In renewable and sustainable hydrogen production energy systems (RSHPES), the presence of harmonics gives rise to fluctuations in the voltage and current of the electrolysis cell (EC). This, in turn, results in an unstable electrolysis process, a reduction in hydrogen production efficiency, and an escalation in electrode corrosion. This paper puts forward a novel harmonic suppression control method (HSCM), which is devised for the single phase PWM rectifier in hydrogen production rectifiers (HPR) with the aim of alleviating the adverse impacts caused by harmonics. Initially, a highly meticulous harmonic model is constructed, which lays solid groundwork for understanding the existing problems. Subsequently, a comprehensive and detailed explanation of the HSCM is provided, accentuating its novel and inventive strategy for harmonic suppression. Thereafter, a comparison is drawn between the HSCM and traditional methods, thereby manifesting its enhanced suitability and superiority within the context of RSHPES. In conclusion, the simulation and experimental results vividly demonstrate the advantages, effectiveness, and practicality of HSCM under four conditions of power grids containing integer multiples of harmonics, interharmonics, ultraharmonics, and voltage disturbances. Full article

With the emphasis on energy conversion and energy-saving technologies, the single-phase pulse width modulation (PWM) rectifier method is widely used in urban rail transit because of its advantages of bidirectional electric energy conversion and higher power factor. However, due to the complex control and harsh environment, it can easily fail. Faults can cause current and voltage distortion, harmonic increases and other problems, which can threaten the safety of the power system and the train. In order to ensure the stable operation of the rectifier, incidences of faults should be reduced. A fault diagnosis technique based on Euclidean norm fusion multi-frequency bands and multi-scale permutation entropy is proposed. Firstly, by the optimal wavelet function, information on the optimal multi-frequency bands of the fault signal is selected after wavelet packet decomposition. Secondly, the multi-scale permutation entropy of each frequency band is calculated, and multiple fault feature vectors are obtained for each frequency band. To reduce the classifier’s computational cost, the Euclidean norm is used to fuse the multi-scale permutation entropy into an entropy value, so that each frequency band uses an entropy value to characterize the fault information features. Finally, the optimal multi-frequency bands and multi-scale permutation entropy after fusion are used as the fault feature vector. In the simulation system, it is shown that the method’s average accuracy is 78.46%, 97.07%, and 99.45% when the SNR is 5 dB, 10 dB, and 15 dB, respectively. And the fusion of multi-scale permutation entropy can improve the accuracy, recall rate, precision, and F1 score and reduce the False Alarm Rate (FAR) and the Missing Alarm Rate (MAR). The results show that the fault diagnosis method has high diagnosis accuracy, is a simple feature fusion method, and has good robustness to working conditions and noise. Full article

To effectively eliminate the impacts of both matched and mismatched power disturbances in a three-phase PWM rectifier, this paper proposes a robust direct power control (RDPC) method with a single-loop control structure. Firstly, a nonlinear power model of the three-phase PWM rectifier is established. Then, using the exact feedback linearization method, a linearized power model including matched and mismatched power disturbances is derived and achieves the decoupling of active and reactive power. Secondly, to regulate the DC bus voltage, a sliding-mode controller (SMC) combined with a nonlinear disturbance observer (NDO) is proposed. The proposed SMC combined with an NDO (SMC + NDO) method features a single-loop control structure, which enables a faster response and simpler structure compared to the dual-loop DPC method. By incorporating estimated mismatched power disturbance into the sliding-mode surface, it overcomes the SMC’s defect in incompletely suppressing mismatched disturbances and enables the simultaneous regulation of voltage and active power. Additionally, it effectively reduces sliding-mode chattering. To regulate reactive power, a sliding-mode controller based on the exponential convergence law is designed to suppress matched reactive power disturbances. Finally, the simulation and experimental comparative results demonstrate that the proposed controller exhibits stronger robustness against matched and mismatched power disturbances, as well as a better performance under the constant power load (CPL). Full article

Due to their advantages in ensuring low harmonic distortion and high power factors, single-phase Pulse-Width Modulated (PWM) rectifiers are widely employed in several industrial applications. Generally, the conventional control loop of a single-phase PWM rectifier uses both voltage and current sensors. Hence, in case of sensor fault, the performance and the availability of the converter can be seriously compromised. Therefore, diagnosis approaches and fault-tolerant control (FTC) strategies are mandatory to monitor these systems. Accordingly, this paper introduces a novel multiple-sensor FTC scheme for a single-phase PWM rectifier. The proposed fault diagnosis approach relies on joining several Generalized Proportional Integral (GPI) and Model Reference Adaptive System (MRAS) observers with a residual generation technique to detect and isolate sensor faults in a simple and reliable manner. While conventional sensor FTC methods dedicated to PWM rectifiers can only deal with single faults, the suggested approach guarantees a very good effectiveness level of sensor fault detection, isolation (FDI) and FTC of multiple-sensor fault occurrence scenarios. Consequently, the single-phase PWM rectifier can work with only the survivable single sensor with the guarantee of very good performance as in healthy operation mode. The effectiveness of the proposed sensor FDI approach and its control reconfiguration performance are demonstrated through both extensive simulation and experimental results. Full article

Energy-feed power electronic loads can precisely control the phase and magnitude of the power supply output current, achieving the emulation of loads. Moreover, they can feed energy back to the grid for energy regeneration, demonstrating significant research value. This article proposes an energy-fed power electronic load topology and control method that can realize the static and dynamic simulation of linear and non-linear loads and take into account the simulation needs of single-phase, three-phase three-wire, and three-phase four-wire loads. The main circuit uses a two-stage back-to-back AC/DC/AC structure: the front side is a three-phase four-wire split capacitor PWM rectifier bridge, which is used to simulate loads under various operating conditions; the back side is a three-phase three-wire PWM inverter bridge, which realizes the energy feeding back to the grid and reduces the waste of energy; and the intermediate side uses a split capacitor to equalize the voltage and achieve voltage stabilization. The topology is analyzed under the simulation demands of three-phase balanced, three-phase unbalanced, single-phase and non-linear loads. Finally, a MATLAB(R2022a)/Simulink simulation platform is built for a power electronic load with a rated capacity of 200 kVA. The simulation results verify the effectiveness, feasibility, and advancement of the power electronic load proposed in this article. Full article

Small-scale wind turbines play an important role in distributed generation since customers can use their houses, farms, and business to produce electric energy. The development of the power electronics system that processes the electric energy from small-scale wind turbines is a concern due to cost, simplicity, efficiency, and performance trade-offs. This paper presents the results of applying a three-phase phase-modular single-ended primary-inductance converter rectifier to processing the energy of a small-scale wind turbine system. The rectifier was designed according to the specifications of a commercial small-scale wind turbine system and tested in an emulator workbench, providing experimental data on the operation of the rectifier in this application. The rectifier can process the energy of a non-sinusoidal three-phase system since the permanent magnet synchronous generator has trapezoidal waveforms. The results show that the rectifier has the advantages of (i) using the inductance of the generator as the input filter inductor of the rectifier, (ii) providing input currents with the same shape as the voltages and in phase without the use of a current control system, (iii) simplicity of control of the DC output voltage and PWM modulation, and (iv) phase-modular characteristics that allow operating with phase fault without any additional control techniques. Due to the operation in discontinuous conduction mode, low efficiency in high power and/or low input voltage specifications are disadvantages. Full article

This study developed a grid-connected biogas power generation system for a rural community using a 3-phase 2.2 kW squirrel-cage induction machine as the self-excited induction generator. The generator was driven by a 196 cc single-cylinder spark-ignition engine fueled by biogas. We developed a back-to-back converter that consists of a 3-phase PWM rectifier as the generator-side converter and a single-phase LCL-filtered grid-connected inverter. The generator-side converter transferred the active power to the grid-side converter and supplied the reactive power control back to the generator. The notch filter-based bus voltage control on the generator side mitigated the inter-harmonics in the generator current. The injected grid current complied with the IEEE 1547 standard because of the multi-frequency unbalanced synchronous reference frame control. The proposed system was validated with biogas produced from pig manure at a pig farm in central Thailand, which found a maximum output of 1.2 kW with a thermal system efficiency of 10.7%. The proposed system was scheduled to operate at 1.2 kW for 8 h per day with a levelized cost of 0.07 US$/kWh, 42% cheaper than the retail electricity price, and a payback period of 2.76 years. The proposed system is suitable for a farm with a minimum of 34 pigs. Full article

The growing utilization of single-phase pulse width modulation (PWM) rectifiers in various applications has spurred interest in detecting and monitoring faults in these devices. In particular, voltage and current sensors play a crucial role in the control loop of these rectifiers. However, sensor faults can significantly affect the converter’s performance and availability. This paper introduces a novel and efficient method for detecting and decoupling sensor faults in single-phase PWM rectifiers. The proposed method utilizes residual generation and incorporates an extended filter within the rectifier. Unlike conventional filters, the presented fault detection and isolation (FDI) method effectively eliminates the influence of disturbances on the residual signal. This feature helps prevent false alarms in the monitored system, ensuring reliable fault detection. To evaluate the effectiveness of the approach, hardware-in-the-loop and simulation tests were conducted. The results from these tests provide substantial evidence supporting the efficacy of the proposed method. The hardware-in-the-loop experiments involved real-world implementation, validating the practicality and reliability of the approach. Meanwhile, simulation tests allowed for a comprehensive analysis of system behavior and performance under various fault scenarios. The findings demonstrate the rapid and dependable nature of the proposed method for detecting and decoupling sensor faults in single-phase PWM rectifiers. By effectively mitigating the impact of disturbances on the residual signal, false alarms are minimized, ensuring accurate fault detection. The experimental validation highlights the practical applicability and effectiveness of the proposed approach, making it a valuable contribution to fault detection in single-phase PWM rectifiers. Full article

Maintaining safe and efficient operation in a single-phase pulse width modulation (PWM) rectifier that employs current sensors relies heavily on accurate sensor readings. However, several factors such as environmental conditions, aging, or damage can lead to sensor faults. Therefore, it is imperative to implement robust fault detection methods to ensure reliable system operation. The use of unknown input observer techniques is one such method that involves analyzing the differences between actual and estimated states to detect and identify faults in the system. This paper presents the development of a fault detection method that employs an unknown input observer with high sensitivity to faults and disturbance rejection to achieve robust fault detection. The method involves modeling the system as a state-space model and designing an observer to estimate the system’s state variables based on input and output measurements. The deviations between the actual and estimated states are then analyzed to detect and identify sensor faults, without the need for additional hardware, making it a cost-effective solution. Hardware-in-the-loop tests confirm the effectiveness of the proposed method. Full article

The popularity of multiphase drives is increasing due to the growing interest in drives with more than three phases. One promising topology is the multiphase matrix converters, which enable the implementation of a single-stage AC/AC power conversion system with bidirectional power flow capability. In this paper, we present the implementation of indirect control for a practical sample of the direct matrix converter. To reduce the overall cost of the control solution for these types of converters, we utilized low-cost FPGA and DSP. The usage of only DSP itself was not possible due to low number of available PWM output needed for 3 × 5 MxC driving. Another reason is commutation, which must be precise and fast to avoid any hazardous states in the converter. Due to these problems, the authors decided to implement an algorithm of a combination of DSP and FPGA, where FPGA is used for time critical operations. The indirect algorithm treats the converter as two separate parts, the rectifier and the inverter, with the DC-LINK being fictitious. The matrix converter is composed of compact modules, and the entire system is verified. The practical verification demonstrates that matrix converters can produce a wide range of output frequencies and achieve input power factor control. Finally, we compare and review the practical model with the simulation model, examining efficiency and other parameters. Full article

In this paper, a novel algorithm with a rotating coordinate system is proposed to improve the total harmonic distortion (THD) of PWM rectifiers. Aiming at solving the disadvantages of poor dynamic response, unstable switching frequency, and a large calculation burden in some current control methods, the proposed method employs the rotating coordinate system to control the active current and reactive current separately while modifying the calculation error. The proposed method is verified through a single-phase PWM rectifier. Based on the measured results and compared with many other algorithms, such as the peak current mode control (PCMC), average current mode control (ACMC), one cycle control (OCC), and modulating duty ratio (MDR), the proposed method not only effectively reduces the intermediate variables during calculation, but also improves the THD and reliability of the circuit. The proposed method can be applied in single-phase PWM rectifiers applied in household-distributed energy storage systems. Full article

The induction heating process at a domestic level is getting attention nowadays as this power converting topology ensures clean, reliable, flexible, and fast operation. The low input frequency is converted to required regulated high output frequency with indirect and direct power converting approaches. The circuit and control complexity and high conversion losses associated with indirect power converting approaches lower their uses for domestic induction systems. The direct ac-ac power conversion approach is one of the viable solutions for low and medium power level loads, especially for domestic induction heating loads. The circuit complexity, cost, and conversion losses of the direct power converting systems depend on the number of the controlled switching devices as each controlled switch requires one gate driving circuit and one isolated dc supply. Simplified pulse width modulation (PWM) switching control also lower their control effort. Therefore, in this article, a simplified direct ac-ac power converting approach is introduced for a high-frequency domestic induction heating system. Here, the regulation of the high output frequency is achieved by simply cascading the single-phase full-bridge rectifier with a full-bridge inverter with a simple control strategy. The characteristics of the developed topology are validated through simulation results of the Simulink-based platform and practical results of the developed practical setup. Full article

The hybrid three-phase rectifiers (HTR) consist of parallel associations of two rectifiers (rectifier 1 and rectifier 2), each one of them with a distinct operation, while the sum of their input currents forms a sinusoidal or multilevel waveform. In general, rectifier 1 is a GRAETZ (full bridge) (can be combined with a BOOST converter) and rectifier 2 is combined with a DC-DC converter. In this HTR contest, this paper is intended to answer some important questions about those hybrid rectifiers. To obtain the correct answers, the study is conducted as an analysis of a systematic literature review. Thus, a search was carried out in the databases, mostly IEEE and IET, and 34 papers were selected as the best corresponding to the HTR theme. It is observed that the preferred form of power distribution in unidirectional hybrid three-phase rectifiers (UHTR) is $55\%P_o$ (rectifier 1) and $45\%P_o$ (rectifier 2). For the bidirectional hybrid three-phase rectifiers (BHTR), rectifier 1 preferably takes $90\%\mathrm{of}{P}_o$ and $10\%\mathrm{of}{P}_o$ is processed by rectifier 2. It is also observed that the UHTR that employ the single-ended primary-inductor converter (SEPIC) or VIENNA converter topologies in rectifier 2 can present sinusoidal input currents with low total harmonic distortion (THD) and high Power Factor (PF), even successfully complying with the international standards. The same can be said about the rectifier that employs a pulse-width (PWM) converter of BOOST topology in rectifier 2. In short, the HTR are interesting because they allow using the GRAETZ full bridge topology in rectifier 1, thus taking advantage of its characteristics, being simple, robust, and reliable. At the same time, the advantages of rectifier 2, i.e., high PF and low THD, are well used. In addition, this article also points out the future direction of research that is still unexplored in the literature, thus giving opportunities for future innovation. Full article

The research object of this paper is single-phase PWM rectifier, the purpose is to reduce the total harmonic distortion (THD) of the grid-side current. A model predictive current control (MPCC) with fixed switching frequency and dead-time compensation is proposed. First, a combination of an effective vector and two zero vectors is used to fix the switching frequency, and a current prediction equation based on the effective vector’s optimal action time is derived. The optimal action time is resolved from the cost function. Furthermore, in order to perfect the established prediction model and suppress the current waveform distortion as a consequence of the dead-time effect, the dead-time’s influence on the switching vector’s action time is analyzed, and the current prediction equation is revised. According to the experimental results, the conclusion is that, firstly, compared with finite-control-set model predictive control, proportional-integral-based instantaneous current control (PI-ICC) scheme and model predictive direct power control (MP-DPC), the proposed MPCC has the lowest current THD. In addition, the proposed MPCC has a shorter execution time than MP-DPC and has fewer adjusted parameters than PI-ICC. In addition, the dead-time compensation scheme successfully suppresses the zero-current clamping effects, and reduce the current THD. Full article

The aim of this paper is to determine which type of control loop is better for each particular type of standard voltage source inverter (VSI) load (static, dynamic, nonlinear rectifier resistive-capacitive RC load). A comparison of three different types of controllers for single-phase VSIs is presented. The first two are of the single input single output (SISO)/proportional-integral-derivative controller (PID) and coefficient diagram method (CDM) types, and the third is of the multi-input single output (MISO)/passivity-based control (PBC) type. The selections of the gains for SISO and MISO controllers are presented, including the problem in the choice of PBC controller gains caused by the imperfection of the pulse width modulation (PWM) modulator. For a standard nonlinear rectifier RC load, the new control quality factor (CQF) is defined to distinguish the properties of the controllers. The results show the superiority of the MISO-PBC controller for the RC load; however, for a linear dynamic load, the MISO-PBC performed worse than the SISO-PID or CDM. Therefore, the choice between either a simple and inexpensive SISO with one measurement trace or an expensive MISO with three measurement traces depends on the purpose of the VSI. The initial simulations and measurements of the experimental models are presented and discussed. Full article
