World Electric Vehicle Journal

Research

12 pages, 5791 KiB

Open AccessArticle

Analysis and Suppression of Spoke-Type Permanent Magnet Machines Cogging Torque with Different Conditions for Electric Vehicles

by Jinlin Huang and Chen Wang

World Electr. Veh. J. 2024, 15(8), 376; https://doi.org/10.3390/wevj15080376 - 19 Aug 2024

Viewed by 402

Abstract

Spoke-type permanent magnet (STPM) machines have high power density and low cost due to flux concentrated effect and high air-gap flux density, but they can cause high cogging torque and torque ripple. To reduce the cogging torque, the analytical model considering a rotor [...] Read more.

Spoke-type permanent magnet (STPM) machines have high power density and low cost due to flux concentrated effect and high air-gap flux density, but they can cause high cogging torque and torque ripple. To reduce the cogging torque, the analytical model considering a rotor slot is established and compared with the finite element mothed (FEM). Then, the cogging torque production mechanism is revealed and analyzed under different conditions, which provides direction to optimize the cogging torque STPM machines. The harmonic content of cogging torque under different conditions is obtained based on the freezing permeability (FP) method. It is found that the fundamental waves mainly generate the cogging torque under a no-load condition, and it is mainly generated by the second harmonics under an on-load condition. In addition, the optimization method is introduced and researched, including rotor slot width, uneven rotor core, and so on. Finally, a 50 kW STPM machine prototype is manufactured and tested to verify the accuracy and efficiency of the analysis method. Full article

(This article belongs to the Special Issue Advanced Electrical Machine and Power Electronics for the Charging and Drive System of Electric Vehicles (EVs))

► Show Figures

Figure 1

15 pages, 4744 KiB

Open AccessArticle

Parameter Identification for Fault Analysis of Permanent Magnet Synchronous Motors Based on Transient Processes

by Chaoqiang Wu and Alexander Verl

World Electr. Veh. J. 2024, 15(8), 347; https://doi.org/10.3390/wevj15080347 - 1 Aug 2024

Viewed by 472

Abstract

As the market for hybrid and electric vehicles expands, electric motor production and testing technology must be continuously improved to meet the cost and quality requirements of mass production. In order to detect faults in motors during the production process, a condition monitoring [...] Read more.

As the market for hybrid and electric vehicles expands, electric motor production and testing technology must be continuously improved to meet the cost and quality requirements of mass production. In order to detect faults in motors during the production process, a condition monitoring tool is used for the motor end line. During most condition monitoring, the motor operates in a static state where the speed of the motor remains constant and the voltage/current is recorded for a certain period. This process usually takes a long time and requires a loader to drag the motor to a standstill at a constant speed. In this paper, various transient process testing methods are introduced. For these processes, only transient operation of the motor, such as acceleration, loss, or a short circuit, is required. By analyzing the measurement results and simulation results of motor models, unhealthy motors can be detected more effectively. Full article

(This article belongs to the Special Issue Advanced Electrical Machine and Power Electronics for the Charging and Drive System of Electric Vehicles (EVs))

► Show Figures

Figure 1

17 pages, 8374 KiB

Open AccessArticle

Vibration Performance Analysis of a Yokeless Stator Axial Flux PM Motor with Distributed Winding for Electric Vehicle Application

by Xue Yu, Qin Wang, Yu Fu, Hao Chen, Jianfu Zhang and Weiwei Geng

World Electr. Veh. J. 2024, 15(8), 335; https://doi.org/10.3390/wevj15080335 - 26 Jul 2024

Viewed by 586

Abstract

This article presents a detailed analysis of the electromagnetic force and vibration behavior of a new axial flux permanent magnet (AFPM) machine with a yokeless stator and interior PM rotor. Firstly, the configuration of an AFPM machine with a dual rotor and a [...] Read more.

This article presents a detailed analysis of the electromagnetic force and vibration behavior of a new axial flux permanent magnet (AFPM) machine with a yokeless stator and interior PM rotor. Firstly, the configuration of an AFPM machine with a dual rotor and a sandwiched stator is introduced, including the structural design, fixation of the yokeless stator and segmented skew rotor structure. Then, the influence of anisotropic material and a fixed structure on stator modes is analyzed, including elastic modulus, shear model, the skew angle of slot and the thickness of stator yoke. Furthermore, a new non-equally segmented skew rotor structure is proposed and calculated for the reduction in vibration based on the multiphysics model. Three different segmented skew rotor schemes are compared to illustrate the influence of reducing vibration and noise. The predicted results show that the effect of the non-equally segmented skew rotor on reducing vibration is better than the other two schemes. Finally, a 120 kW AFPM motor is experimented with and the result matches well with the predicted data. The vibration performance of the AFPM motor with a dual rotor and sandwiched yokeless stator is revealed comprehensively. Full article

(This article belongs to the Special Issue Advanced Electrical Machine and Power Electronics for the Charging and Drive System of Electric Vehicles (EVs))

► Show Figures

Figure 1

21 pages, 5003 KiB

Open AccessArticle

Analytical Calculation of Magnetic Field and Analysis of Rotor Permeability Effects on Permanent Magnet Synchronous Motor with Fractional Slot Concentrated Winding

by Xuandong Wu, Huaiyuan Zhang, Cunxiang Yang and Hongbo Qiu

World Electr. Veh. J. 2024, 15(7), 312; https://doi.org/10.3390/wevj15070312 - 16 Jul 2024

Viewed by 674

Abstract

Accurate calculation of the flux and the magnetic field distribution of fractional slot concentrated winding permanent magnet synchronous motor (FSCW PMSM) is the basis for motor performance analysis, and rapid calculation is key. In this paper, to solve the problem of difficult modeling [...] Read more.

Accurate calculation of the flux and the magnetic field distribution of fractional slot concentrated winding permanent magnet synchronous motor (FSCW PMSM) is the basis for motor performance analysis, and rapid calculation is key. In this paper, to solve the problem of difficult modeling and accuracy guarantee of the flux linkage differential method, a method is proposed to calculate the flux and the no-load back EMF by the slotless subdomain model. By introducing the leakage flux calculation link, the calculation accuracy is improved, the analytical method results are compared with the finite element method results, and the effectiveness of the proposed method is verified. On this basis, the nonlinear variations of the magnetic field and the no-load back EMF with rotor permeability are determined, and the influence mechanism of rotor length and rotor permeability on the main magnetic circuit is revealed. Finally, an experiment of the prototype is carried out, and the correctness and accuracy of the analytical method and the finite element method is verified by comparing with the experimental results. Full article

(This article belongs to the Special Issue Advanced Electrical Machine and Power Electronics for the Charging and Drive System of Electric Vehicles (EVs))

► Show Figures

Figure 1

18 pages, 5451 KiB

Open AccessArticle

Permanent Magnet Installation Optimization of Outer Rotor PMSM Depending on Adding Auxiliary Teeth

by Jiayin Su, Rui Nie, Peixin Wang, Shuai Xu, Jing Liang and Jikai Si

World Electr. Veh. J. 2024, 15(6), 271; https://doi.org/10.3390/wevj15060271 - 19 Jun 2024

Viewed by 881

Abstract

To reduce the influence of the permanent magnet (PM) installation error on the electromagnetic characteristics of the outer rotor permanent magnet synchronous motor (OPMSM), the rotor structure of the OPMSM is optimized in this paper. The optimization method of adding auxiliary teeth on [...] Read more.

To reduce the influence of the permanent magnet (PM) installation error on the electromagnetic characteristics of the outer rotor permanent magnet synchronous motor (OPMSM), the rotor structure of the OPMSM is optimized in this paper. The optimization method of adding auxiliary teeth on the surface of the rotor core is studied, and the influence of different auxiliary teeth heights on the electromagnetic performance of OPMSM is analyzed. It is found that adding auxiliary teeth with suitable height can greatly reduce the installation error of the PM, increase the mechanical stability of the motor, and ensure that the electromagnetic characteristics of the motor remain at a good level. Firstly, the topology and parameters of the motor proposed in this paper are introduced and analyzed. Secondly, the influence of PM installation error on the electromagnetic performance of the motor is analyzed based on the finite element method (FEM), and the necessity of eliminating PM installation error is demonstrated. Then, the parametric scanning method is used to analyze the influence of auxiliary teeth height change on the electromagnetic performance of the motor, and the selection standard of the optimal auxiliary teeth height is determined. By comparing and analyzing OPMSM with different sizes and different pole–slot ratios, the universality of the conclusions is demonstrated. Full article

(This article belongs to the Special Issue Advanced Electrical Machine and Power Electronics for the Charging and Drive System of Electric Vehicles (EVs))

► Show Figures

Figure 1

19 pages, 26111 KiB

Open AccessArticle

Optimization Design of Variable Reluctance Resolver Based on Three-phase Symmetrical Winding

by Xinmin Li, Jiannan Chen and Zhen Zhang

World Electr. Veh. J. 2024, 15(5), 201; https://doi.org/10.3390/wevj15050201 - 6 May 2024

Viewed by 1109

Abstract

In order to ease the structure and manufacturing process of the variable reluctance (VR) resolver, the three-phase symmetrical single-layer winding commonly used in the stator winding of permanent magnet synchronous motors (PMSM) is applied to the VR resolver in this paper. The proposed [...] Read more.

In order to ease the structure and manufacturing process of the variable reluctance (VR) resolver, the three-phase symmetrical single-layer winding commonly used in the stator winding of permanent magnet synchronous motors (PMSM) is applied to the VR resolver in this paper. The proposed resolver has the same winding direction and number of turns on all teeth. And the non-overlapping distribution of the three-phase windings of the resolver is ensured. For this novel resolver, the resolver-to-digital conversion (RDC) method references the ultra-high-frequency (UHF) signal injection method used when a PMSM is powered off and restarted. Instead of the need for the orthogonal envelope RDC required by conventional resolvers, the absolute position of the rotor can be obtained. In this paper, the prototype of the proposed resolver and the peripheral circuits are fabricated and compared with the position detected by the optical encoder, and the validity of the proposed resolver and the accuracy of the RDC are verified by the results of the comparison experiments. Full article

(This article belongs to the Special Issue Advanced Electrical Machine and Power Electronics for the Charging and Drive System of Electric Vehicles (EVs))

► Show Figures

Figure 1

21 pages, 4797 KiB

Open AccessArticle

Sliding Mode Control of an Electric Vehicle Driven by a New Powertrain Technology Based on a Dual-Star Induction Machine

by Basma Benbouya, Hocine Cheghib, Daniela Chrenko, Maria Teresa Delgado, Yanis Hamoudi, Jose Rodriguez and Mohamed Abdelrahem

World Electr. Veh. J. 2024, 15(4), 155; https://doi.org/10.3390/wevj15040155 - 9 Apr 2024

Viewed by 1472

Abstract

This article examines a new powertrain system for electric vehicles based on the dual-star induction machine, presented as a promising option due to its significant advantages in terms of performance, energy efficiency, and reliability. This system could play a key role in the [...] Read more.

This article examines a new powertrain system for electric vehicles based on the dual-star induction machine, presented as a promising option due to its significant advantages in terms of performance, energy efficiency, and reliability. This system could play a key role in the evolution of electro-mobility technology. The dual-star induction machine reduces electromagnetic torque fluctuations, limits current harmonics, improves power factor, and enables half-speed operation. Our study focuses on the control strategy and operation of the traction chain for electric vehicles propelled by the dual-star induction machine (DSIM) using Matlab software with version 2017. We integrate the battery as the main energy source, along with three-level static converters for energy conversion in the vehicle’s four operating quadrants. We have opted for sliding mode control, which has proven to be feasible and robust against external disturbances. Although we have modeled driver behavior, we consider it as an aspect of control, to which we add the driving profile to guide our evaluation of the control to be used for vehicle operation. The results of our study demonstrate the reliability and robustness of DSIM for electric vehicle motorization and speed control. Promoting this technology is essential to improve the overall performance and efficiency of electric vehicles, especially in traction and braking modes for energy recovery. This underscores the importance of DSIM in the sustainable development of the electric transportation system. Full article

(This article belongs to the Special Issue Advanced Electrical Machine and Power Electronics for the Charging and Drive System of Electric Vehicles (EVs))

► Show Figures

Figure 1

17 pages, 6709 KiB

Open AccessArticle

An Open-Circuit Fault Diagnosis System Based on Neural Networks in the Inverter of Three-Phase Permanent Magnet Synchronous Motor (PMSM)

by Kenny Sau Kang Chu, Kuew Wai Chew, Yoong Choon Chang and Stella Morris

World Electr. Veh. J. 2024, 15(2), 71; https://doi.org/10.3390/wevj15020071 - 16 Feb 2024

Viewed by 1644

Abstract

Three-phase motors find extensive applications in various industries. Open-circuit faults are a common occurrence in inverters, and the open-circuit fault diagnosis system plays a crucial role in identifying and addressing these faults to enhance the safety of motor operations. Nevertheless, the current open-circuit [...] Read more.

Three-phase motors find extensive applications in various industries. Open-circuit faults are a common occurrence in inverters, and the open-circuit fault diagnosis system plays a crucial role in identifying and addressing these faults to enhance the safety of motor operations. Nevertheless, the current open-circuit fault diagnosis system faces challenges in precisely detecting specific faulty switches. The proposed work presents a neural network-based open-circuit fault diagnosis system for identifying faulty power switches in inverter-driven motor systems. The system leverages trained phase-to-phase voltage data from the motor to recognize the type and location of faults in each phase with high accuracy. Employing separate neural networks for each of the three phases in a three-phase permanent magnet synchronous motor, the system achieves an outstanding overall fault detection accuracy of approximately 99.8%, with CNN and CNN-LSTM architectures demonstrating superior performance. This work makes two key contributions: (1) implementing neural networks to significantly improve the accuracy of locating faulty switches in open-circuit fault scenarios, and (2) identifying the optimal neural network architecture for effective fault diagnosis within the proposed system. Full article

(This article belongs to the Special Issue Advanced Electrical Machine and Power Electronics for the Charging and Drive System of Electric Vehicles (EVs))

► Show Figures
