismatic-spherical parallel structure and a virtual environmental flight simulator. Overall, the results demonstrate the successful harvesting of a Fuji apple weighing approximately 300 g by the single motor-driven fruit harvesting mechanism, with no adverse effects observed on the hexacopter’s operation. Full article

(This article belongs to the Topic Innovation and Inventions in Aerospace and UAV Applications)

► Show Figures

Figure 1

23 pages, 15722 KiB

Open AccessArticle

Experimental Research into an Innovative Green Propellant Based on Paraffin–Stearic Acid and Coal for Hybrid Rocket Engines

by Grigore Cican, Alexandru Paraschiv, Adrian Nicolae Buturache, Andrei Iaroslav Hapenciuc, Alexandru Mitrache and Tiberius-Florian Frigioescu

Inventions 2024, 9(2), 26; https://doi.org/10.3390/inventions9020026 - 29 Feb 2024

Viewed by 2504

Abstract

This study focuses on an innovative green propellant based on paraffin, stearic acid, and coal, used in hybrid rocket engines. Additionally, lab-scale firing tests were conducted using a hybrid rocket motor with gaseous oxygen as the oxidizer, utilizing paraffin-based fuels containing stearic acid [...] Read more.

This study focuses on an innovative green propellant based on paraffin, stearic acid, and coal, used in hybrid rocket engines. Additionally, lab-scale firing tests were conducted using a hybrid rocket motor with gaseous oxygen as the oxidizer, utilizing paraffin-based fuels containing stearic acid and coal. The mechanical performance results revealed that the addition of stearic acid and coal improved the mechanical properties of paraffin-based fuel, including tensile, compression, and flexural strength, under both ambient and sub-zero temperatures (−21 °C). Macrostructural and microstructural examinations, conducted through optical and scanning electron microscopy (SEM), highlighted its resilience, despite minimal imperfections such as impurities and micro-voids. These characteristics could be attributed to factors such as raw material composition and the manufacturing process. Following the mechanical tests, the second stage involved conducting a firing test on a hybrid rocket motor using the new propellant and gaseous oxygen. A numerical simulation was carried out using ProPEP software to identify the optimal oxidant-to-fuel ratio for the maximum specific impulse. Following simulations, it was observed that the specific impulse for the paraffin and for the new propellant differs very little at each oxidant-to-fuel (O/F) ratio. It is noticeable that the maximum specific impulse is achieved for both propellants around the O/F value of 2.2. It was observed that no hazardous substances were present, unlike in traditional solid propellants based on ammonium perchlorate or aluminum. Consequently, there are no traces of chlorine, ammonia, or aluminum-based compounds after combustion. The resulting components for the simulated motor include H₂, H₂O, O₂, CO₂, CO, and other combinations in insignificant percentages. It is worth noting that the CO concentration decreases with an increase in the O/F ratio for both propellants, and the differences between concentrations are negligible. Additionally, the CO₂ concentration peaks at an O/F ratio of around 4.7. The test proceeded under normal conditions, without compromising the integrity of the test stand and the motor. These findings position the developed propellant as a promising candidate for applications in low-temperature hybrid rocket technology and pave the way for future advancements. Full article

(This article belongs to the Topic Innovation and Inventions in Aerospace and UAV Applications)

► Show Figures

Figure 1

Topic Menu

Topic Editors

Innovation and Inventions in Aerospace and UAV Applications

Topic Information

Keywords

Participating Journals

Published Papers (21 papers)

Further Information

Guidelines

MDPI Initiatives

Follow MDPI
