Railways are among the most efficient and widely used mass transportation systems for mid-range distances. To enhance the attractiveness of this type of transport, it is necessary to improve the level of comfort, which is much influenced by the vibration derived from the train motion and wheel-track interaction; thus, railway track infrastructure conditions and maintenance are a major concern. Based on discomfort levels, a methodology capable of detecting railway track infrastructure failures is proposed. During regular passenger service, acceleration and GPS measurements were taken on Alfa Pendular and Intercity trains between Porto (Campanhã) and Lisbon (Oriente) stations. ISO 2631 methodology was used to calculate instantaneous floor discomfort levels. By matching the results for both trains, using GPS coordinates, 12 track section locations were found to require preventive maintenance actions. The methodology was validated by comparing these results with those obtained by the EM 120 track inspection vehicle, for which similar locations were found. The developed system is a complementary condition-based maintenance tool that presents the advantage of being low-cost while not disturbing regular train operations. Full article

Switches and crossings (S&Cs) are also known as turnouts or railway points. They are important assets in railway infrastructures and a defect in such a critical asset might lead to a long delay for the railway network and decrease the quality of service. A squat is a common rail head defect for S&Cs and needs to be detected and monitored as early as possible to avoid costly emergent maintenance activities and enhance both the reliability and availability of the railway system. Squats on the switchblade could even potentially cause the blade to break and cause a derailment. This study presented a method to collect and process vibration data at the point machine with accelerometers on three axes to extract useful features. The two most important features, the number of peaks and the total power, were found. Three different unsupervised machine learning algorithms were applied to cluster the data. The results showed that the presented method could provide promising features. The k-means and the agglomerative hierarchical clustering methods are suitable for this data set. The density-based spatial clustering of applications with noise (DBSCAN) encounters some challenges. Full article

The objective of this paper was to analyze the effect of yellow-safety-line designs on the behavior of passengers at the platform edge in metro stations. To achieve this, an experimental approach, based on observation, was used in existing metro stations in Santiago and Valparaiso, Chile. The experiments were carried out for different widths of the yellow safety line: 5 cm, 10 cm, 24 cm, and 40 cm. In addition, the material was also changed to include yellow adhesive tape, PVC material with yellow pods, and carbon- and fiberglass-reinforced material with yellow pods. The experiments considered a mock-up to represent the hall entrance of the train and its adjacent platform, in which 25 participants were recruited, some of whom had reduced mobility. The results obtained from the experiments showed that the greater the width of the yellow safety line at the edge of the platform, the greater the level of compliance that was achieved. In addition, surveys were carried out with the passengers who participated in the experiment; the majority felt more comfortable and safer for a width of 24 cm. Some participants highlighted the phenomenon of “safety offers comfort”. In conclusion, the results of this research will allow the generation of new design and safety standards for the train–platform interface, which can then be tested in existing stations. Future research is expected to study the space occupied by different types of passengers and to study accessibility in other circulation spaces of metro stations. Full article

The guardrail is an indispensable part of ballasted track structures on bridges. In order to reveal its influence on the track–bridge interaction of continuous welded rail (CWR), the longitudinal resistance model of the guardrail fastener and its influential factors are established through tests. By taking a continuous girder bridge (CGB) for railways as an example, a stock rail-guardrail-sleeper-bridge-pier integrated simulation model is developed. The effects of the guardrails, installation torque of the guardrail fastener, and joint resistance of the guardrail under typical conditions are carefully examined. The research results indicate that the nominal longitudinal resistance of the guardrail fastener and the elastic longitudinal displacement of the rail prior to sliding approximately grow linearly with the growth of the installation torque. The presence of a guardrail can alleviate the track–bridge interaction in the range of the CGB, but exacerbate the interaction near the abutment with moveable bearings. This fact enables the abutment position to be considered as a new control point for the design of CWR on bridges. Considering the changing rules of the rail longitudinal force and rail gap, it is recommended that the installation torques of the guardrail fastener and guardrail joint are 40–60 N·m and 700–800 N·m, respectively. The recommended maximum longitudinal stiffness of piers for CGBs is evaluated. When the longitudinal stiffness of the pier for a CGB is lower than the recommended value, the influence of the guardrail can be neglected in the design of the CWR. Full article

Pile-raft foundation reinforcement will have a certain impact on the adjacent existing line foundation, which will affect the normal service of the subgrade, and even lead to the instability of the subgrade. Until now, there have been few studies on adjacent construction problems, and there are few field experimental data available for us to consult. Therefore, this study relies on the construction project of Shanghai–Nanjing intercity high-speed railway close to the existing line, using in situ monitoring methods, such as stress shovels, horizontal strain gauges, and inclinometers combined with finite-element calculation and rail-inspection vehicle-data analysis. The stress, displacement, and geometric linearity of the adjacent existing line foundation during the reinforcement construction of a pile-raft foundation were studied. Our aim was to measure the impact and optimize the existing roadbed-protection measures employed during the construction period. We found that the cumulative horizontal displacement of the existing line foundation slope toe during the construction period was 24.25 mm, and the lateral displacement rate was less than 0.59 mm/d. The distance between the two lines was 9 m. The horizontal stress of the foundation soil in the depth range varied according to extrusion and retraction with the different construction stages, and the extrusion stress was less than 10 kPa. The horizontal stress changes in different construction stages were not obvious; the track quality index (TQI) in the existing track inspection during the construction period increased by 129.58%, and the existing track geometric linearity fluctuated greatly. According to the test results, the excavation stage of the subgrade foundation pit was the most dangerous stage of the existing subgrade during the construction of the new line pile-raft foundation. Although the change of the horizontal stress in different construction stages was not obvious, the horizontal displacement of the slope toe was sensitive to the construction process. Therefore, it could be used as a key indicator to monitor the deformation and stability of the existing subgrade. The correction coefficient was obtained by combining the detection data of the track-inspection vehicle with the finite element calculation data, based on which the accurate estimation of the horizontal displacement of the slope toe after the excavation of the foundation pit was realized. The monitoring and evaluation method of the stability of the existing line foundation under the influence of the pile-raft foundation reinforcement construction was preliminarily established through field monitoring and the analysis of the track-inspection data. Based on this method, relevant early warning values were proposed. The test results and engineering measures ensured the safe operation of the existing line foundation. This has important theoretical significance for guiding the construction of a new subgrade of adjacent existing lines. Full article

High-value sensitive cargoes are often damaged by low-frequency vibration and shock of containers during land and rail transport processes or mixed transport processes. Therefore, a dedicated cylindrical elastomer spring that absorbs vibration transmitted into the container has been developed. This study developed an optimal shape using a polyurethane material instead of the existing rubber spring. Elastomer spring requires an optimal design that satisfies the design target stiffness and strength by nonlinear finite element analysis. In order to develop an elastomer spring for a cargo container, the material constant was obtained by a hyperelastic behavior test of natural rubber, and based on this, the necessary optimal material constant of the new spring was predicted. In addition, nonlinear structural analysis was performed using ABAQUS to obtain the optimal shape of the spring, and optimal design was performed with I-SIGHT software. As a result of the sum of squared difference minimization with the comparison algorithm, it was found that the polyurethane material constant C₁₀, C₂₀, and C₃₀ with the same characteristics as natural rubber was obtained. In addition, analysis using three optimization algorithms, Hooke–Jeeves algorithm, multi-island genetic algorithm, and optimal Latin hypercube, yielded a maximum principal strain of 0.244 of the spring obtained through the optimal cross-sectional shape design. It was found that this value was about 39% lower than the natural rubber spring in use. As a result of the compression load-displacement test of the actually developed product, it was confirmed that the correlation coefficient between the predicted value and the measured value was 0.928. Full article

Railways are one of the most efficient and widely used mass transportation systems for mid-range distances, also being pointed out as the best strategy to reach European Union decarbonisation goals. However, to increase railways attractiveness, it is necessary to improve the quality of the ride, namely its comfort, by decreasing the vibration at the passenger level. This article describes the experimental vibration modal identification of train seats based on a dedicated set of dynamic tests performed on Alfa Pendular and Intercity trains. This work uses two output-only modal identification techniques: the transmissibility functions and the Enhanced Frequency Domain Decomposition (EFDD) method. The last method allows us to clearly distinguish the seat structural movements, particularly the ones related to torsion and bending of the seat frame, from the local vertical foam vibrations. The natural frequencies and mode shapes are validated by matching the results derived from the transmissibility functions and EFDD method. The identified modal parameters are particularly relevant to characterise the vibration transmissibility provided by the foams (local transmissibility) and the vibration transmissibility derived from the metallic seat frame (global transmissibility). Full article

The development of an efficient freight railway system requires minimizing the travel time and maximizing the load capacity of trains. This objective can be achieved through three different strategies which can be adopted separately or in synergy. These strategies substantially consist of improvement of the load capacity of a single vehicle, increase in the train length, and increment of the vehicle velocity. The option to adopt simultaneously all three strategies is possible only when operating on dedicated infrastructures and specifically designing the vehicles and the track. This work shows the effect of the increment of the axle load, over the actual Italian limitation, on the most important indicators defined by the UIC regulation to homologate the vehicles. The calculations have been performed on a high-quality real track using a numerical model of a vehicle based on the Y25 bogie. In order to take into account higher axle loads, the vehicle primary suspension has been redesigned. The results show that an increment of the axle load is feasible until an axle load of 32.5 ton if speed is limited to 80 km/h, or until 30 ton if speed is limited to 120 km/h. Full article

The state-of-the-art design methods for railway prestressed concrete sleepers are currently based on the quasi-static stresses resulting from a simplification of dynamic wheel loads, and subsequently the quasi-static responses of concrete sleepers. This method has been widely used in practices to overcome the complexity of dynamic analysis and testing. A single load factor (or called dynamic impact factor) for a partial safety-factored design (or k factors for the test criteria) is commonly used to crudely account for dynamic train–track interactions over different levels of track irregularities. The dynamic impact factors for either design or testing are usually obtained from either (i) railway infrastructure managers (i.e., in EN 13230), or (ii) prescribed standardised factors (i.e., AS 1085.14, AREMA Chapter 30, JSA—JIS E 1201). The existing design concepts for prestressed concrete sleepers using either (i) an allowable stress design or (ii) the limit state design method require many iterations for calculations and optimisations. The design process to achieve optimal products suitable for track, operational, and environmental parameters is, thus, very time-consuming. On this ground, this study investigates the potential capability of machine learning (ML) to learn from large amounts of design data sets and then to facilitate the design and capacity prediction of railway prestressed concrete sleepers. Three ML algorithms are developed, namely deep learning, Bayesian Neural Network, and random forest. Through a combination of hand-calculated design data, industry design data, and experimental investigations in compliance with EN 13230, over 3000 sets of design data have been collected. These data sets are used to assimilate a comprehensive database for machine learning. Four indicators, namely mean squared error (MSE), root-mean-square error (RMSE), mean absolute error (MAE), and R² are used to benchmark the accuracy and precision of machine learning models. Our results reveal that the random forest algorithm offers the best performance. The values of MSE, RMSE, MAE, and R² are 0.54, 0.74, 0.25, and 0.99, respectively. Note that the Bayesian neural network also performs very well. In contrast, the deep learning algorithm performs worse than the others. The insight demonstrates machine learning’s capability to aid in the design of railway prestressed concrete sleepers, to satisfy both serviceability and ultimate limit states Full article

Rolling stock manufacturers face the challenge of manufacturing lightweight high-speed trains without deteriorating comfort. One of the difficulties is to mantain or increase structural stiffness and damping as the car bodies become lighter. Leaving aside active solutions, which are expensive and generally complex to implement, increasing structural damping by means of viscoelastic patches (via Constrained Layer Damping) seems to be a viable solution which is in fact already used for acoustic insulation in automotive, aerospace and even railway applications. Although there are works in the literature that try to optimise viscoelastic panels, this work presents an experimental study with two essential contributions: (i) to analyse the influence of a broad set of design parameters such as type of the constraining layer (uniform or honeycomb), thickness of the viscoelastic layer, location, covered area and continuity between patches; and (ii) to consider absolute and specific (per unit mass) damping depending on the design scenario. To locally increase the structural damping of an existing lightweight structure without compromising its weight, partial application of thin viscoelastic and constraining layers turned out to be the best solution. To enhance structural damping from the design stages, disregarding constraining layer mass by incorporating its stiffness into the overall stiffness of the structure, full coverage with thick viscoelastic layer and a honeycomb constraining layer with a high cross-section moment of inertia turned out to be the best option, reaching modal damping ratios up to 22 times higher than structures without viscoelastic materials. Full article

Purpose: Steel-spring-floating slab tracks are widely used in subway lines. It is necessary to analyze and study the vibration damping and transmission characteristics of the steel-spring-floating slab track in various frequency bands under the action of train loads. Method: A steel-spring-floating slab track and ordinary monolithic track tunnel sites with similar line conditions on straight and curved segments were selected. The vibration signals of rail, track bed, and tunnel walls were collected and the analysis results of vibration damping and vibration transmission between the steel-spring-floating slab track and the ordinary monolithic track were compared. Results: The dynamic responses of the rail in the four working conditions are relatively close, and the acceleration of the steel-spring-floating slab track bed is significantly larger than that of the ordinary monolithic track. The vibration response generated in the curved segment is significantly greater, and each frequency band will generate more peak points, and the high-frequency vibration will be more severe. Conclusions: The steel-spring-floating slab track can significantly reduce the acceleration response of the tunnel wall; the bottom constraint of the steel-spring-floating slab track is less, and the vibration response of the track bed is more severe. Full article

The paper is created within a project which aims to design a system of active wheelset steering for an electric four-axle locomotive. The wheelset steering system enables reduction in forces acting in the wheel-rail contacts in a curved track and consequently a reduction in wear and maintenance costs of both vehicles and rails is achieved. The project consists of three main parts: computer simulations, scaled roller rig experiments, and field tests. The paper is focused on the fundamental aspects of the first and the second part on the project. Track curvature estimation based on the rotation of the bogies towards the car body is proposed and assessed by computer simulations across varying track radiuses, vehicle speeds, and friction conditions. The scaled roller rig has been innovated in order to simulate bogie run in a curved track with uncompensated value of lateral acceleration and instrumented with a system of measurement of lateral wheel-rail forces. The experimental bogie has been equipped with systems of active wheelset steering and measurement of axle-box forces. The experiment setup, newly developed and applied systems of forces measurement and wireless signal transmission, and results of the first experiments are described in detail. Performed computer simulations and scaled roller rig experiments show that active wheelset steering is effective and practically implementable method of reducing guiding forces acting between railway vehicle wheels and rails in a curved track. Full article

In the course of digitalization, the concept of the digital twin (DT) has become increasingly important in recent years. Hereby, initial concept approaches focus on use cases in industrial production. Although the concept has diverse potential for the asset intensive and increasingly important German rail transport sector. Due to the still low level of research of the DT, there are few empirical values on how this promising concept can be implemented in a target-oriented manner. In a qualitative-explorative research design, this work focuses on answering the question of how a generic implementation strategy (GIS) of DTs in logistics systems of German rail transport can be designed. The central result of this work is a validated GIS which has a sufficient level of detail for the targeted implementation of DTs. Due to its socio-technical system focus, this process model enables user-oriented development and consideration of the complex framework conditions of German rail transport for the first time. The perspective use of the GIS as well as the utilization of the derived recommendations for action contribute to realizing DTs. Consequently, this work is to be regarded as an important instrument for achieving the operational optimization and intelligent management of rail transport assets. Full article
