J. Compos. Sci., Volume 8, Issue 9 (September 2024) – 4 articles

We have developed a convenient route to transform biomass power plant ashes (BPPA) into porous sponge-like fertilizer composites. The absence of water prevents the chemical reaction and carbon dioxide formation when concentrated sulfuric acid is mixed with BPPA and CaCO₃. Adding water, however, initiates the protonation reaction of carbonate ion content and starts CO₂ evolution. The key element of the method was that the BPPA and, optionally, CaCO₃ and/or CaSO₄·0.5H₂O were mixed with concentrated sulfuric acid to make a paste-like consistency. No gas evolution occurred at this stage; however, with the subsequent and controlled addition of water, CO₂ gas evolved and was released through the channels developed in the pastry-like material due to the internal gas pressure, but without foaming. Using a screw-containing tube reactor, the water can be introduced under pressure. Due to the pressure, the pores in the pastry-like material became smaller, and consequently, the mechanical strength of the granulated and solidified mixture became higher than that of the reaction products prepared under atmospheric pressure. The main reaction products were syngenite (K₂Ca(SO₄)₂·H₂O) and polyhalite (K₂Ca₂Mg(SO₄)₄·2H₂O). These compounds are valuable fertilizer components in themselves, but the material’s porous nature helps absorb solutions of microelement fertilizers. Surprisingly, concentrated ammonium nitrate solutions transform the syngenite content of the porous fertilizer into ammonium calcium sulfate ((NH₄)₂Ca(SO₄)₂·2H₂O, koktaite). Koktaite is slightly soluble in water, thus the amount of ammonium ion released on the dissolution of koktaite depends on the amount of available water. Accordingly, ammonium ion release for plants can be increased with rain or irrigation, and koktaite is undissolved and does not decompose in drought situations. The pores (holes) of this sponge-like fertilizer product can be filled with different solutions containing other fertilizer components (phosphates, zinc, etc.) to adjust the composition of the requested fertilizer compositions for particular soils and plant production. The method allows the preparation of ammonium nitrate composite fertilizers containing metallic microelements, and various solid sponge-like composite materials with adjusted amounts of slowly releasing fertilizer components like syngenite and koktaite. Full article

This paper presents a post-forming technique utilising both induction heating and rotary draw bending (RDB) for carbon fibre-reinforced polyetherentherketone (CF/PEEK) tubular structures. Existing post-forming techniques are unable to form CF/PEEK tubes due to the lack of a suitable mandrel material to provide internal support to the tube while withstanding high heat from melting the PEEK matrix during forming. This is addressed by using a steel spring mandrel in the tube induction heating process. In this study, four sets of [±60°]₄ CF/PEEK tubes were formed using an induction heater-incorporated RDB setup into 45°, 90°, 135°, and 180° bends with a bending ratio of 2. Optical characterisation was performed to analyse tube fibre angle changes. A post-forming fibre angle prediction model previously derived for CF/polyamide 6 tubes was validated for its application in predicting fibre angle changes for CF/PEEK tubes by comparing the prediction with the characterised results. Full article

Stress shielding is a problem for traditional metal bone fixation plates made of magnesium and titanium alloys. This problem can be solved by using composite materials with a low elastic modulus. This study analyzed the effect of carbon fiber reinforced PEEK (CFRP) composites on stress shielding under static loading using finite element simulations. Callus formation times relative to the healing period were gradually imposed according to the elapsed time, considering 1% and 75% as healing stages. The Inventor© 3D CAD 2024 software was used for modeling, and the ANSYS© FEA R2023 software was used for analysis. The results showed that metal fixation plates made of titanium and magnesium alloys transferred less stress to the bone than the CFRP fixation plate. In particular, the use of the CFRP fixation plate resulted in a higher peak stress and a more uniform stress field in the bone, especially in the bone-plate contact area, where the risk of stress shielding is higher in the 1% and 75% healing phases. Full article

In the context of global sustainable development, using natural fibers as reinforcement for composites have become increasingly attractive due to their lightweight, abundant availability, renewability, and comparable specific properties to conventional fibers. This paper investigates the tensile properties of a sycamore bark fiber-reinforced composite. The tensile tests using digital image correlation showed that, by adding 18% by volume of sycamore bark for the polyester matrix, the tensile modulus achieves 4788.4 ± 940.1 MPa. Moreover, the tensile strength of the polyester resin increased by approximately 90% when reinforced with sycamore bark fiber, achieving a tensile strength of 64.5 ± 13.4 MPa. These mechanical properties are determined by the way loads are transferred between the polyester matrix and fibers and by the strength of the bond between the fiber-matrix interfaces. Since it is difficult and time consuming to characterize the mechanical properties of natural fibers, an alternative approach was proposed in this study. The method consists of the identification of the fiber elastic modulus using a finite element analysis approach, based on tensile tests conducted on the sycamore bark fiber-reinforced composites. The model correctly describes the overall composite behavior, a good agreement is found between the experimental, and the finite element predicted stress–strain curves. The identified sycamore bark fiber elastic modulus is 17,763 ± 6051 MPa. These results show that sycamore bark fibers can be used as reinforcements to produce composite materials. Full article
