Remote Sens., Volume 9, Issue 8 (August 2017) – 108 articles

In this study, full-waveform LiDAR data were exploited to detect weak returns backscattered by the bare terrain underneath vegetation canopies and thus improve the generation of a digital terrain model (DTM). Building on the methods of progressive generation of triangulation irregular network (TIN) model reported in the literature, we proposed an integrated approach where echo detection, terrain identification, and TIN generation were carried out iteratively. The proposed method was tested on a dataset collected by a Riegl LMS Q-560 scanner over a study area near Sault Ste. Marie, Ontario, Canada (46°33′56′′N, 83°25′18′′W). The results demonstrated that more terrain points under shrubs could be identified, and the generated DTMs exhibited more details in the terrain than those obtained using the progressive TIN method. In addition, 1275 points across this study area were surveyed on the ground and used to validate the proposed approach. The estimated elevations were shown to have a strong linear relationship with the measured ones, with R² values above 0.98, and the RMSEs (Root Mean Squared Errors) between them were less than 0.15 m even for areas with hilly terrains underneath vegetation canopies. Full article

This study attempts to estimate spatial soil moisture in South Korea (99,000 km²) from January 2013 to December 2015 using a multiple linear regression (MLR) model and the Terra moderate-resolution imaging spectroradiometer (MODIS) land surface temperature (LST) and normalized distribution vegetation index (NDVI) data. The MODIS NDVI was used to reflect vegetation variations. Observed precipitation was measured using the automatic weather stations (AWSs) of the Korea Meteorological Administration (KMA), and soil moisture data were recorded at 58 stations operated by various institutions. Prior to MLR analysis, satellite LST data were corrected by applying the conditional merging (CM) technique and observed LST data from 71 KMA stations. The coefficient of determination (R²) of the original LST and observed LST was 0.71, and the R² of corrected LST and observed LST was 0.95 for 3 selected LST stations. The R² values of all corrected LSTs were greater than 0.83 for total 71 LST stations. The regression coefficients of the MLR model were estimated seasonally considering the five-day antecedent precipitation. The p-values of all the regression coefficients were less than 0.05, and the R² values were between 0.28 and 0.67. The reason for R² values less than 0.5 is that the soil classification at each observation site was not completely accurate. Additionally, the observations at most of the soil moisture monitoring stations used in this study started in December 2014, and the soil moisture measurements did not stabilize. Notably, R² and root mean square error (RMSE) in winter were poor, as reflected by the many missing values, and uncertainty existed in observations due to freezing and mechanical errors in the soil. Thus, the prediction accuracy is low in winter due to the difficulty of establishing an appropriate regression model. Specifically, the estimated map of the soil moisture index (SMI) can be used to better understand the severity of droughts with the variability of soil moisture. Full article

Every year, a large number of aerosols are released from dust storms into the atmosphere, which may have potential impacts on the climate, environment, and air quality. Detecting dust aerosols and monitoring their movements and evolutions in a timely manner is a very significant task. Satellite remote sensing has been demonstrated as an effective means for observing dust aerosols. In this paper, an algorithm based on the multi-spectral technique for detecting dust aerosols was developed by combining measurements of moderate resolution imaging spectroradiometer (MODIS) reflective solar bands and thermal emissive bands. Data from dust events that occurred during the past several years were collected as training data for spectral and statistical analyses. According to the spectral curves of various scene types, a series of spectral bands was selected individually or jointly, and corresponding thresholds were defined for step-by-step scene classification. The multi-spectral algorithm was applied mainly to detect dust storms in Asia. The detection results were validated not only visually with MODIS true color images, but also quantitatively with products of Ozone Monitoring Instrument (OMI) and Cloud Aerosol Lidar with Orthogonal Polarization (CALIOP). The validations showed that this multi-spectral detection algorithm was suitable to monitor dust aerosols in the selected study areas. Full article

Hyperspectral images and light detection and ranging (LiDAR) data have, respectively, the high spectral resolution and accurate elevation information required for urban land-use/land-cover (LULC) classification. To combine the respective advantages of hyperspectral and LiDAR data, this paper proposes an optimal decision fusion method based on adaptive differential evolution, namely ODF-ADE, for urban LULC classification. In the ODF-ADE framework the normalized difference vegetation index (NDVI), gray-level co-occurrence matrix (GLCM) and digital surface model (DSM) are extracted to form the feature map. The three different classifiers of the maximum likelihood classifier (MLC), support vector machine (SVM) and multinomial logistic regression (MLR) are used to classify the extracted features. To find the optimal weights for the different classification maps, weighted voting is used to obtain the classification result and the weights of each classification map are optimized by the differential evolution algorithm which uses a self-adaptive strategy to obtain the parameter adaptively. The final classification map is obtained after post-processing based on conditional random fields (CRF). The experimental results confirm that the proposed algorithm is very effective in urban LULC classification. Full article

We investigate the effects of aerosol optical depth (AOD), single scattering albedo (SSA), aerosol peak height (APH), measurement geometry (solar zenith angle (SZA) and viewing zenith angle (VZA)), relative azimuth angle, and surface reflectance on the accuracy of NO₂ slant column density using synthetic radiance. High AOD and APH are found to decrease NO₂ SCD retrieval accuracy. In moderately polluted (5 × 10¹⁵ molecules cm⁻² < NO₂ vertical column density (VCD) < 2 × 10¹⁶ molecules cm⁻²) and clean regions (NO₂ VCD < 5 × 10¹⁵ molecules cm⁻²), the correlation coefficient (R) between true NO₂ SCDs and those retrieved is 0.88 and 0.79, respectively, and AOD and APH are about 0.1 and is 0 km, respectively. However, when AOD and APH are about 1.0 and 4 km, respectively, the R decreases to 0.84 and 0.53 in moderately polluted and clean regions, respectively. On the other hand, in heavily polluted regions (NO₂ VCD > 2 × 10¹⁶ molecules cm⁻²), even high AOD and APH values are found to have a negligible effect on NO₂ SCD precision. In high AOD and APH conditions in clean NO₂ regions, the R between true NO₂ SCDs and those retrieved increases from 0.53 to 0.58 via co-adding four pixels spatially, showing the improvement in accuracy of NO₂ SCD retrieval. In addition, the high SZA and VZA are also found to decrease the accuracy of the NO₂ SCD retrieval. Full article

Synthetic aperture radar (SAR) is one of the most important techniques for ocean monitoring. Azimuth ambiguities are a real problem in SAR images today, which can cause performance degradation in SAR ocean applications. In particular, littoral zones can be strongly affected by land-based sources, whereas they are usually regions of interest (ROI). Given the presence of complexity and diversity in littoral zones, azimuth ambiguities removal is a tough problem. As SAR sensors can have a repeat cycle, multi-temporal SAR images provide new insight into this problem. A method for azimuth ambiguities removal in littoral zones based on multi-temporal SAR images is proposed in this paper. The proposed processing chain includes co-registration, local correlation, binarization, masking, and restoration steps. It is designed to remove azimuth ambiguities caused by fixed land-based sources. The idea underlying the proposed method is that sea surface is dynamic, whereas azimuth ambiguities caused by land-based sources are constant. Thus, the temporal consistence of azimuth ambiguities is higher than sea clutter. It opens up the possibilities to use multi-temporal SAR data to remove azimuth ambiguities. The design of the method and the experimental procedure are based on images from the Sentinel data hub of Europe Space Agency (ESA). Both Interferometric Wide Swath (IW) and Stripmap (SM) mode images are taken into account to validate the proposed method. This paper also presents two RGB composition methods for better azimuth ambiguities visualization. Experimental results show that the proposed method can remove azimuth ambiguities in littoral zones effectively. Full article

The 2008 Wenchuan earthquake and associated co-seismic landslide was the most recent expression of the rapid deformation and erosion occurring in the eastern Tibetan Plateau. The erosion associated with co-seismic landslides balances the long-term tectonic uplift in the topographic evolution of the region; however, the quantitative relationship between earthquakes, uplift, and erosion is still unknown. In order to quantitatively distinguish the seismically-induced erosion in the total erosion, here, we quantify the Wenchuan earthquake-induced erosion using the digital elevation model (DEM) differential method and previously-reported landslide volumes. Our results show that the seismically-induced erosion is comparable with the pre-earthquake short-term erosion. The seismically-induced erosion rate contributes ~50% of the total erosion rate, which suggests that the local topographic evolution of the middle Longmen Shan region may be closely related to tectonic events, such as the 2008 Wenchuan earthquake. We propose that seismically-induced erosion is a very important component of the total erosion, particularly in active orogenic regions. Our results demonstrate that the remote sensing technique of differential DEM provides a powerful tool for evaluating the volume of co-seismic landslides produced in intermountain regions by strong earthquakes. Full article

Satellite derived vegetation indices (VIs) are broadly used in ecological research, ecosystem modeling, and land surface monitoring. The Normalized Difference Vegetation Index (NDVI), perhaps the most utilized VI, has countless applications across ecology, forestry, agriculture, wildlife, biodiversity, and other disciplines. Calculating satellite derived NDVI is not always straight-forward, however, as satellite remote sensing datasets are inherently noisy due to cloud and atmospheric contamination, data processing failures, and instrument malfunction. Readily available NDVI products that account for these complexities are generally at coarse resolution; high resolution NDVI datasets are not conveniently accessible and developing them often presents numerous technical and methodological challenges. We address this deficiency by producing a Landsat derived, high resolution (30 m), long-term (30+ years) NDVI dataset for the conterminous United States. We use Google Earth Engine, a planetary-scale cloud-based geospatial analysis platform, for processing the Landsat data and distributing the final dataset. We use a climatology driven approach to fill missing data and validate the dataset with established remote sensing products at multiple scales. We provide access to the composites through a simple web application, allowing users to customize key parameters appropriate for their application, question, and region of interest. Full article

The accurate and timely monitoring of regional urban extent is helpful for analyzing urban sprawl and studying environmental issues related to urbanization. This paper proposes a classification scheme for large-scale urban extent mapping by combining the Day/Night Band of the Visible Infrared Imaging Radiometer Suite on the Suomi National Polar-orbiting Partnership Satellite (NPP-VIIRS DNB) and the Normalized Difference Vegetation Index from the Moderate Resolution Imaging Spectroradiometer products (MODIS NDVI). A Back Propagation (BP) neural network based one-class classification method, the Present-Unlabeled Learning (PUL) algorithm, is employed to classify images into urban and non-urban areas. Experiments are conducted in mainland China (excluding surrounding islands) to detect urban areas in 2012. Results show that the proposed model can successfully map urban area with a kappa of 0.842 on the pixel level. Most of the urban areas are identified with a producer’s accuracy of 79.63%, and only 10.42% the generated urban areas are misclassified with a user’s accuracy of 89.58%. At the city level, among 647 cities, only four county-level cities are omitted. To evaluate the effectiveness of the proposed scheme, three contrastive analyses are conducted: (1) comparing the urban map obtained in this paper with that generated by the Defense Meteorological Satellite Program/Operational Linescan System Nighttime Light Data (DMSP/OLS NLD) and MODIS NDVI and with that extracted from MCD12Q1 in MODIS products; (2) comparing the performance of the integration of NPP-VIIRS DNB and MODIS NDVI with single input data; and (3) comparing the classification method used in this paper (PUL) with a linear method (Large-scale Impervious Surface Index (LISI)). According to our analyses, the proposed classification scheme shows great potential to map regional urban extents in an effective and efficient manner. Full article

Artisanal and Small-scale Gold Mining (ASGM) within the Amazon region has created several environmental impacts, such as mercury contamination and changes in water quality due to increased siltation. This paper describes the effects of water siltation on the underwater light environment of rivers under different levels of gold mining activities in the Tapajós River Basin. Furthermore, it investigates possible impacts on the phytoplankton community. Two field campaigns were conducted in the Tapajós River Basin, during high water level and during low water level seasons, to measure Inherent and Apparent Optical Properties (IOPs, AOPs), including scattering (b) and absorption (a) coefficients and biogeochemical data (sediment content, pigments, and phytoplankton quantification). The biogeochemical data was separated into five classes according to the concentration of total suspended solids (TSS) ranging from 1.8 mg·L⁻¹ to 113.6 mg·L⁻¹. The in-water light environment varied among those classes due to a wide range of concentrations of inorganic TSS originated from different levels of mining activities. For tributaries with low or no influence of mining tailings (TSS up to 6.8 mg·L⁻¹), waters are relatively more absorbent with b:a ratio of 0.8 at 440 nm and b₆₆₀ magnitude of 2.1 m⁻¹. With increased TSS loadings from mining operations (TSS over 100 mg·L⁻¹), the scattering process prevails over absorption (b:a ratio of 10.0 at 440 nm), and b₆₆₀ increases to 20.8 m⁻¹. Non-impacted tributaries presented a critical depth for phytoplankton productivity of up to 6.0 m with available light evenly distributed throughout the spectra. Whereas for greatly impacted waters, attenuation of light was faster, reducing the critical depth to about 1.7 m, with most of the available light comprising of red wavelengths. Overall, a dominance of diatoms was observed for the upstream rivers, whereas cyanobacteria prevailed in the low section of the Tapajós River. The results suggest that the spatial and temporal distribution of phytoplankton in the Tapajós River Basin is not only a function of light availability, but rather depends on the interplay of factors, including flood pulse, water velocity, nutrient availability, and seasonal variation of incoming irradiance. Ongoing research indicates that the effects of mining tailings on the aquatic environment, described here, are occurring in several rivers within the Amazon River Basin. Full article

In this paper, the retrieving significant wave height from X-band marine radar images based on shadow statistics is investigated, since the retrieving accuracy can not be seriously affected by environmental factors and the method has the advantage of without any external reference to calibrate. However, the accuracy of the significant wave height estimated from the radar image acquired at the near-shore area is not ideal. To solve this problem, the effect of water depth is considered in the theoretical derivation of estimated wave height based on the sea surface slope. And then, an improved retrieving algorithm which is suitable for both in deep water area and shallow water area is developed. In addition, the radar data are sparsely processed in advance in order to achieve high quality edge image for the requirement of shadow statistic algorithm, since the high resolution radar images will lead to angle-blurred for the image edge detection and time-consuming in the estimation of sea surface slope. The data acquired from Pingtan Test Base in Fujian Province were used to verify the effectiveness of the proposed algorithm. The experimental results demonstrate that the improved method which takes into account the water depth is more efficient and effective and has better performance for retrieving significant wave height in the shallow water area, compared to the in situ buoy data as the ground truth and that of the existing shadow statistic method. Full article

Synthetic aperture radar (SAR) ship detection has been playing an increasingly essential role in marine monitoring in recent years. The lack of detailed information about ships in wide swath SAR imagery poses difficulty for traditional methods in exploring effective features for ship discrimination. Being capable of feature representation, deep neural networks have achieved dramatic progress in object detection recently. However, most of them suffer from the missing detection of small-sized targets, which means that few of them are able to be employed directly in SAR ship detection tasks. This paper discloses an elaborately designed deep hierarchical network, namely a contextual region-based convolutional neural network with multilayer fusion, for SAR ship detection, which is composed of a region proposal network (RPN) with high network resolution and an object detection network with contextual features. Instead of using low-resolution feature maps from a single layer for proposal generation in a RPN, the proposed method employs an intermediate layer combined with a downscaled shallow layer and an up-sampled deep layer to produce region proposals. In the object detection network, the region proposals are projected onto multiple layers with region of interest (ROI) pooling to extract the corresponding ROI features and contextual features around the ROI. After normalization and rescaling, they are subsequently concatenated into an integrated feature vector for final outputs. The proposed framework fuses the deep semantic and shallow high-resolution features, improving the detection performance for small-sized ships. The additional contextual features provide complementary information for classification and help to rule out false alarms. Experiments based on the Sentinel-1 dataset, which contains twenty-seven SAR images with 7986 labeled ships, verify that the proposed method achieves an excellent performance in SAR ship detection. Full article

Monitoring fine particulate matter with diameters of less than 2.5 μm (PM2.5) is a critical endeavor in the Beijing–Tianjin–Hebei (BTH) region, which is one of the most polluted areas in China. Polar orbit satellites are limited by observation frequency, which is insufficient for understanding PM2.5 evolution. As a geostationary satellite, Himawari-8 can obtain hourly optical depths (AODs) and overcome the estimated PM2.5 concentrations with low time resolution. In this study, the evaluation of Himawari-8 AODs by comparing with Aerosol Robotic Network (AERONET) measurements showed Himawari-8 retrievals (Level 3) with a mild underestimate of about −0.06 and approximately 57% of AODs falling within the expected error established by the Moderate-resolution Imaging Spectroradiometer (MODIS) (±(0.05 + 0.15AOD)). Furthermore, the improved linear mixed-effect model was proposed to derive the surface hourly PM2.5 from Himawari-8 AODs from July 2015 to March 2017. The estimated hourly PM2.5 concentrations agreed well with the surface PM2.5 measurements with high R² (0.86) and low RMSE (24.5 μg/m³). The average estimated PM2.5 in the BTH region during the study time range was about 55 μg/m³. The estimated hourly PM2.5 concentrations ranged extensively from 35.2 ± 26.9 μg/m³ (1600 local time) to 65.5 ± 54.6 μg/m³ (1100 local time) at different hours. Full article

Fractional vegetation cover (FVC) is an essential land surface parameter for Earth surface process simulations and global change studies. The currently existing FVC products are mostly obtained from low or medium resolution remotely sensed data, while many applications require the fine spatial resolution FVC product. The availability of well-calibrated coverage of Landsat imagery over large areas offers an opportunity for the production of FVC at fine spatial resolution. Therefore, the objective of this study is to develop a general and reliable land surface FVC estimation algorithm for Landsat surface reflectance data under various land surface conditions. Two machine learning methods multivariate adaptive regression splines (MARS) model and back-propagation neural networks (BPNNs) were trained using samples from PROSPECT leaf optical properties model and the scattering by arbitrarily inclined leaves (SAIL) model simulations, which included Landsat reflectance and corresponding FVC values, and evaluated to choose the method which had better performance. Thereafter, the MARS model, which had better performance in the independent validation, was evaluated using ground FVC measurements from two case study areas. The direct validation of the FVC estimated using the proposed algorithm (Heihe: R² = 0.8825, RMSE = 0.097; Chengde using Landsat 7 ETM+: R² = 0.8571, RMSE = 0.078, Chengde using Landsat 8 OLI: R² = 0.8598, RMSE = 0.078) showed the proposed method had good performance. Spatial-temporal assessment of the estimated FVC from Landsat 7 ETM+ and Landsat 8 OLI data confirmed the robustness and consistency of the proposed method. All these results indicated that the proposed algorithm could obtain satisfactory accuracy and had the potential for the production of high-quality FVC estimates from Landsat surface reflectance data. Full article

The overestimation of volume scattering (OVS) is an intrinsic drawback in model-based polarimetric synthetic aperture radar (PolSAR) target decomposition. It severely impacts the accuracy measurement of scattering power and leads to scattering mechanism ambiguity. In this paper, a hierarchical extended general four-component scattering power decomposition method (G4U) is presented. The conventional G4U is first proposed by Singh et al. and it has advantages in full use of information and volume scattering characterization. However, the OVS still exists in the G4U and it causes a scattering mechanism ambiguity in some oriented urban areas. In the proposed method, matrix rotations by the orientation angle and the helix angle are applied. Afterwards, the transformed coherency matrix is applied to the four-component decomposition scheme with two refined models. Moreover, the branch condition applied in the G4U is substituted by the ratio of correlation coefficient (RCC), which is used as a criterion for hierarchically implementing the decomposition. The performance of this approach is demonstrated and evaluated with the Airborne Synthetic Aperture Radar (AIRSAR), Uninhabited Aerial Vehicle Synthetic Aperture Radar (UAVSAR), Radarsat-2, and the Advanced Land Observing Satellite (ALOS) Phased Array type L-band Synthetic Aperture Radar (PALSAR) fully polarimetric data over different test sites. Comparison studies are carried out and demonstrated that the proposed method exhibits promising improvements in the OVS and scattering mechanism characterization. Full article

Crop identification in large irrigation districts is important for crop yield estimation, hydrological simulation, and agricultural water management. Remote sensing provides an opportunity to visualize crops in the regional scale. However, the use of coarse resolution remote sensing images for crop identification usually causes great errors due to the presence of mixed pixels in regions with complex planting structure of crops. Therefore, it is preferable to use remote sensing data with high spatial and temporal resolutions in crop identification. This study aimed to map multi-year distributions of major crops (maize and sunflower) in Hetao Irrigation District, the third largest irrigation district in China, using HJ-1A/1B CCD images with high spatial and temporal resolutions. The Normalized Difference Vegetation Index (NDVI) series obtained from HJ-1A/1B CCD images was fitted with an asymmetric logistic curve to find the NDVI characteristics and phenological metrics for both maize and sunflower. Nine combinations of NDVI characteristics and phenological metrics were compared to obtain the optimal classifier to map maize and sunflower from 2009 to 2015. Results showed that the classification ellipse with the NDVI characteristic of the left inflection point in the NDVI curve and the phenological metric from the left inflection point to the peak point normalized, with mean values of corresponding grassland indexes achieving the minimum mean relative error of 10.82% for maize and 4.38% for sunflower. The corresponding Kappa coefficient was 0.62. These results indicated that the vegetation and phenology-based classifier using HJ-1A/1B data could effectively identify multi-year distribution of maize and sunflower in the study region. It was found that maize was mainly distributed in the middle part of the irrigation district (Hangjinhouqi and Linhe), while sunflower mainly in the east part (Wuyuan). The planting sites of sunflower had been gradually expanded from Wuyuan to the north part of Hangjinhouqi and Linhe. These results were in agreement with the local economic policy. Results also revealed the increasing trends of both maize and sunflower planting areas during the study period. Full article

The Sentinel-1 synthetic aperture radar (SAR) allows sufficient resources for cross-pol wind speed retrievals over the ocean. In this paper, we present technical evaluation on wind retrieval from both Sentinel-1A and Sentinel-1B IW cross-pol images. Algorithms are based on the existing theoretical and empirical ones derived from the RADARSAT-2 cross-pol data. First, to better understand the Sentinel-1 observed normalized radar cross section (NRCS) values under various environmental conditions, we constructed a dataset that integrates SAR images with wind field information from scatterometer measurements. There are 11,883 matchup data in the experimental dataset. We then calculated the systemic noise floor of Sentinel-1 IW mode, and presented its unique noise characteristics among different sub-bands. Based on the calculated NESZ measurements, the noise is removed for all matchup data. Empirical relationships among the noise free NRCS ${\sigma }_{\mathrm{VH}}^0$ , wind speed, wind direction, and radar incidence angle are analyzed for each sub-band, and a piecewise model is proposed. We showed that a larger correlation coefficient, r, is achieved by including both wind direction and incidence terms in the model. Validation against scatterometer measurements showed the suitability of the proposed model. Full article

The intensity value recorded by terrestrial laser scanning (TLS) systems is significantly influenced by the incidence angle. The incidence angle effect is an object property, which is mainly related to target scattering properties, surface structures, and even some instrumental effects. Most existing models focus on diffuse reflections of rough surfaces and ignore specular reflections, despite that both reflections simultaneously exist in all natural surfaces. Due to the coincidence of the emitter and receiver in TLS, specular reflections can be ignored at large incidence angles. On the contrary, at small incidence angles, TLS detectors can receive a portion of specular reflections. The received specular reflections can trigger highlight phenomenon (hot-spot effects) in the intensity data of the scanned targets, particularly those with a relatively smooth or highly-reflective surface. In this study, a new method that takes diffuse and specular reflections, as well as the instrumental effects into consideration, is proposed to eliminate the specular reflection effects in TLS intensity data. Diffuse reflections and instrumental effects are modeled by a polynomial based on Lambertian reference targets, whereas specular reflections are modeled by the Phong model. The proposed method is tested and validated on different targets scanned by the Faro Focus^3D 120 terrestrial scanner. Results imply that the coefficient of variation of the intensity data from a homogeneous surface is reduced by approximately 38% when specular reflections are considered. Compared with existing methods, the proposed method exhibits good feasibility and high accuracy in eliminating the specular reflection effects for intensity image interpretation and 3D point cloud representation by intensity. Full article

Using CO₂ data from the Atmospheric Infrared Sounder (AIRS), it is found for the first time that the mid-tropospheric CO₂ concentration is ~1 part per million by volume higher during dry years than wet years over the southwestern USA from June to September. The mid-tropospheric CO₂ differences between dry and wet years are related to circulation and CO₂ surface fluxes. During drought conditions, vertical pressure velocity from NCEP2 suggests that there is more rising air over most regions, which can help bring high surface concentrations of CO₂ to the mid-troposphere. In addition to the circulation, there is more CO₂ emitted from the biosphere to the atmosphere during droughts in some regions, which can contribute to higher concentrations of CO₂ in the atmosphere. Results obtained from this study demonstrate the significant impact of droughts on atmospheric CO₂ and therefore on a feedback cycle contributing to greenhouse gas warming. It can also help us better understand atmospheric CO₂, which plays a critical role in our climate system. Full article

This paper presents a novel method for fully automatic and convenient extrinsic calibration of a 3D LiDAR and a panoramic camera with a normally printed chessboard. The proposed method is based on the 3D corner estimation of the chessboard from the sparse point cloud generated by one frame scan of the LiDAR. To estimate the corners, we formulate a full-scale model of the chessboard and fit it to the segmented 3D points of the chessboard. The model is fitted by optimizing the cost function under constraints of correlation between the reflectance intensity of laser and the color of the chessboard’s patterns. Powell’s method is introduced for resolving the discontinuity problem in optimization. The corners of the fitted model are considered as the 3D corners of the chessboard. Once the corners of the chessboard in the 3D point cloud are estimated, the extrinsic calibration of the two sensors is converted to a 3D-2D matching problem. The corresponding 3D-2D points are used to calculate the absolute pose of the two sensors with Unified Perspective-n-Point (UPnP). Further, the calculated parameters are regarded as initial values and are refined using the Levenberg-Marquardt method. The performance of the proposed corner detection method from the 3D point cloud is evaluated using simulations. The results of experiments, conducted on a Velodyne HDL-32e LiDAR and a Ladybug3 camera under the proposed re-projection error metric, qualitatively and quantitatively demonstrate the accuracy and stability of the final extrinsic calibration parameters. Full article

Accurate characterization of the direction of land change is a neglected aspect of land dynamics. Knowledge on direction of historical land change can be useful information when understanding relative influence of different land-change drivers is of interest. In this study, we present a novel perspective on land-change analysis by focusing on directionality of change. To this end, we employed Maximum Cross-Correlation (MCC) approach to estimate the directional change in land cover in a dynamic river floodplain environment using Landsat 5 Thematic Mapper (TM) images. This approach has previously been used for detecting and measuring fluid and ice motions but not to study directional changes in land cover. We applied the MCC approach on land-cover class membership layers derived from fuzzy remote-sensing image classification. We tested the sensitivity of the resulting displacement vectors to three user-defined parameters—template size, search window size, and a threshold parameter to determine valid (non-noisy) displacement vectors—that directly affect the generation of change, or displacement, vectors; this has not previously been thoroughly investigated in any application domain. The results demonstrate that it is possible to quantitatively measure the rate of directional change in land cover in this floodplain environment using this particular approach. Sensitivity analyses indicate that template size and MCC threshold parameter are more influential on the displacement vectors than search window size. The results vary by land-cover class, suggesting that spatial configuration of land-cover classes should be taken into consideration in the implementation of the method. Full article

After publication of the research paper [1], the authors wish to make the following correction to this paper. In the fourth line from the bottom in abstract, due to a typing error, “RMSE = 0.84 m3/m3” should be replaced with “RMSE = 0.084 m3/m3”.[...] Full article

The rapid development of high spatial resolution (HSR) remote sensing imagery techniques not only provide a considerable amount of datasets for scene classification tasks but also request an appropriate scene classification choice when facing with finite labeled samples. AlexNet, as a relatively simple convolutional neural network (CNN) architecture, has obtained great success in scene classification tasks and has been proven to be an excellent foundational hierarchical and automatic scene classification technique. However, current HSR remote sensing imagery scene classification datasets always have the characteristics of small quantities and simple categories, where the limited annotated labeling samples easily cause non-convergence. For HSR remote sensing imagery, multi-scale information of the same scenes can represent the scene semantics to a certain extent but lacks an efficient fusion expression manner. Meanwhile, the current pre-trained AlexNet architecture lacks a kind of appropriate supervision for enhancing the performance of this model, which easily causes overfitting. In this paper, an improved pre-trained AlexNet architecture named pre-trained AlexNet-SPP-SS has been proposed, which incorporates the scale pooling—spatial pyramid pooling (SPP) and side supervision (SS) to improve the above two situations. Extensive experimental results conducted on the UC Merced dataset and the Google Image dataset of SIRI-WHU have demonstrated that the proposed pre-trained AlexNet-SPP-SS model is superior to the original AlexNet architecture as well as the traditional scene classification methods. Full article

To apply satellite-retrieved soil moisture to a short-range weather prediction, we review a stochastic approach for reducing foot print scale biases and estimating its uncertainties. First, we discuss a challenge of representativeness errors. Before describing retrieval errors in more detail, we clarify a conceptual difference between error and uncertainty in basic metrological terms of the International Organization for Standardization (ISO), and briefly summarize how current retrieval algorithms deal with a challenge of land surface heterogeneity. As compared to relative approaches such as Triple Collocation, or cumulative distribution function (CDF) matching that aim for climatology stationary errors at time-scale of years, we address a stochastic approach for reducing instantaneous retrieval errors at time-scale of several hours to days. The stochastic approach has a potential as a global scheme to resolve systematic errors introducing from instrumental measurements, geo-physical parameters, and surface heterogeneity across the globe, because it does not rely on the ground measurements or reference data to be compared with. Full article

Accurate and timely change detection of the Earth’s surface features is extremely important for understanding the relationships and interactions between people and natural phenomena. Owing to the all-weather response capability, polarimetric synthetic aperture radar (PolSAR) has become a key tool for change detection. Change detection includes both unsupervised and supervised methods. Unsupervised change detection is simple and effective, but cannot detect the type of land cover change. Supervised change detection can detect the type of land cover change, but is easily affected and depended by the human interventions. To solve these problems, a novel method of change detection using a joint-classification classifier (JCC) based on a similarity measure is introduced. The similarity measure is obtained by a test statistic and the Kittler and Illingworth (TSKI) minimum-error thresholding algorithm, which is used to automatically control the JCC. The efficiency of the proposed method is demonstrated by the use of bi-temporal PolSAR images acquired by RADARSAT-2 over Wuhan, China. The experimental results show that the proposed method can identify the different types of land cover change and can reduce both the false detection rate and false alarm rate in the change detection. Full article

High-resolution synthetic aperture radar (SAR) wind observations provide fine structural information for tropical cycles and could be assimilated into numerical weather prediction (NWP) models. However, in the conventional method assimilating the u and v components for SAR wind observations (SAR_uv), the wind direction is not a state vector and its observational error is not considered during the assimilation calculation. In this paper, an improved method for wind observation directly assimilates the SAR wind observations in the form of speed and direction (SAR_sd). This method was implemented to assimilate the sea surface wind retrieved from Sentinel-1 synthetic aperture radar (SAR) in the basic three-dimensional variational system for the Weather Research and Forecasting Model (WRF 3DVAR). Furthermore, a new quality control scheme for wind observations is also presented. Typhoon Lionrock in August 2016 is chosen as a case study to investigate and compare both assimilation methods. The experimental results show that the SAR wind observations can increase the number of the effective observations in the area of a typhoon and have a positive impact on the assimilation analysis. The numerical forecast results for this case show better results for the SAR_sd method than for the SAR_uv method. The SAR_sd method looks very promising for winds assimilation under typhoon conditions, but more cases need to be considered to draw final conclusions. Full article

This paper analyzes a method for Synthetic Aperture Radar (SAR) Tomographic (TomoSAR) imaging, allowing the detection of multiple scatterers that can exhibit time deformation and thermal dilation by using a CFAR (Constant False Alarm Rate) approach. In the last decade, several methods for TomoSAR have been proposed. The objective of this paper is to present the results obtained on high resolution tomographic SAR data of urban areas, by using a statistical test for detecting multiple scatterers that takes into account phase variations due to possible deformations and/or thermal dilation. The test can be evaluated in terms of probability of detection (P_D) and probability of false alarm (P_FA), and is based on an approximation of a Generalized Likelihood Ratio Test (GLRT), denoted as Fast-Sup-GLRT. It was already applied and validated by the authors in the 3D case, while here it is extended and experimented in the 5D case. Numerical experiments on simulated and on StripMap TerraSAR-X (TSX) data have been carried out. The presented results show that the adopted method allows the detection of a large number of scatterers and the estimation of their position with a good accuracy, and that the consideration of the thermal dilation and surface deformation helps in recovering more single and double scatterers, with respect to the case in which these contributions are not taken into account. Moreover, the capability of method to provide reliable estimates of the deformations in urban structure suggests its use in structure stress monitoring. Full article

Forest structure attributes produced from terrestrial laser scanning (TLS) rely on normalisation of the point cloud values from sensor coordinates to height above ground. One method to do this is through the derivation of an accurate and repeatable digital elevation model (DEM) from the TLS point cloud that is used to adjust the height. The primary aim of this paper was to test a number of TLS scan configurations, filtering options and output DEM grid resolutions (from 0.02 m to 1.0 m) to define a best practice method for DEM generation in sub-tropical forest environments. The generated DEMs were compared to both total station (TS) spot heights and a 1-m DEM generated from airborne laser scanning (ALS) to assess accuracy. The comparison to TS spot heights found that a DEM produced using the minimum elevation (minimum Z value) from a point cloud derived from a single scan had mean errors >1 m for DEM grid resolutions <0.2 m at a 25-m plot radius. At a 1-m grid resolution, the mean error was 0.19 m. The addition of a filtering approach that combined a median filter with a progressive morphological filter and a global percentile filter was able to reduce mean error of the 0.02-m grid resolution DEM to 0.31 m at a 25-m plot radius using all returns. Using multiple scan positions to derive the DEM reduced the mean error for all DEM methods. Our results suggest that a simple minimum Z filtering DEM method using a single scan at the grid resolution of 1 m can produce mean errors <0.2 m, but for a small grid resolution, such as 0.02 m, a more complex filtering approach and multiple scan positions are required to reduced mean errors. The additional validation data provided by the 1-m ALS DEM showed that when using the combined filtering method on a point cloud derived from a single scan at the plot centre, errors between 0.1 and 0.5 m occurred in the TLS DEM for all tested grid resolutions at a plot radius of 25 m. These findings present a protocol for DEM production from TLS data at a range of grid resolutions and provide an overview of factors affecting DEMs produced from single and multiple TLS scan positions. Full article

Satellite gravity data from the Gravity Recovery and Climate Experiment (GRACE) provides a quantitative measure of terrestrial water storage (TWS) change at different temporal and spatial scales. In this study, we investigate the ability of GRACE to quantitatively monitor long-term hydrological characteristics over the Lake Volta region. Principal component analysis (PCA) is employed to study temporal and spatial variability of long-term TWS changes. Long-term Lake Volta water storage change appears to be the dominant long-term TWS change signal in the Volta basin. GRACE-derived TWS changes and precipitation variations compiled by the Global Precipitation Climatology Centre (GPCC) are related both temporally and spatially, but spatial leakage attenuates the magnitude of GRACE estimates, especially at small regional scales. Using constrained forward modeling, we successfully remove leakage error in GRACE estimates. After this leakage correction, GRACE-derived Lake Volta water storage changes agree remarkably well with independent estimates from satellite altimetry at interannual and longer time scales. This demonstrates the value of GRACE estimates to monitor and quantify water storage changes in lakes, especially in relatively small regions with complicated topography. Full article

A Probabilistic Weighted Archetypal Analysis method with Earth Mover’s Distance (PWAA-EMD) is proposed to extract endmembers from hyperspectral imagery (HSI). The PWAA-EMD first utilizes the EMD dissimilarity matrix to weight the coefficient matrix in the regular Archetypal Analysis (AA). The EMD metric considers manifold structures of spectral signatures in the HSI data and could better quantify the dissimilarity features among pairwise pixels. Second, the PWAA-EMD adopts the Bayesian framework and formulates the improved AA into a probabilistic inference problem by maximizing a joint posterior density. Third, the optimization problem is solved by the iterative multiplicative update scheme, with a careful initialization from the two-stage algorithm and the proper endmembers are finally obtained. The synthetic and real Cuprite Hyperspectral datasets are utilized to verify the performance of PWAA-EMD and five popular methods are implemented to make comparisons. The results show that PWAA-EMD surpasses all the five methods in the average results of spectral angle distance (SAD) and root-mean-square-error (RMSE). Especially, the PWAA-EMD obtains more accurate estimation than AA in almost all the classes of endmembers including two similar ones. Therefore, the PWAA-EMD could be an alternative choice for endmember extraction on the hyperspectral data. Full article
